Terex Z4525XCF-101 Operator's Manual page 9

First Edition • Second Printing
Maximum capacity Runaway hazard
Recovery procedure if tilt alarm sounds while
elevated.
Platform uphill: Platform downhill:
1 Lower primary. 1 Retract primary.
2 Lower secondary. 2 Lower secondary.
3 Retract primary. 3 Lower primary.
Do not use ether or Crush hazard
other high energy
starting aids on
machines equipped
with glow plugs.
Part No. 1301594GT
Symbol and Hazard Pictorials Definitions
Color coded
direction arrows
Access by trained
and authorized
personnel onlyl
Z
Voltage rating for
power to platform
Emergency lowering Read the service
® -45 XC ™
Operator's Manual
Pressure rating for air
line to platform
manual
7
