Scan the QR Code™ below
for more info about this product:
Do not exceed the maximum rated weight
specified. Otherwise, serious injury or
property damage may occur.
200x200 | 300x200 | 300x300 | 400x200 | 400x300 | 400x400
600x200 | 600x300 | 600x400 | 800x200 | 800x300 | 800x400
Version October 2017
Advertisement
Related Manuals for QualGear QG-TM-002-BLK
Summary of Contents for QualGear QG-TM-002-BLK
- Page 1 Scan the QR Code™ below for more info about this product: Do not exceed the maximum rated weight specified. Otherwise, serious injury or property damage may occur. 200x200 | 300x200 | 300x300 | 400x200 | 400x300 | 400x400 600x200 | 600x300 | 600x400 | 800x200 | 800x300 | 800x400 Version October 2017...
-
Page 2: Parts Checklist
If any parts are missing or damaged, contact your local distributor or WARNING support@qualgear.com for replacement parts and do not start assembly and installation until you receive all the parts. Do not begin to install your QualGear product Tighten screws firmly, but do not over tighten. - Page 3 Mounting to a Wooden Stud Wall Bubble Level For concrete or brick NOTE wall mounting, follow Step 1b. Stud Finder Using an edge-to-edge stud finder, find the Using a level, mark the centerline of the stud. Wall Plate edges of the stud. Mount the wall plate (A) and tighten it with the provided 65mm 65mm...
- Page 4 Mounting to a Concrete or a Brick Wall NOTE Do NOT use power drill and do NOT over tighten the lag bolts. Marking Template Bubble Level Wall Plate Hold the marking template (C) provided against the wall where you want to install your TV, mark six holes for drilling.
- Page 5 M-A/ M-B Installing to a Flat Back Panel of a TV Flat Back Panel 5.5mm Adapter Bracket M-C/ M-D 8.5mm Choose the appropriate screws and washers according to the type of your TV, and attach adapter brackets (B) to the back of the TV using a Phillips screwdriver.
- Page 6 Installing to a Curved or Recessed Back Panel of a TV Choose the appropriate screws, washers, and spacers (if necessary) according to the type of your T V and attach adapter brackets (B) to the back of the TV using a Phillips screwdriver. 8.5mm Recessed Back Panel IMPORTANT!
