Overview Overview Properties The CB1067 is an industrial motherboard in the ATX form factor. It is based on Intel®'s current Coffeelake (Refresh) S-processors of the Core™, Celeron™ and Pentium™ families in the 8 and 9 generation in connection with the Q370-PCH chipset. Using its four SO-DIMM260 slots it can be equipped with up to 128 GB of DDR4-2666 memory.
Plug connector overview The following illustration provides an overview of the plug connections on the CB1067 board. The function of the respective connector can be taken from the table below. The listed page in the manual provides you with further information on this connection.
SVCC. The voltage you choose depends on the setting of the KBPWR jumper. If contacts 1 and 2 are closed, then VCC is applied; if contacts 2 and 3 are closed, then SVCC. Fig. 3: KBPWR jumper Version: 1.0 CB1067...
Pin Name Description FANON3 Fan 4 switched to ground, connected to fan 3 12 V 12 V N/C N/C Pin assignment with FAN4 FAN4 is connected to FAN3 via pin 1. Pins 3 and 4 not connected (N/C). CB1067 Version: 1.0...
CD-In (P1200) In addition to the external jack sockets, there is also an internal 4-pin housing connector (Foxconn HF1104E- P1) on the CB1067 board via which the other audio signals can be made available. Fig. 5: CD-In plug CD-In pin assignment Pin...
Memory SO-DIMM260 (U600/700 and U601/701) On the CB1067 board there are four SO-DIMM260 memory slots for DDR4-2666 RAM. For technical and mechanical reasons, it is possible that certain memory modules cannot be used. Information regarding the recommended memory modules can be obtained from your distributor.
Page 18
DQ26 DQ27 Data line 27 Ground GND GND Ground Not connected CB5 / NC CB4 / NC Not connected Ground GND GND Ground Not connected CB1 / NC CB0 / NC Not connected Ground GND GND Ground Version: 1.0 CB1067...
Page 19
Ground GND GND Ground Data line 33 DQ33 DQ32 Data line 32 Ground GND GND Ground Data strobe 4 - DQS4# DQM4 Data Mask Data strobe 4 + DQS4 GND Ground Ground GND DQ39 Data line 39 CB1067 Version: 1.0...
Page 20
Ground GND GND Ground SMBus Clock SCL SDA SMBus Data I²C power for SPD EEProm VCCSPD SA0 SPD Address 0 3.3 V DRAM Activating Power VPP M_VTT Termination voltage DRAM Activating Power VPP SA1 SPD Address 1 Version: 1.0 CB1067...
ATX Power good PWR_ON -5 V –5 V supply voltage Standby 5 V S VCC VCC 5 V supply voltage 12 V supply voltage 12 V VCC 5 V supply voltage 12 V supply voltage 12 V VCC 5 V supply voltage 3.3 V supply voltage 3.3 V GND Ground CB1067 Version: 1.0...
The board has a 2x13-pin standard pin contact strip for insulation displacement contact technology with a spacing of 2.54 mm, via which the signals for power button, speaker, reset and various status LEDs are provided. This connector is coded for Beckhoff. Fig. 12: System connectors Pin assignment of connector system 1...
Name Description 3.3 V supply voltage 3.3 V GND Ground SMBus Clock SMBCLK SMBDAT SMBus Data SMBus Alarm SMBALERT# S VCC Standby supply 5 V I C-Bus Clock I2CLK I2DAT I C-Bus Data 5 V supply voltage VCC GND Ground CB1067 Version: 1.0...
Pin Name Description VCC 5 V for USB USB# Minus data channel USB USB Plus data channel USB GND1 Ground StdA_SSRX- SuperSpeed Receiver - StdA_SSRX+ SuperSpeed Receiver + GND2 Ground StdA_SSTX- SuperSpeed Transmitter - StdA_SSTX+ SuperSpeed Transmitter + Version: 1.0 CB1067...
5 V for USBx VCC VCC 5 V for USBy Minus data channel USBx USBx- USBy- Minus data channel USBy Plus data channel USBx USBx+ USBy+ Plus data channel USBy Ground GND GND Ground Not connected N/C N/C Not connected CB1067 Version: 1.0...
