Assembly/Inflating/Deflation Instruction; Assembly; Understanding Your Valves - Advanced Elements ATTACK PRO Owner's Manual

Adjustable Foot Braces
Molded Rubber
Handle

3. ASSEMBLY/INFLATING/DEFLATION INSTRUCTION

The Attack™ PRO Kayak has 12" bow and stern rocker and a 35" beam that enhances its
performance.

3.1 ASSEMBLY

Your kayak comes from the factory pre-assembled. The only assembly you should need to do is
attach the adjustable seat, foot pegs, and thigh straps. The thigh straps clip to the steel d-rings
located towards the front of the kayak, in the crease between the floor and the main tubes, and
right behind the seat located on the side walls of the main tubes. The thigh straps should curve
inward with the thicker, or broader, end of the thigh strap closest to your body. Follow the
instructions and figures on pages 9 & 10 for installing the foot pegs.

3.2 UNDERSTANDING YOUR VALVES

Advanced Elements Attack™ PRO Kayak uses the following valves. The 2-way military valve
has the function and durability of other military type valves and is compatible with most
standard pumps. The following figures will have details on how to operate the valves.
TO INFLATE: use finger to push in center stem, rotate ¼ turn, and allow stem to spring up into
the up/outward position.
TO DEFLATE: Use finger to push in center stem and rotate ¼ turn to lock stem down/inward.
Thigh Straps
Drop-Stitch Floor
12" Bow and
Tarpaulin Hull
Stern Rocker
Attack
TM
Self-Bailing Covered
High-Back
Adjustable Seat
Durable PVC
Material
Pro Inflatable Kayak Owner's Manual
Cargo Bay
2-Way Military
Full-Time Self Bailing
Valves
7
