  • Page 1 For professionals Installation instructions This guide is available in digital format at: www.stuv.com Find us also on: April 2023 P-10.3 APF 137 242026 > ...
  • Page 2 Any changes made to the appliance can be dangerous. In addition, the appliance will no longer be covered by its warranty. We recommend that you read this manual before carrying out the installation. Stûv P-10.3 - installation [en] - 04/23 SN 242026 - ...

  • Page 4: Table Of Contents

    Powering up the Stûv P-10 Installing the device on the home Wi-Fi network Setting up the device on the home WiFi network Controlling the Stûv P-10 with a smartphone Stûv P-10.3 - installation [en] - 04/23 SN 242026 - ...
  • Page 5 Flux calibration (mandatory after each transport) Flue gas calibration Filling the pellet hopper Checks before the first lighting of the appliance Lighting the Stûv P-10 Once the appliance is lit... ACCEPTANCE OF WORKS CONTACTS Stûv P-10.3 - installation [en] - 04/23 SN 242026 - ...

  • Page 6: Presentation Of The Product

    6 Pa Requirements relating to the electrical power supply Voltage 230 V Frequency 50 Hz Electric power consumption on ignition 1000 W Electrical power consumption under normal operation 40 W Stûv P-10.3 - installation [en] - 04/23 SN 242026 - ...
  • Page 7 Maximum length of air supply duct Maximum number of 90° bends Minimum cross-section of combustion air supply from outside 30 cm² (when the fireplace is not connected directly to the outside air) Stûv P-10.3 - installation [en] - 04/23 SN 242026 - ...
  • Page 8 Belgique P = particle, VOCs = volatile organic compounds, CO = carbon monoxide, NO = nitrogen oxides. (**) Required only if the correction factor F(2) or F(3) is applied. Stûv P-10.3 - installation [en] - 04/23 SN 242026 - ...

  • Page 9: Stûv P-10 Marking

    50Hz Minimum clearance distance from combustible materials ENERG енергия - ενέργεια P-10.3 10cm 100cm 100cm ENERGIA - ЕНЕРГИЯ - ΕΝΕΡΓΕΙΑ - ENERGIJA - ENERGY - ENERGIE - ENERGI 2015/1186 Stûv P-10.3 - installation [en] - 04/23 SN 242026 - ...

  • Page 10: Materials And Main Components

    (rated or trained in the safe use of the power) and the radiation from the appliance. glass can be high. Stûv P-10.3 - installation [en] - 04/23 SN 242026 - ...

  • Page 11: Fireplace Dimensions

    Fireplace dimensions wood and “to be sheet metal version trimmed” version 1400 Ø 60 Ø 80 Ø 60 wood and “to be trimmed” version sheet metal version Stûv P-10.3 - installation [en] - 04/23 SN 242026 - ...

  • Page 12: Overview Of The Stove Components

    R. Pellet hopper S. Electronic card T. Ashpan U. Reloading hatch V. Front hood with dust channel *Facings are available in two versions. The illustration shows one side of each finish. Stûv P-10.3 - installation [en] - 04/23 SN 242026 - ...

  • Page 13: Facing Trim Kit - Sizes Of Trim Parts (Option)

    The trim must not exceed; - in the case of the door: 30kg - in the case of the side facing panels: 25kg 45° Visible side Stûv P-10.3 - installation [en] - 04/23 SN 242026 - ...

  • Page 14: Preparation Of The Area

    Certain local regulations make these Careful not to crush the flue. measures obligatory. Local and/or national regulations take precedence over our recommendations.. Stûv P-10.3 - installation [en] - 04/23 SN 242026 - ...

  • Page 15: Electrical Power Supply

    If the stove is situated in a bell-shaped area (ex : a former hearth), this space must be ventilated to prevent "heat traps". Allow a clearance of at least 10 cm above the device. 100cm Stûv P-10.3 - installation [en] - 04/23 SN 242026 - ...

