Initial Inspection; Initial Setup; Electrical Interface - MOXTEK X-ray Sources Operation Manual

Initial Inspection

TUB0020X-W08
Molex 12 pin Picoblade connector # 53398-1271*
Cable – USB Type A-B 2.0*
12V power supply*

Initial Setup

Ensure proper ground connection to the shell.
Ensure all pinouts are correct.
Confirm everything is powered off when connecting to source.
If using the adapter board, proceeed to software section.

Electrical Interface

The Samtec 10-pin FLE-105-01-G-DV connector is not used. This is for Moxtek use only. See Figure 3 below.
The Moxtek uses a Molex Picoblade connector # 53398-1271 (12-pins) is used to interface with MOX140G.
*Pin 12 should be powered with the same voltage used on the host's I2C pull-up. If +3.3V I2C bus, is used +3.3V
should be used for pin 12. If +5V I2C bus is used, +5V should be used for pin 12.
MOXTEK
®
Components
Pin # Name
1 VDC
2 VDC
3 VDC
4 SCL
5 SDA
6 ENABLE
7 GND
8 GND
9 GND
10 GND
11 +5V
12 +3.3 OR +5V
Please Inspect Contents
*Optional items to purchase
Table 3: Components, Quantities
Table 4: Pins Defined
Description
Main power, 12V +/- .5V
Main power, 12V +/- .5V
Main power, 12V +/- .5V
I2C clock line
I2C data line
+5V to enable x-rays
Ground return
Ground return
Ground return
Ground return
Aux power
I2C power*
3
Quantity Required
1
1
1
1
Subject to technical change without notice
TUB-MAN-1022 Rev A
