  • Page 1 For professionals Installation instructions This guide is available in digital format at: www.stuv.com Find us also on: March 2020 P-10.2 APF 134 203951 > ...
  • Page 2 Any changes made to the appliance can be dangerous. In addition, the appliance will no longer be covered by its warranty. We recommend that you read this manual before carrying out the installation. Stûv P-10.2 - installation [en] - 03/20 SN 203951 - ...
  • Page 4: Table Of Contents

    Powering up the Stûv P-10 Pairing the remote control Setting up the device on the home WiFi network Controlling the Stûv P-10 with a smartphone Flux calibration (mandatory after each transport) Checks before the first lighting of the appliance Lighting the Stûv P-10 Once the appliance is lit...
  • Page 5: Presentation Of The Product

    2.8 g/s Recommended draught at maximum power 6 Pa Recommended draught at minimum power (P1) 3 Pa Minimum draught at the output of the appliance for flue calculation. 0 Pa Stûv P-10.2 - installation [en] - 03/20 SN 203951 - ...
  • Page 6: Stûv P-10 Marking

    > Cast steel for the structural elements of the burner > Aluminium for the smoke extraction flue > HDPE for the Pellet hopper Stûv P-10.2 - installation [en] - 03/20 SN 203951 - ...
  • Page 7: Fireplace Dimensions

    Fireplace dimensions wood and “to be sheet metal version trimmed” version 1400 Ø 60 Ø 80 Ø 60 wood and “to be trimmed” version sheet metal version Stûv P-10.2 - installation [en] - 03/20 SN 203951 - ...
  • Page 8: Overview Of The Stove Components

    R. Pellet hopper S. Electronic card T. Ashpan U. Reloading hatch V. Front hood with dust channel *Facings are available in two versions. The illustration shows one side of each finish. Stûv P-10.2 - installation [en] - 03/20 SN 203951 - ...
  • Page 9: Facing Trim Kit - Sizes Of Trim Parts (Option)

    The trim must not exceed; - in the case of the door: 30kg - in the case of the side facing panels: 25kg 45° Visible side Stûv P-10.2 - installation [en] - 03/20 SN 203951 - ...
  • Page 10: Preparation Of The Area

    (whether it is connected to The ideal solution the stove or not) The Stûv P-10 is designed to be ... will be protected on the outside connected directly to an outside air by a grill the free passage section of...
  • Page 11: Electrical Power Supply

    If the stove is situated in a bell-shaped area (ex : a former hearth), this space must be ventilated to prevent "heat traps". Allow a clearance of at least 10 cm above the device. 100cm Stûv P-10.2 - installation [en] - 03/20 SN 203951 - ...
  • Page 12: Smoke Flue

    2m with a minimum slope of As the Stûv P-10 is a highly efficient stove, the smoke flue must be of Maximum number of elbow joints: good quality. The flue must also be as >...
  • Page 13: Connection To The Smoke Flue

    [diagram 2/a] rather than the smoke [diagram 2/b]. Stûv P-10.2 - installation [en] - 03/20 SN 203951 - ...
  • Page 14 > Install a 90° tee-piece with plug [A]. > The connection duct may be single- or double-walled [B]. > Fit flexible ducting inside the chimney to tube it [C]. Stûv P-10.2 - installation [en] - 03/20 SN 203951 - ...
  • Page 15 > Use concentric flues [D]. > Install the "ceiling offtake" kit Poujoulat: : KFRL PGI / Modinox: 2PLAADA780 > Line the chimney with a flexible flue up to the concentric cap plate [F]. Stûv P-10.2 - installation [en] - 03/20 SN 203951 - ...
  • Page 16: Circulation Of Convection Air

    To operate correctly, place the remote control in the room where the Stûv P-10 is located but not too close to the stove or too exposed to sunlight. Stûv P-10.2 - installation [en] - 03/20...
  • Page 17: Installation

    > Disassemble the pallet, starting from the top. > Unhook each side with a crowbar. > Unscrew the three screws that are holding the stove on the pallet [ diagrams 3, 4 and 5]. Stûv P-10.2 - installation [en] - 03/20 SN 203951 - ...
  • Page 18: Transporting The Stove