Name Description Data Carrier Detect DCD DSR Data Set Ready Receive Data RXD RTS Request to Send Transmit Data TXD CTS Clear to Send Data Terminal Ready DTR RI Ring Indicator Ground GND VCC 5 V supply voltage Version: 1.0 CB1067...
Connections 5.17 PCI interfaces (P1300 and P1301) The CB1067 board has two standard PCI slots for expansion cards. Fig. 18: PCI connector NOTE Observe pin assignment In the pin assignment table below, note that for certain signals there are necessary differences between the different PCI connectors on the board.
Page 28
3.3 V supply voltage Address/Data 15 AD15 A44 B44 CBE1# Command, Byte Enable 1 3.3 V supply voltage 3.3 V A45 B45 AD14 Address/Data 14 Address/Data 13 AD13 A46 B46 GND Ground Address/Data 11 AD11 A47 B47 AD12 Address/Data 12 Version: 1.0 CB1067...
Page 29
VCC A59 B59 VCC 5 V supply voltage 5 V supply voltage REQ64 A60 B60 VCC 5 V supply voltage 5 V supply voltage VCC A61 B61 VCC 5 V supply voltage 5 V supply voltage VCC A62 B62 VCC 5 V supply voltage CB1067 Version: 1.0...
Connections 5.18 PCI-Express interfaces x4 (P1305 and P1302) Two PCI-Express x4 expansion card slots are available on the CB1067 board. x1 expansion cards can also be operated in these slots. Fig. 19: PCIe x4 connector Pin assignment of PCI-Express x4 connector Description...
PCI-Express interface x16 (P1402) A slot for PCI-Express x16 cards completes the range of available expansion options on the CB1067 board. This slot can be used for PCIe x16 graphics cards. An x1 or x4 expansion card can also be operated in this slot.
Page 32
Receive Lane 6 + PER6 B43 GND Ground Receive Lane 6 - PER6# B44 GND Ground Ground GND B45 PET7 Transmit Lane 7 + Ground GND B46 PET7# Transmit Lane 7 - Receive Lane 7 + PER7 B47 GND Ground Version: 1.0 CB1067...
Page 33
B78 PET15 Transmit Lane 15 + Ground GND B79 PET15# Transmit Lane 15 - Receive Lane 15 + PER15 B80 GND Ground Receive Lane 15 - PER15# B81 DDAT- Reserved PRSNT Ground GND B82 RSVD Not connected CB1067 Version: 1.0...
2.54 mm. Fig. 21: SPDIF connector Pin assignment of SPDIF connector Description Name Name Description Ground GND SPDIFO SPDIF Out 3.3 V supply voltage 3.3 V VCC Supply voltage 5 V Ground GND SPDIFI SPDIF In Version: 1.0 CB1067...
Hot Plug Detect 2 Ground GND B18 GND Ground 5.22 Audio connections (P1602) Connections for Line-In, Line-Out and microphone are fed out in the form of three jack sockets for 3.5 mm jack plugs. Fig. 23: Audio connectors CB1067 Version: 1.0...
LAN line 0 plus LAN-0# LAN line 0 minus LAN-1 LAN line 1 plus LAN-1# LAN line 1 minus LAN-2 LAN line 2 plus LAN-2# LAN line 2 minus LAN-3 LAN line 3 plus LAN-3# LAN line 3 minus Version: 1.0 CB1067...
5.24 DVI-D (P1500) The CB1067 has two DVI-D connectors in a combination component (Foxconn QH11121-DBDF-4F). You can connect digital DVI or HDMI displays to both connectors. Analog signals are not available on this connector. The CPU graphics support a maximum of three independent displays.
Display Port Lane 3 + Ground GND L#3 Display Port Lane 3 - DP / HDMI HDMI# GND Ground Auxiliary plus AUX GND Ground Auxiliary minus AUX# HPD Hot Plug Detect Ground GND 3.3 V Supply voltage 3.3 V Version: 1.0 CB1067...
This may result in differences between the options actually available and those described below. It should also be noted that the settings shown in the setup menus below are not necessarily the recommended or default settings. Which settings must be selected depends on the application scenario in which the board is operated. CB1067 Version: 1.0...
