Summary of Contents for Beckhoff FC9024
- Page 1 Installation- and Operating instructions for FC9001-0010, FC9011, FC9002, FC9004 FC9022, FC9024, FC9062 PCI/PCIe Cards for Ethernet Version: 2.3 Date: 2023-12-20...
-
Page 3: Table Of Contents
State at Delivery Operator’s obligation to exercise diligence 1.2.2 Description of safety symbols 2 Product Description Product Overview 2.1.1 FC9001-0010, FC9011, FC9022, FC9024 PCI Ethernet 2.1.2 FC9002, FC9004 PCI Ethernet 2.1.3 FC9062 PCIe Modul Technical data 2.2.1 FC9001-0010, FC9011, FC9002, FC9004 2.2.2... - Page 4 Table of contents 4.2.1 Compatible Devices EtherCAT tab Statistics tab Diagnostics tab 5 Appendix Beckhoff Support & Service 5.1.1 Beckhoff branches and partner companies 5.1.2 Beckhoff headquarters 5.1.3 Beckhoff Support 5.1.4 Beckhoff Service FC90xx...
-
Page 5: Foreword
1.1.4 Copyright © Beckhoff Automation GmbH & Co. KG. Publication of this document on websites other than ours is prohibited. Offenders will be held liable for the payment of damages. All rights reserved in the event of the grant of a patent, utility model or design. -
Page 6: Safety Instructions
Foreword 1.2 Safety instructions 1.2.1 State at Delivery All the components are supplied in particular hardware and software configurations appropriate for the application. Changes to the hardware or software configuration are permitted, provided they are within the specified limits for power consumption and power loss (please refer to the respective data sheet). 1.2.2 Operator’s obligation to exercise diligence The operator must ensure that •... -
Page 7: Product Description
2.1 Product Overview 2.1.1 FC9001-0010, FC9011, FC9022, FC9024 PCI Ethernet The Ethernet PCI network cards FC9001-0010, FC9011 und FC9022 from Beckhoff save space and costs. They can be used in office and automation networks and offer the following benefits: •... -
Page 8: Fc9002, Fc9004 Pci Ethernet
Product Description 2.1.2 FC9002, FC9004 PCI Ethernet Up to four Ethernet channels in one slot: The Ethernet PCI network cards from Beckhoff save space and costs. They can be used in office and automation networks and offer the following benefits: •... -
Page 9: Fc9062 Pcie Modul
Product Description 2.1.3 FC9062 PCIe Modul Beckhoff PCIe modules are based on a new definition of highly integrated PCI Express plug-in cards and follow the trend towards ever smaller PCs. The function of PC plug-in cards is integrated in a compact format that is suitable for harsh industrial environments. -
Page 10: Technical Data
- Link/ Speed (Green = 100MBit/ Orange = 1GBit) - Activity Interface to the PC 32 Bit Plug-and-Play PCI-Interface Standard driver for Intel or Beckhoff driver Standard driver standard operating system drivers for Intel-compatible NIC (Drivers can be selected separately for... -
Page 11: Fc9022, Fc9024, Fc9062
- Link/ Speed (Green = 100MBit/ Orange = 1GBit) - Activity Interface to the PC 1x PCIe-Interface Plug-And-Play Standard driver Standard driver for Intel or Beckhoff driver (Drivers can be selected separately for each channel) Real time driver TwinCAT driver for real time Ethernet Supply voltage... -
Page 12: Ethernet
Product Description 2.3 Ethernet Ethernet was originally developed by DEC, Intel and XEROX (as the "DIX" standard) for passing data between office devices. The term nowadays generally refers to the IEEE 802.3 CSMA/CD specification, published in 1985. Because of the high acceptance around the world this technology is available everywhere and is very economical. -
Page 13: Installation
Installation 3 Installation 3.1 Installation in the PC Follow the usual ESD guidelines The Ethernet cards are supplied in ESD packaging. Follow the usual ESD guidelines Warning for handling PC cards during installation! Before installing the Ethernet card, switch off the PC and any external power supplies, and separate the PC from the mains. -
Page 14: Twincat Driver For Ethernet Cards
Driver substitution via the TwinCAT System Manager: If your operating system installed its own driver for the Beckhoff Intel PCI/Ethernet card, you can substitute this driver by the TwinCAT driver for real-time Ethernet manually in order to be able to take advantage of its real-time capability. -
Page 15: Driver Installation Using The Add New Hardware Wizard
Note Under all Windows operating systems, the TwinCAT driver is installed in the same way. After installation of the Beckhoff Ethernet card, the operating system comes up with the following message during start-up: Follow the instructions of the Add Hardware Wizard. - Page 16 Installation Allow the assistant to search for a suitable driver. The TwinCAT driver for real-time Ethernet is included with the Beckhoff TwinCAT automation software. FC90xx...