    For any subsequent transport, replace at least 2 of the 3 screws or move the top and bottom parts separately. > Bring the Stûv P-10 close to its final location. Stûv P-10.2 - installation [en] - 03/20 SN 203951 - ...
  • Page 19 [diagram 15]. > Remove and take away the upper part of the stove. Caution! Each part is heavy, so make sure that there are two persons to hold these assemblies. Stûv P-10.2 - installation [en] - 03/20 SN 203951 - ...
  • Page 20: Positioning Of The Stove

    (this will have an impact on the different connections). min 70 mm Caution! Do not go below the minimum height from the ground to the bottom of the unit (feet screwed to the maximum). Stûv P-10.2 - installation [en] - 03/20 SN 203951 - ...
  • Page 21: Checking The Contents Of The Combustion Chamber

    > instructions for installing and using the device. A box containing: > the remote control (2.1) > the wall mount for the remote control (2.2) > The charger for the remote control (2.3) Stûv P-10.2 - installation [en] - 03/20 SN 203951 - ...
  • Page 22: Connection With Outside Air (Option)

    If you are not connecting your stove to the outside air, provide for an air intake with a cross-section greater than 30 cm² in the room where the stove is installed. Stûv P-10.2 - installation [en] - 03/20 SN 203951 - ...
  • Page 23: Connection To The Smoke Flue

    The grooved portions represent the underside of the ring [diagram 3]. > Replace the lantern facings. > Fit the door of the combustion Underside chamber. Stûv P-10.2 - installation [en] - 03/20 SN 203951 - ...
  • Page 24 Final assembly Stûv P-10.2 - installation [en] - 03/20 SN 203951 - ...
  • Page 25 > The screws fixing the side facing panels must be fully tightened to prevent vibration noise [diagrams 3 & 4] > Repeat steps 1 to 4 for the right trim [figure 5]. Stûv P-10.2 - installation [en] - 03/20 SN 203951 - ...
  • Page 26 Final assembly - positioning the lower trims on the wooden version > Repeat steps 1 to 4 for the right trim [figure 5]. Stûv P-10.2 - installation [en] - 03/20 SN 203951 - ...
  • Page 27 > Tighten the nut to lock the setting of the shelf [diagram 24 detail 3]. Once the facings have been correctly adjusted, fix them using an M5X10 torx head screw. Stûv P-10.2 - installation [en] - 03/20 SN 203951 - ...
  • Page 28: Final Assembly - Fitting The Trim Facings

    [Figure 2]. > Fit the rear vertical profile [Figure 3] and tighten the serews through the slots provided for this purpose [Figures 4 & 5]. Stûv P-10.2 - installation [en] - 03/20 SN 203951 - ...
  • Page 29 [Figure 8]. > Fix the metal panel and the panel using the wood screws [Figures 9 & 10]. Stûv P-10.2 - installation [en] - 03/20 SN 203951 - ...
  • Page 30 > Fit the templates onto the metal panel which is fixed onto the door panel [Figures 13 & 17]. > Align the edge of the template with the fold in the metal panel [Figure 14]. Stûv P-10.2 - installation [en] - 03/20 SN 203951 - ...
  • Page 31 [Figure 20]. > Fix the metal panel and the panel using the wood screws [Figure 21]. > Unscrew the fitting template [diagram 22]. Stûv P-10.2 - installation [en] - 03/20 SN 203951 - ...
  • Page 32 [Figure 27]. > Tighten the screws [Figure 28]. > Remove the template [Figure 29]. > Repeat the operation for the upper side. Stûv P-10.2 - installation [en] - 03/20 SN 203951 - ...
  • Page 33 > Tighten both upper screws at the rear of the facings [Figure 34]. > Fit the shelves onto the appliance, starting with the front [Figures 35 & 36]. Stûv P-10.2 - installation [en] - 03/20 SN 203951 - ...
  • Page 34 > Fit the door onto its hinges [Figure 41]. > Fit the shaft for the door closing strut onto the appliance’s framework [Figure 42]. > Fit the strut onto the shaft [Figure 43]. Stûv P-10.2 - installation [en] - 03/20 SN 203951 - ...
  • Page 35 > If the hollow gasket is not equal between the shelf and the top of the door, it is possible to play with the height position of the support bearing [Figures 50 & 51]. Stûv P-10.2 - installation [en] - 03/20 SN 203951 - ...
  • Page 36 54]. > Loosen the bearing and modify its position before tightening the bearing [Figures 55 & 56]. > Replace the support bearing onto the appliance [Figures 57 & 58]/ Stûv P-10.2 - installation [en] - 03/20 SN 203951 - ...
  • Page 37: Starting Up