  • Page 16: Smoke Flue

    EN 13384-1 or -2 and its annexes in order to guarantee that the appliance does not operate in a condensation regime. This calculation must include the power range targeted by the appliance. Check that your flue pipe complies with standard EN 1853-1, which characterises metal flue pipes. Stûv P-10.3 - installation [en] - 04/23 SN 242026 - ...

  • Page 17: Connection To The Smoke Flue

    [diagram 2/a] rather than the smoke [diagram 2/b]. Stûv P-10.3 - installation [en] - 04/23 SN 242026 - ...
  • Page 18 > Install a 90° tee-piece with plug [A]. > The connection duct may be single- or double-walled [B]. > Fit flexible ducting inside the chimney to tube it [C]. Stûv P-10.3 - installation [en] - 04/23 SN 242026 - ...
  • Page 19 > Use concentric flues [D]. > Install the "ceiling offtake" kit Poujoulat: : KFRL PGI / Modinox: 2PLAADA780 > Line the chimney with a flexible flue up to the concentric cap plate [F]. Stûv P-10.3 - installation [en] - 04/23 SN 242026 - ...

  • Page 20: Circulation Of Convection Air

    To operate correctly, place the remote control in the room where the Stûv P-10 is located but not too close to the stove or too exposed to sunlight. Stûv P-10.3 - installation [en] - 04/23 SN 242026 - ...

  • Page 21: Installation

    > Disassemble the pallet, starting from the top. > Unhook each side with a crowbar. > Unscrew the three screws that are holding the stove on the pallet [diagrams 3, 4 and 5]. Stûv P-10.3 - installation [en] - 04/23 SN 242026 - ...
  • Page 22 It is imperative to tighten the 4 screws on the stove to ensure a good seal! Tighten the 4 screws on the stove to ensure a good seal! [diagrams 8 and 11]. Stûv P-10.3 - installation [en] - 04/23 SN 242026 - ...

  • Page 23: Unpacking

    [Diagram 6]. Check the contents of the box (see chapter “checking the contents of the combustion chamber"). > Put protection on the trolley (e.g. cover, cardboard, etc.). Stûv P-10.3 - installation [en] - 04/23 SN 242026 - ...
  • Page 24 [diagram 15]. > Remove and take away the upper part of the stove. Caution! Each part is heavy, so make sure that there are two persons to hold these assemblies. Stûv P-10.3 - installation [en] - 04/23 SN 242026 - ...

  • Page 25: Positioning Of The Stove

    (this will have an impact on the different connections). min 70 mm Caution! Do not go below the minimum height from the ground to the bottom of the Stûv P-10.3 - installation [en] - 04/23 unit (feet screwed to the maximum). SN 242026 - ...

  • Page 26: Checking The Contents Of The Combustion Chamber

    NOTE: After one minute, the remote control will display a «communication alarm» message, as it is not connected to the device. Ignore this message, and continue with the installation. Stûv P-10.3 - installation [en] - 04/23 SN 242026 - ...

  • Page 27: Connection With Outside Air (Option)

    If you are not connecting your stove to the outside air, provide for an air intake with a cross-section greater than 30 cm² in the room where the stove is installed. Stûv P-10.3 - installation [en] - 04/23 SN 242026 - ...

  • Page 28: Connection To The Smoke Flue

    The grooved portions represent the underside of the ring [diagram 3]. > Replace the lantern facings. > Fit the door of the combustion Underside chamber. Stûv P-10.3 - installation [en] - 04/23 SN 242026 - ...
  • Page 29 Final assembly Stûv P-10.3 - installation [en] - 04/23 SN 242026 - ...
  • Page 30 > The screws fixing the side facing panels must be fully tightened to prevent vibration noise [diagrams 3 & 4] > Repeat steps 1 to 4 for the right trim [figure 5]. Stûv P-10.3 - installation [en] - 04/23 SN 242026 - ...
  • Page 31 Final assembly - positioning the lower trims on the wooden version > Repeat steps 1 to 4 for the right trim [figure 5]. Stûv P-10.3 - installation [en] - 04/23 SN 242026 - ...
  • Page 32 > Tighten the nut to lock the setting of the shelf [diagram 24 detail 3]. Once the facings have been correctly adjusted, fix them using an M5X10 torx head screw. Stûv P-10.3 - installation [en] - 04/23 SN 242026 - ...