BIOS settings Main Aptio Setup Utility ─ Copyright (C) 2020 American Megatrends, Inc. Main Advanced Chipset Security Boot Save & Exit ┌─────────────────────────────────────────────────────────────────┬────────────────────────────────┐ │ │Set the Date. Use Tab to │ │ Board Information │switch between Date elements. │ │ Board CB1067 │Default Ranges: │ │ Revision 1 │Year: 2005─2099 │ │ Bios Version 0.13 │Months: 1─12 │ │ │Days: dependent on month │ │ Processor Information │ │ │ Name CoffeeLake DT │ │ │ Type Intel(R) Core(TM) │ │ │ i3─6100TE CPU @ 2.70GHz │ │ │ Speed 2700 MHz │ │ │ ID 0x506E3 │ │ │ Stepping Unknown ├────────────────────────────────┤ │ Number of Processors 2Core(s) / 2Thread(s) │→←: Select Screen │ │ Microcode Revision Not loaded │↑↓: Select Item │ │ GT Info GT2 (0x1912) │Enter: Select │ │ │+/─: Change Opt. │ │ IGFX VBIOS Version N/A │F1: General Help │...
Page 41
None IGFX VBIOS version None IGFX GOP version None Memory RC version None Total Memory None Memory Frequency None PCH information Name None Stepping None ME FW version None System Date Here you can change the system date. System Time Here you can change the system time. CB1067 Version: 1.0...
Submenu see: Serial Port 1 Configuration [} 49] Serial Port 2 Configuration Submenu see: Serial Port 2 Configuration [} 50] Serial Port 3 Configuration Submenu see: Serial Port 3 Configuration [} 51] Serial Port 4 Configuration Submenu see: Serial Port 4 Configuration [} 52] Version: 1.0 CB1067...
Page 49
│ │→←: Select Screen │ │ │↑↓: Select Item │ │ │Enter: Select │ │ │+/─: Change Opt. │ │ │F1: General Help │ │ │F2: Previous Values │ │ │F3: Optimized Defaults │ │ │F4: Save & Reset │ │ │ESC: Exit │ │ │ │ └─────────────────────────────────────────────────────────────────┴────────────────────────────────┘ Version 2.20.1275. Copyright (C) 2020 American Megatrends, Inc. Bios entry Options Serial Port 1 Configuration Serial Port Enabled / Disabled Device Settings None Change Settings Auto / IO=3F8h; IRQ=4;…IO=2E8h; IRQ=3,4,5,6,7,9,10,11,12; Device Mode Normal / High Speed CB1067 Version: 1.0...
Page 50
│ │→←: Select Screen │ │ │↑↓: Select Item │ │ │Enter: Select │ │ │+/─: Change Opt. │ │ │F1: General Help │ │ │F2: Previous Values │ │ │F3: Optimized Defaults │ │ │F4: Save & Reset │ │ │ESC: Exit │ │ │ │ └─────────────────────────────────────────────────────────────────┴────────────────────────────────┘ Version 2.20.1275. Copyright (C) 2020 American Megatrends, Inc. Bios entry Options Serial Port 2 Configuration Serial Port Enabled / Disabled Device Settings None Change Settings Auto / IO=2F8h; IRQ=3;…IO=2E8h; IRQ=3,4,5,6,7,9,10,11,12; Device Mode Normal / High Speed Version: 1.0 CB1067...
Page 51
│ │→←: Select Screen │ │ │↑↓: Select Item │ │ │Enter: Select │ │ │+/─: Change Opt. │ │ │F1: General Help │ │ │F2: Previous Values │ │ │F3: Optimized Defaults │ │ │F4: Save & Reset │ │ │ESC: Exit │ │ │ │ └─────────────────────────────────────────────────────────────────┴────────────────────────────────┘ Version 2.20.1275. Copyright (C) 2020 American Megatrends, Inc. Bios entry Options Serial Port 3 Configuration Serial Port Enabled / Disabled Device Settings None Change Settings Auto / IO=3E8h; IRQ=11;…IO=2E8h; IRQ=3,4,5,6,7,9,10,11,12; Device Mode Normal / High Speed CB1067 Version: 1.0...
