  • Page 1 S110-5W User Manual www.kaadasgroup.com...

  • Page 2: Table Of Contents

    Cautions This section contains important information to ensure the user's safety and prevent potential damage to property. Please, read this section carefully and use the product accordingly. Content 1 How to install Delete fingerprint Package Content Delete card Explosive View Opening Mode Setting Before Installation System Setting...

  • Page 3: How To Install

    1 How to install Package Content This described package content is for reference only, the real products should be considered as final. If some components lost, please check with the sellers. Outside escutcheon Inside escutcheon Installation Template Mortise Strike Plate Assembly Mechanical Key with rubber gasket with rubber gasket...

  • Page 4: Explosive View

    Explosive View 1. Back Cover 2. Connecting mounting screw（3pcs） 3. Inside escutcheon assembly 4. Pressure spring （2pcs） 5. Mounting plate 6. Mortise 7. Screw bolt （3pcs） 8. Outside escutcheon assembly 9. Square shaft （2pcs） 10. Fixed screw for key cylinder 11.
  • Page 5 •Do not short-circuit the two poles of the battery lead with metal objects in case of explosion. •Making sure replacement or maintenance are done by professional person authorized by Kaadas. •Your warranty may invalidate if you used accessories produced by other manufacturer or not recommended by Kaadas. Disposal of used battery and lock •Please understand the local electronic product classification and collection system.

  • Page 6: Before Installation

    Before Installation Check Door Open Direction Right-out Right-in Left-out Left-in...
  • Page 7 Change latch bolt direction 1. Move the latch 2. Push the both switcher to latch bolt the other end as inside the the arrow shows mortise Directional screw 3. Turn around 180 degree 4. Let the latch bolt eject Caution: Make sure the position of directional screw is faced to the indoor direction, then fasten them properly.
  • Page 8 Change Handle Direction Change Outside escutcheon Handle Direction Front panel Front panel silicone pad silicone pad Screws Screws Positional Component Positional Component Shield Sleeve Shield Sleeve Cable Taking out screws, positional Rotating the handle to the other Put the cable into the right end, end.
  • Page 9 Change Inside escutcheon Handle Direction Rear panel Rear panel silicone pad silicone pad Screws Screws Positional Positional Component Component Shield Shield Sleeve Sleeve Taking out screws and positional Rotating the handle to the other Place positional component component in proper order. end.

  • Page 10: Installation Steps

    Installation Steps Connection screw bolts Connection screw bolts Indoor square shaft Pressure spring Connecting cable for front panel Connection screw bolts Connecting cable for mortise Caution: Caution: Do not make the mortise deadbolt come out. Spring: the big end is downward. Mark and drill bores by using the Put the key cylinder into the Fix 3 screw bolts on the front panel,...
  • Page 11 Mounting screw Connecting cable for mortise Connecting cable for mortise Connecting cable for front panel Connecting cable for front panel Pass the connection wire through the bottom bore. Install the mounting plate with fixing Then align and insert square into mortise to make the screws tightly against the door surface front panel fit against the door closely.
  • Page 12 Connecting mounting screw Square shaft Square shaft Pressure spring Pressure spring Connecting Connecting cable cable for mortise for mortise Connecting Connecting Connecting cable cable mounting for front panel for front panel screw Caution: Caution: According to the door thickness, cut the night latch key pick in 1.

  • Page 13: Product Overview

    2 Product Overview Outside escutcheon Inside escutcheon Touch keypad Back cover Card reader area Safe handle switch Fingerprint sensor Reset button Thumb turn Emergency power USB port Caution: Pictures above are just for reference, please refer to the real product as final.

  • Page 14: How To Set

    3 How to set Before set There are normal mode and security mode in the product. The default mode is normal mode. Security Mode Normal Mode Master PIN code Default Master PIN code：12345678 Default Master PIN code：12345678 User PIN code 6 groups 10 groups 6-12 digits...
  • Page 15 User Number When you in security mode, you shall edit user number before enroll PIN code/fingerprint/card. When you need to delete one user, you can enter the user number to delete. You can fill your user information in below sheet for convenience Name PIN code Fingerprint...

  • Page 16: Menu Index

    Menu index 1. Add user pin code 2. Add user fingerprint 3. Add user card 4. Delete user pin code Press【1】 5. Delete user fingerprint 6. Delete user card 7. Set the openning mode 9. Change master pin code 1. User setting 2.

  • Page 17: Enroll User Pin Code

    User Setting Access into master mode Enroll user PIN code Access into master mode Default master PIN code is Press [1] for user setting.Then press [1] to enroll user PIN code. Enter 2 digital user number (00-09), and 12345678. confirm with [#] key Enter user PIN code (6-12 digits), and confirm with [#] 1.

  • Page 18: Delete User Pin Code

    Press [1] for user setting.Then press [3] to enroll user Press [2] to delete all users card. Enter 2 digital user number (00-99), and confirm Voice prompt of "Deletion succeeded" with [#] key. Delete User Card Access into master mode Place card on the card icon area until beep sound and voice prompt "Enrollment succeed".

  • Page 19: System Setting

    System Setting Extension Function Access into master mode Volume Setting Access into master mode Press [4] for function extension. Press [1] to join network. Press [2] for system setting. Then press [1] for volume Press [2] to log off network. setting.

  • Page 20: How To Use

    4 How to use Open from outside 1. PIN code opening 2. Fingerprint opening 3. Card opening Enter PIN code Card reader area Fingerprint sensor Press the Press the Press the handle to handle to handle to open open open Touch pad screen by palm to Place the enrolled finger properly Place the enrolled card properly on...

  • Page 21: Open Door By Mechanical Key Override

    Open door by mechanical key override Mechanical key First,Loose the cover of mechanical key from the position for pull, then rotate it 90 degrees. Next, insert the key into key hole and rotate it with proper angles. Mechanical key cover Caution: In case of forgetting PIN code, battery run out or system error, mechanical key is used to open door as backup mode.

  • Page 22: Other Features

    Emergency power supply 5 Other Features When the battery voltage is too low to open the lock Restore to factory setting from outside, you can use 5V power bank to charge Double click [RES] button to make the door lock via Micro USB port. After the door is the lock restore to factory unlocked, please replace all batteries immediately.

  • Page 23: Safe Handle Feature

    Safe Handle Feature Safe handle switch 1.Enable: move the safe handle switch to display ‘red’ mark. Once safe handle feature is enabled, the indoor handle will be locked. 2.Disable: move the safe handle switch to display ‘green’ mark. The indoor handle can be pressed and turn upward freely.
  • Page 24 Shenzhen Kaadas Intelligent Technology Co.; Ltd reserves all rights for the final interpretation to this user manual. All design and specifications are subject to change without notice. V1.0...
