Assembly/Inflating/Deflation Instruction; Assembly - Advanced Elements STRAITEDGE ANGLER PRO Owner's Manual

Front and Rear Accessory
Frame System
Molded Rubber
Carry Handle
Hard edge bow
for improved
tracking
Bow and Stern Design
The bow and stern have removable ribs of high-grade aluminum. When the chambers are inflated,
these ribs press against the outer cover and form a high performance bow and stern.

3. ASSEMBLY/INFLATING/DEFLATION INSTRUCTION

The StraitEdge
TM

3.1 ASSEMBLY

1. Insert aluminum Bow rib and the Stern rib into the webbing slots on the StraitEdge™ air bags
and webbing slots on the kayak floor, at the bow and stern.
2. Attach air bags to the outer cover by tightening the "air bag compression straps" and buckling
the "air bag buckle". Do this while the air bag is deflated. These are preset at the factory and
may not require any adjustment.
3. Attach the adjustable seat to the StraitEdge™ Angler side tubes by fastening the buckles and
clipping the steel snap hooks to the d-rings behind the seating area.
AirFrame PRO
Drop-Stitch Floor
StraitEdge
TM
System
Kayak has a rigid frame in the bow and stern that enhances its performance.
StraitEdge Angler PRO Inflatable Kayak Owner's Manual
TM
Front and Rear Bungee
Deck Lacing
Seat
TM
Paddle Holder
Self Bailing Ports
Removable Tracking
Spring
TM
Stainless Steel D-Rings for Drift
Anchor and Stringer Attachment
Fin
Valve
7