- Page 17 PC. Operation of the TwinCAT drivers for real-time Ethernet requires no digital signature from Microsoft. Beckhoff has thoroughly tested this driver in conjunction with the supported hardware and has verified compatibility with Windows operating systems.
- Page 18 Installation The TwinCAT driver for real-time Ethernet was installed successfully for an Ethernet port. Exit the installation with Finish. If you are using a multi-channel Beckhoff Ethernet card, repeat the driver installation procedure for each additional channel: FC90xx...
-
Page 19: Resources
Installation Now you have to activate the TwinCAT Ethernet Protocol (see chapter Activating the TwinCAT Ethernet protocol). 3.3.1 Resources Example for the resources of an FC900x under Windows 2000 (Control Panel/System/Hardware/Device Manager/Network adapters/TwinCAT Intel PCI-Ethernet adapter/Resources): FC90xx... -
Page 20: Driver Substitution Using The Twincat System Manager
Installation 3.4 Driver substitution using the TwinCAT System Manager First install Software Install the Beckhoff TwinCAT automation software before installing the Beckhoff Note Ethernet card. Installation under Windows operating systems All screen shots of this documentation are made under Windows 2000. - Page 21 Installation Now the TwinCAT System Manager shows the real time capable (Compatible devices) and non real time capable (Incompatible devices) network cards. Chose a real time capable network card and click on the Install button. Now the TwinCAT System Manager installs the TwinCAT driver for real-time Ethernet and the TwinCAT Ethernet Protocol for the chosen device.
- Page 22 Installation Operation of the TwinCAT drivers for real-time Ethernet requires no digital signature from Microsoft. Beckhoff has thoroughly tested this driver in conjunction with the supported hardware and has verified compatibility with Windows operating systems. Click Yes to continue with the rest of the installation.
- Page 23 Installation FC90xx...
-
Page 24: Manual Driver Installation
3.5 Manual driver installation If your operating system installed its own driver for the Beckhoff Intel PCI/Ethernet card, you have to install the TwinCAT driver for real-time Ethernet manually in order to be able to take advantage of its real- time capability. - Page 25 Installation Click on Configure. FC90xx...
- Page 26 If you wish to select the associated driver yourself, select the option to display a list of all known drivers. If the Beckhoff TwinCAT automation software is already installed, the Add New Hardware Wizard will offer the TwinCAT driver for real-time Ethernet.
- Page 27 Start installing the selected driver. Operation of the TwinCAT drivers for real-time Ethernet requires no digital signature from Microsoft. Beckhoff has thoroughly tested this driver in conjunction with the supported hardware and has verified compatibility with Windows operating systems. Click Yes to continue with the rest of the installation.
- Page 28 Installation The TwinCAT driver for real-time Ethernet was installed successfully. Exit the installation with Finish. Now you have to activate the TwinCAT Ethernet Protocol (see chapter Activating the TwinCAT Ethernet protocol). FC90xx...
-
Page 29: Resources
Installation 3.5.1 Resources Example for the resources of an FC900x under Windows 2000. (Control Panel/System/Hardware/Device Manager/Network adapters/TwinCAT Intel PCI-Ethernet adapter/Resources): FC90xx... -
Page 30: Activating The Twincat Ethernet Protocol
3.6 Activating the TwinCAT Ethernet protocol In order to be able to make use of real-time capability, the TwinCAT Ethernet protocol has to be activated for the Beckhoff Intel PCI-Ethernet card. Under Start/Settings/Control Panel/Network and Dial-up Connections click on the LAN connection for which you would like to activate the TwinCAT Ethernet protocol (in the example LAN connection 2). - Page 31 Installation Select Protocol (not Service!) and click on Add. Under Beckhoff select the option TwinCAT Ethernet Protocol and click OK. FC90xx...
