- Page 1 I N F L A T A B L E K A Y A K 1 Person Inflatable Kayak Owner's Manual MODEL AE1006 IMPORTANT! BEFORE PROCEEDING READ THIS MANUAL CAREFULLY Save these instructions for future reference ADVANCED ELEMENTS, INC. 2005...
-
Page 2: Table Of Contents
OWNER'S INFORMATION PACKET StraitEdge I N F L A T A B L E K A Y A K 1 Person Inflatable Kayak Owner's Manual MODEL AE1006 CONTENTS 1. CAUTION - SAFETY WARNING 2. ASSEMBLY / INFLATING INSTRUCTIONS 3. GUIDELINES FOR USAGE 4. -
Page 3: Caution - Safety Warning
· READ OWNER'S INFORMATION PACKET PRIOR TO USING THIS PRODUCT. THE USER OF THIS PRODUCT ACKNOWLEDGES BOTH AN UNDERSTANDING AND AN ASSUMPTION OF THE RISK INVOLVED IN PADDLESPORTS. ADVANCED ELEMENTS INC. TOLL FREE 866-262-9076 Please read this entire manual for additional safety information. Please pay close attention to items marked Important, Caution, Warning, Never, and Always. -
Page 4: Assembly / Inflating Instructions
Assembly / Inflating Instructions The illustration below shows the general assembly of the kayak, with optional thigh straps (sold separately).. Your kayak comes from the factory pre-assembled. The only assembly you should need to do is attach the adjustable seat. The StraitEdge Kayak has a rigid frame in the bow and stern that enhances its performance. -
Page 5: Inflating Instructions
To begin inflating your kayak, you will need a Bellows Foot Pump (FAQ) or a Double Action Hand Pump (FAQ) and your Valve Adaptor (FAQ). The Valve Adaptor can be located in the seat pocket with the repair kit. Never use compressors, CO2 or compressed air as they may damage you kayak. - Page 6 VALVE CHECK VALVE CAP BODY SMALL CAP INSERT “BOSTON PUMP ADAPTOR” SMALL CAP ADVANCED ELEMENTS, INC. (FLOOR) PUMP ADAPTORS fig. 4 (PUMP HOSE) (BOSTON) 4. Locate Chambers 5 and 6. Inflate Chambers 5 and 6 until firm (1.0 PSI). 5. Make sure all valves are closed tightly and properly. Check to be sure the cap tether is not interfering with the valve seating on all chambers.
-
Page 7: Guidelines For Usage
To use as self-bailing: The StraitEdge can be used as both a self-bailing and non self-bailing kayak. Most self- bailing inflatable kayaks are designed for paddling white water only. They typically have quite a bit of rocker to allow quick turning and other maneuvers. By opening the drain ports you will allow water or waves that spills into the kayak to drain out through the bottom. -
Page 8: Proper Care And Storage
Your kayak is designed to be paddled with a double bladed kayak paddle. Paddle with short and even strokes. Keep the blade close to the kayak and the paddle almost vertical. Pull with your lower hand and push with your upper hand. To reduce the amount of swaying at the front of the kayak, ease off on the force of your stroke. -
Page 9: Repairs
Folding instructions to store your kayak: 1. Completely deflate all air chambers (FAQ) and thoroughly dry kayak and remove the seat. 2. Fold in half, down the center, lengthwise. 3. Fold into 3 equal sections. 4. Place into duffel bag. 5. -
Page 10: Frequently Asked Questions (Faq)
To repair pinholes: 1.Inflate the PVC tube. Locate the pinhole by sponging soapy water over the tube until you see air bubbles. Mark the location of the pinhole. 2. Deflate the tube and dry the affected area. Apply a drop of glue to the pinhole 3. -
Page 11: Limited Warranty
Once an authorization number is obtained, the purchaser must ship the product, POSTAGE PREPAID, to Advanced Elements, Inc for repair. Do not ship to P.O. Box address as it may be sent back. This warranty does NOT cover: Products used for rental, for hire or in professionally guided tours and other uses not considered normal recreational purposes;... - Page 12 Toll Free 866-262-9076 WARRANTY REGISTRATION CARD PLEASE COMPLETE THE OTHER SIDE OF THIS CARD AND RETURN TO: Mail to: Advanced Elements, Inc. P.O. Box 5128, Concord, CA 94524 Attn: warranty department.