    Powering up the Stûv P-10 > Connect the Stûv P-10. > Ensure the plug is fully pushed in. Stûv P-10.2 - installation [en] - 03/20 SN 203951 - ...
  • Page 38: Pairing The Remote Control

    > A message shows that a figure 1. The light should flash connection has been successfully purple. established [figure 5]. > On the home screen of the un-paired remote control, press Stûv P-10.2 - installation [en] - 03/20 SN 203951 - ...
  • Page 39: Setting Up The Device On The Home Wifi Network

    Note: Some special characters and punctuation marks in the Wi-Fi network name (SSID) can cause connection problems. Note: the Stûv P-10 is only compatible with Wi-Fi networks using a frequency of 2.4 GHz. Adjust the modem router if necessary. The stove will then be set up on the http://192.168.100.1...
  • Page 40: Controlling The Stûv P-10 With A Smartphone

    [figure 2]. P-10 P-10 P-10 Please name your Stûv P-10 to identify it To prevent any user from being able to If you forgot your PIN code, an email in the application. You can use up to control your stove you need to configure...
  • Page 41: Flux Calibration (Mandatory After Each Transport)

    Wait for the remote control to display the home screen. Once it does, the process is complete [figure > Connect the external air inlet [figure 7]. WEDNESDAY 01/07/15 12:00 20.0°C NORMAL Stûv P-10.2 - installation [en] - 03/20 SN 203951 - ...
  • Page 42: Checks Before The First Lighting Of The Appliance

    [diagrams 1, 2 and 3]. > Remove the vermiculite ring [diagram 4]. > Remove the flame modeller [diagram 5]. > Look to see that the grille is positioned correctly [diagrams 6 & Stûv P-10.2 - installation [en] - 03/20 SN 203951 - ...
  • Page 43 [diagrams 8, 9 et 10]. Underside > Reposition the various parts correctly. > Check that the ashpan, the hopper hatch and the door of the combustion chamber are securely locked before lighting. Stûv P-10.2 - installation [en] - 03/20 SN 203951 - ...
  • Page 44: Lighting The Stûv

    For more details on the operation of the appliance, please refer to the user manual supplied in addition to these installation instructions. For any questions or comments, please do not hesitate to contact our customer service department via email: info@stuv. Stûv P-10.2 - installation [en] - 03/20...
  • Page 46: Acceptance Of Works

    ACCEPTANCE OF WORKS THIS DOCUMENT CERTIFIES ACCEPTANCE OF THE WORK . THIS FORM IS TO BE COMPLETED BY THE INSTALLER IN 2 COPIES, 1 FOR THE INSTALLER, 1 FOR THE USER. THE PURCHASER SURNAME ....................FIRST NAME .................... ADDRESS WHERE WORKS WERE CARRIED OUT ........POST CODE ....................
  • Page 47: Contacts

    Importer for Sweden Sopruse 145 – 13417 Tallinn Eldoform Sverige AB T +372 56 249 004 - www.tulering.ee Slipgatan 2 – 117 39 Stockholm T 0707 883 53 – www.eldoform.se Stûv P-10.2 - installation [en] - 03/20 SN 203951 - ...
  • Page 48 This document is available in several languages : accept responsibility for any errors that may have been made. Contact your distributor or visit www.stuv.com Editor: Gérard Pitance – rue Jules Borbouse 4 – 5170 Bois-de-Villers – Belgium 9310XXXX - installation instructions - Stûv P-10.2...