  • Page 33: Final Assembly - Fitting The Trim Facings

    [Figure 2]. > Fit the rear vertical profile [Figure 3] and tighten the serews through the slots provided for this purpose [Figures 4 & 5]. Stûv P-10.3 - installation [en] - 04/23 SN 242026 - ...
  • Page 34 [Figure 8]. > Fix the metal panel and the panel using the wood screws [Figures 9 & 10]. Stûv P-10.3 - installation [en] - 04/23 SN 242026 - ...
  • Page 35 > Fit the templates onto the metal panel which is fixed onto the door panel [Figures 13 & 17]. > Align the edge of the template with the fold in the metal panel [Figure 14]. Stûv P-10.3 - installation [en] - 04/23 SN 242026 - ...
  • Page 36 [Figure 20]. > Fix the metal panel and the panel using the wood screws [Figure 21]. > Unscrew the fitting template [diagram 22]. Stûv P-10.3 - installation [en] - 04/23 SN 242026 - ...
  • Page 37 [Figure 27]. > Tighten the screws [Figure 28]. > Remove the template [Figure 29]. > Repeat the operation for the upper side. Stûv P-10.3 - installation [en] - 04/23 SN 242026 - ...
  • Page 38 > Tighten both upper screws at the rear of the facings [Figure 34]. > Fit the shelves onto the appliance, starting with the front [Figures 35 & 36]. Stûv P-10.3 - installation [en] - 04/23 SN 242026 - ...
  • Page 39 > Fit the door onto its hinges [Figure 41]. > Fit the shaft for the door closing strut onto the appliance’s framework [Figure 42]. > Fit the strut onto the shaft [Figure 43]. Stûv P-10.3 - installation [en] - 04/23 SN 242026 - ...
  • Page 40 > If the hollow gasket is not equal between the shelf and the top of the door, it is possible to play with the height position of the support bearing [Figures 50 & 51]. Stûv P-10.3 - installation [en] - 04/23 SN 242026 - ...
  • Page 41 54]. > Loosen the bearing and modify its position before tightening the bearing [Figures 55 & 56]. > Replace the support bearing onto the appliance [Figures 57 & 58]/ Stûv P-10.3 - installation [en] - 04/23 SN 242026 - ...

  • Page 42: Starting Up

    Min. 1 heure to the mains [diagram 1]. > Turn on the remote control by pressing the small button above the charging port [Figure 2]. Stûv P-10.3 - installation [en] - 04/23 SN 242026 - ...
  • Page 43 C° control pairing procedure. 2]. When this mode is active, the connection by pressing "OK!" on the Simplified Control Display screen remote control display [Figure 3]. will flash. Stûv P-10.3 - installation [en] - 04/23 SN 242026 - ...
  • Page 44 Check the power supply to the communication board Check the correct connection of the cable between the communication board and the control board * Please refer to the networking procedure on the next page. Stûv P-10.3 - installation [en] - 04/23...

  • Page 45: Installing The Device On The Home Wi-Fi Network

    • The assignment of IP addresses on the network must be managed automatically by DHCP. The stove can be connected to • Ports 1883 and 443 must be open to the outside. the Wi-Fi home network (*) Stûv P-10.3 - installation [en] - 04/23 SN 242026 - ...
  • Page 46 If you are not familiar with the above parameters or if they are not (or cannot be made to be) compliant with the prerequisites, it is imperative to configure the installation in wired mode! DETAIL OF THE ANTENNA INSTALLATION Stûv P-10.3 - installation [en] - 04/23 SN 242026 - ...