Page 52
│ │→←: Select Screen │ │ │↑↓: Select Item │ │ │Enter: Select │ │ │+/─: Change Opt. │ │ │F1: General Help │ │ │F2: Previous Values │ │ │F3: Optimized Defaults │ │ │F4: Save & Reset │ │ │ESC: Exit │ │ │ │ └─────────────────────────────────────────────────────────────────┴────────────────────────────────┘ Version 2.20.1275. Copyright (C) 2020 American Megatrends, Inc. Bios entry Options Serial Port 4 Configuration Serial Port Enabled / Disabled Device Settings None Change Settings Auto / IO=2E8h; IRQ10;…IO=2E8h; IRQ=3,4,5,6,7,9,10,11,12; Device Mode Normal / High Speed Version: 1.0 CB1067...
Page 61
Disabled / 1 M / 2 M / 4 M / 8 M / 16 M / 32 M / 64 M / 128 M PFMMIO 32 bit Resources Padding Disabled / 1 M / 2 M / 4 M / 8 M / 16 M / 32 M / 64 M / 128 M CB1067 Version: 1.0...
│ │ │ └─────────────────────────────────────────────────────────────────┴────────────────────────────────┘ Version 2.20.1275. Copyright (C) 2020 American Megatrends, Inc. Bios entry Options Bootloader version None Firmware version None Mainboard Serial No None Mainboard Prod. Date (Week.Year) None Mainboard BootCount None Mainboard Operation Time None Voltage /Min/Max) None Temperature (Min/Max) None ext. USB port voltage Off in S3-5 / by SCVV int. USB port voltage Off in S3-5 / by SCVV WatchDogTimer mode Normal Mode / Compatibility Mode WDT OSBoot Timeout Disabled / 45 / 60 / ... / 255 seconds Version: 1.0 CB1067...
HDD / SSD SATA Port 0 DevSlp Disabled / Enabled DITO Configuration Disabled / Enabled NOTE Settings on SATA ports 0 - 5 The possible settings on SATA ports 0-5 are identical. Therefore, these are summarized in the illustration. CB1067 Version: 1.0...
Page 66
Smart Response Technology Enabled / Disabled OROM UI Normal Delay 2 / 4 / 6 / 8 secs RST Force Form Disabled / Enabled System acceleration with Intel® Enabled / Disabled Optane™ memory CPU Attached Storage Enabled / Disabled Version: 1.0 CB1067...
Bios entry Options Network Stack Disabled / Enabled NOTE Network Stack Enabled If Network Stack is enabled, additional menu items for displaying and setting the LAN controllers are shown here. To do this, carry out a reset. CB1067 Version: 1.0...
PORT CONFIGURATION MENU NIC Configuration See submenu: --- FEHLENDER LINK --- Flashing LEDs None PORT CONFIGURATION INFORMATION UEFI driver None PBA adapter None Chip type None PCI Device ID None PCI Address None Link status None MAC Address None CB1067 Version: 1.0...
Page 78
│ │F1: General Help │ │ │F2: Previous Values │ │ │F3: Optimized Defaults │ │ │F4: Save & Reset │ │ │ESC: Exit │ │ │ │ └─────────────────────────────────────────────────────────────────┴────────────────────────────────┘ Version 2.20.1275. Copyright (C) 2020 American Megatrends, Inc. Bios entry Options Link Speed Auto Negotiated / 10 Mbps Half / 10 Mbps Full / 100 Mbps Half / 100 Mbps Full Wake On LAN Disabled / Enabled Version: 1.0 CB1067...
Page 86
Disabled / Enabled LTR Lock Disabled / Enabled Extra Options Submenu see: Extra Options [} 87] NOTE PCI Express Configuration The BIOS entries and options on ports 1-3, 9 and 21 are identical. Port 1 is shown as an example Version: 1.0 CB1067...