- Page 32 Installation Beckhoff TwinCAT Ethernet protocol is not available If the Beckhoff TwinCAT Ethernet protocol is not available for selection despite the fact Note that TwinCAT and the TwinCAT driver for real-time Ethernet have been installed, click on Data carrier, then Search, and select the file TcEther.inf in folder C:\Windows\inf.
- Page 33 Installation The TwinCAT Ethernet Protocol can be started by issuing can the command net start TcEther in a DOS Command Prompt or by restarting the PC. The TwinCAT Ethernet Protocol will be started whenever the PC is restarted. FC90xx...
-
Page 34: Searching For Devices
Installation 3.7 Searching for devices Description in TwinCAT 2 All screen shots of this description are made within TwinCAT 2. Note Switch TwinCAT to configuration mode. Start the TwinCAT System Manager. Using the right mouse button, start searching for new devices under the branch I/O Configuration \I/O devices or via the magic wand button in the button bar. - Page 35 Installation The system manager will now search the FC9004 channels for boxes (Bus Couplers, Bus Terminal controllers or Fieldbus Box modules). The system manager now wants to activate Free Run mode. Click on Yes. The system manager will now display the configuration it found: FC90xx...
- Page 36 Installation FC90xx...
-
Page 37: Configuration Via Twincat System Manager
Configuration via TwinCAT System Manager 4 Configuration via TwinCAT System Manager In the left-hand window of the TwinCAT system manager, click on the Ethernet channel you wish to configure (in the example: device 2 (RT Ethernet)). In the right-window of the TwinCAT system manager, various tabs, i.e. - General tab - Adapter tab - EtherCAT tab... -
Page 38: General Tab
Configuration via TwinCAT System Manager 4.1 General tab Name The name Device 2 (RT Ethernet) was allocated by the system manager. You may change it. Type Device type. Comment Here you can save a free comment text. Disabled This control box can be used to disable the Ethernet channel. Create Symbols If this control box is activated, the variables can also be accessed via names, although this takes up more memory. -
Page 39: Adapter Tab
Configuration via TwinCAT System Manager 4.2 Adapter tab Description Shows the number of the LAN connection and the desktop adapter of the Ethernet channel used. Device name Shows the Windows device name of the Ethernet channel used. MAC address shows the unique MAC address of the Ethernet channel used. IP address Shows the IP address of the Ethernet channel used. -
Page 40: Compatible Devices
Configuration via TwinCAT System Manager 4.2.1 Compatible Devices Click on Compatible Devices for displaying the TwinCAT-compatible Ethernet devices found on your PC. TwinCAT Ethernet protocol installed This control box indicates whether the TwinCAT protocol driver is already installed. Installed usable devices For the fieldbus cards/fieldbus card channels displayed here, - the TwinCAT driver for real-time Ethernet is installed and - the TwinCAT Ethernet protocol is activated. - Page 41 Configuration via TwinCAT System Manager Disable Automatic Windows Updates The advantage that TwinCAT real-time Ethernet uses standard hardware comes with a Attention small disadvantage: Windows knows this standard hardware, but during a Windows Update or during installation of a Service Packs it will try and install the latest drivers that it considers to be the "best"...
-
Page 42: Ethercat Tab
Configuration via TwinCAT System Manager 4.3 EtherCAT tab Net ID Shows the AMS Net ID. Start up to This options field can be used to specify which EtherCAT system state should be activated when the device is switched on: INIT: Initiate PRE-OP: Pre Operation SAFE-OP: Safe Operation OP: Operation. -
Page 43: Statistics Tab
Configuration via TwinCAT System Manager 4.4 Statistics tab Sent Frames Shows the number of EtherCAT frames sent and the number of frames sent per second. Recv Frames Shows the number of EtherCAT frames received and the number of frames received per second. Missed Frames Shows the number of lost EtherCAT frames. -
Page 44: Diagnostics Tab
Configuration via TwinCAT System Manager 4.5 Diagnostics tab State INIT: Initiate PRE-OP: Pre Operation SAFE-OP: Safe Operation OP: Operation. CRC A Cyclic Redundancy Check at the incoming EtherCAT connection. CRC B Cyclic Redundancy Check at the outgoing EtherCAT connection. CRC C Cyclic Redundancy Check at the branch EtherCAT connection (if present). -
Page 45: Appendix
Please contact your Beckhoff branch office or partner company for local support and service on Beckhoff products! The contact addresses for your country can be found in the list of Beckhoff branches and partner companies: www.beckhoff.com. You will also find further documentation for Beckhoff components there.
