Suggested Settings and Operating Parameters

Suggested Settings and Operation Parameters

• The source should be run between 10KV and 140KV.
• No beam current should be applied, unless the source is at 50KV or higher.
• 20uA should be the maximum current setting when below 100KV.
• If the source has been sitting overnight, or for about 24 hours, set the "Std Ramp" to 50 for the initial start-up.
After it has been running, the "Std Ramp" can be set to 140.
• At full output, the source should be set to 140KV and 50uA. 50uA should be the maximum current setting for the
source at any KV level.
• Active cooling is recommended to keep the temperature down on the source.