Page 87
│ Detect Non─Comliance Device [Disabled] │Detect Non─Compliance PCI │ │ Prefetchable Memory 10 │Express Device. If enable, it │ │ Reserved Memory Alignment 1 │will take more time at POST │ │ Prefetchable Memory Alignment 1 │time. │ │ │────────────────────────────────│ │ │→←: Select Screen │ │ │↑↓: Select Item │ │ │Enter: Select │ │ │+/─: Change Opt. │ │ │F1: General Help │ │ │F2: Previous Values │ │ │F3: Optimized Defaults │ │ │F4: Save & Reset │ │ │ESC: Exit │ │ │ │ └─────────────────────────────────────────────────────────────────┴────────────────────────────────┘ Version 2.20.1275. Copyright (C) 2020 American Megatrends, Inc. BIOS entry Options Detect non-compliance device Disabled / Enabled Prefetchable Memory None Reserved Memory Alignment None Prefetchable Memory Alignment None CB1067 Version: 1.0...
Page 88
HD Audio Configuration Aptio Setup Utility - Copyright (C) 2020 American Megatrends, Inc. Chipset ┌─────────────────────────────────────────────────────────────────┬────────────────────────────────┐ │ HD Audio Subsystem Configuration Settings │Control Detection of the │ │ │HD─Audio device. │ │ HD Audio [Enabled] │Disabled = HDA will be │ │ │unconditionally disabled │ │ │Enabled = HDA will be │ │ │unconditionally enabled. │ │ │ │ │ ├────────────────────────────────┤ │ │→←: Select Screen │ │ │↑↓: Select Item │ │ │Enter: Select │ │ │+/─: Change Opt. │ │ │F1: General Help │ │ │F2: Previous Values │ │ │F3: Optimized Defaults │ │ │F4: Save & Reset │ │ │ESC: Exit │ │ │ │ └─────────────────────────────────────────────────────────────────┴────────────────────────────────┘ Version 2.20.1275. Copyright (C) 2020 American Megatrends, Inc. Bios entry Options HD audio subsystem configuration settings HD audio Enabled / Disabled Version: 1.0 CB1067...
Legacy / UEFI / Dual Fixed Boot Order Priorities Boot Option #1-11 Here you can set the order of the boot media to be used. Advanced Fixed Boot Order Parameters Submenu see: Advanced Fixed Boot Order Parameters [} 107] Version: 1.0 CB1067...
Before a planned BIOS update, it is essential to ensure that the BIOS file to be reloaded is really released for exactly this board and for exactly this board version. If an inappropriate file is used, the board will in- evitably not boot afterwards. CB1067 Version: 1.0...
Mechanical drawing Mechanical drawing NOTE Dimensional notation All dimensions in mil (1 mil = 0.0254 mm). Data in square brackets are in mm. PCB: Dimensions Fig. 28: PCB dimensions Version: 1.0 CB1067...
5 to 9 Hz, 3.5 mm amplitude 9 to 500 Hz, 10 m/s², for packed boards Note on impact and vibration resistance The specifications for impact and vibration resistance refer only to the motherboard itself without heat sink, memory module, cabling, etc. Version: 1.0 CB1067...
It is the end customer's responsibility to ensure that the die temperature of the processor does not exceed 100 °C! Continuous overheating can destroy the board! If the temperature exceeds 100 °C, the ambient temperature needs to be reduced. Ensure sufficient air cir- culation if necessary. CB1067 Version: 1.0...
Support and Service Support and Service Beckhoff and their partners around the world offer comprehensive support and service, making available fast and competent assistance with all questions related to Beckhoff products and system solutions. Beckhoff Support Beckhoff Support offers you comprehensive technical assistance, helping you not only with the application of individual Beckhoff products, but also with other, wide-ranging services: •...
Codes are explained in the document "Aptio™ 5.x Status Codes" from American Megatrends®, which is available from the website http://www.ami.com. In addition, the following OEM POST Codes are output: Code Description 87h BIOS-API started 88h PCA9535 started 89h PWRCTRL firmware started CB1067 Version: 1.0...
The resources used are independent of the setup setting. The listed interrupts and their use are given by the AT compatibility. If interrupts are to be available only on the ISA side, they must be reserved by the BIOS setup. Exclusivity on the PCI side is neither given nor possible. Version: 1.0 CB1067...
API access to power supply unit 36-39 Reserved 5C-5D NCT7491 60-6F Reserved for DDR4 70-73 POST Code output 88-89 Slave address defined by BIOS A0-A7 Reserved for DDR4 B0-B3 Power controller (access via BIOS-API) B8-BB Power controller (access via BIOS-API) Version: 1.0 CB1067...