  • Page 47: Setting Up The Device On The Home Wifi Network

    The stove will then be set up on the home network. Stûv P-10.3 - installation [en] - 04/23 SN 242026 - ... * Stûv cannot be held responsible for compatibility with the Wi-Fi network or the stability of the Wi-Fi network...
  • Page 48 (see Summary p.45). * Stûv cannot be held responsible for the compatibility with the Wi-Fi network or the stability of the Wi-Fi network. Stûv P-10.3 - installation [en] - 04/23 SN 242026 - ...
  • Page 49 A BLINKING blue indicates a cable connection problem and/or a network access right problem. In this case, please check these 2 points and repeat the above operation. Stûv P-10.3 - installation [en] - 04/23 SN 242026 - ...
  • Page 50 > If you wish to disconnect the Ethernet cable, remove the right side panel [figure 2] to gain access to the unit's network card. > Disconnect it as shown [figure 3]. Stûv P-10.3 - installation [en] - 04/23 SN 242026 - ...

  • Page 51: Controlling The Stûv P-10 With A Smartphone

    > Follow the rest of the connection steps on the application. The application is ready for use as soon Veuillez scanner as the room temperature is displayed le code barre du poêle on the screen. Stûv P-10.3 - installation [en] - 04/23 SN 242026 - ...

  • Page 52: Starting Up

    > After checking to make sure that the Min. 1 hour remote control is working properly, give it to the user in its box. Stûv P-10.3 - installation [en] - 04/23 SN 242026 - ...

  • Page 53: Flux Calibration (Mandatory After Each Transport)

    Wait for the remote control to display the home screen. Once it does, the process is complete [figure > Connect the external air inlet [figure 7]. WEDNESDAY 01/07/15 12:00 20.0°C NORMAL Stûv P-10.3 - installation [en] - 04/23 SN 242026 - ...

  • Page 54: Flue Gas Calibration

    > From this point on, the unit will reconfigure the temperature sensor. Wait until the remote control displays the home screen. Once it does, the operation is complete [Figure 5]. Stûv P-10.3 - installation [en] - 04/23 SN 242026 - ...

  • Page 55: Filling The Pellet Hopper

    [diagrams 1, 2 and 3]. > Remove the vermiculite ring [diagram > Remove the flame modeller [diagram > Look to see that the grille is positioned correctly [diagrams 6 & 7]. Stûv P-10.3 - installation [en] - 04/23 SN 242026 - ...
  • Page 56 [diagrams 8, 9 et 10]. Underside > Reposition the various parts correctly. > Check that the ashpan, the hopper hatch and the door of the combustion chamber are securely locked before lighting. Stûv P-10.3 - installation [en] - 04/23 SN 242026 - ...

  • Page 57: Lighting The Stûv

    For more details on the operation of the appliance, please refer to the user manual supplied in addition to these installation instructions. For any questions or comments, please do not hesitate to contact our customer service department via email: info@stuv. Stûv P-10.3 - installation [en] - 04/23...

  • Page 58: Acceptance Of Works

    ACCEPTANCE OF WORKS THIS DOCUMENT CERTIFIES ACCEPTANCE OF THE WORK . THIS FORM IS TO BE COMPLETED BY THE INSTALLER IN 2 COPIES, 1 FOR THE INSTALLER, 1 FOR THE USER. THE PURCHASER SURNAME ....................FIRST NAME .................... ADDRESS WHERE WORKS WERE CARRIED OUT ........POST CODE ....................

  • Page 59: Contacts

    Importer for Sweden Sopruse 145 – 13417 Tallinn Eldoform Sverige AB T +372 56 249 004 - www.tulering.ee Slipgatan 2 – 117 39 Stockholm T 0707 883 53 – www.eldoform.se Stûv P-10.3 - installation [en] - 04/23 SN 242026 - ...
  • Page 60 This document is available in several languages : accept responsibility for any errors that may have been made. Contact your distributor or visit www.stuv.com Editor: Gérard Pitance – rue Jules Borbouse 4 – 5170 Bois-de-Villers – Belgium 93109200 - installation instructions - Stûv P-10.3...
