TransAct Ithaca 152 Specifications page 2

PRINTING CHARACTERISTICS
Printing style:
Pitch (char./in.):
Characters/line (maximum):
Print speed (lines/sec.):
PHYSICAL CHARACTERISTICS
Dimensions (in mm.):
Dimensions (in inches):
Weight:
Shipping Weight:
ModELS
151 Receipt (when ordered with Auto-cut option, single piece spill-resistant
cover is standard)
152 Receipt/Journal
153 Receipt/Journal/15-line Validation
154 Receipt/15-line Validation
INTERFACE oPTIoNS
RS232C:
IEEE1284:
PRINTER dRIVERS
Windows TM 95/98/2000/Me, NT 4.0, OPOS
oPTIoNS
Journal Lock
Display Pass-Thru (serial only)
Auto-Cutter — Partial cut leaves a .04 in. (1 mm.) tab in center of receipt
Light Gray or Black Cabinetry
PoWER REQUIREMENTS
Internal Universal AC Power: 90 VAC to 264 VAC (self-ranging), 47 to 63 Hz
RELIABILITY
Printer in full operation (using all available features)*
MCBF:
MTBF:
Printhead:
Auto-Cutter:
*Reliability data is based on our standard test conditions simulating a
normal retail operating environment.
ENVIRoNMENTAL SPECS
Temperature: Operating: 0 to +50 °C (32 to +122 °F)
Humidity: Operating: 10 to 90% RH (non condensing)
REGULAToRY CoMPLIANCE
FCC Class A CSA 950
©2008 Transact Technologies, Inc. Contents of this publication may
be changed without notice and shall not be regarded as a warranty.
The Epic 430TM name and logo are registered trademarks of TransAct
Technologies. Windows is a registered trademark of Microsoft
Corporation. All rights reserved. Patent pending.
Condensed
17.1
48
9.5 @ 10 char./line; 5.9 @ 40 char./line
171.45 W x 287 D x 142 H
6.75 W x 11.3 D x 5.6 H
6.5 lbs. (2.95 Kg)
9.5 lbs. (4.32 Kg)
Bi-Directional Serial (9-pin)
Bi-Directional Parallel (25-pin)
4,000,000 to 5,000,000 Print Lines
(depending on model)
22,000 to 30,000 Hours
(depending on model)
200,000,000 Characters
1,000,000 Cuts
CEMark UL 1950
SUPPLIES & SERVICE
We offer convenient one-stop shopping for all your printer needs-paper,
spare parts, manuals, printer servicing/refurbishment and more. For more
information, call us at 1-877-748-4222 or visit transact-tech.com.
FEATURES ANd BENEFITS
Print Speed: 9.5 lps. (340 cps.)—On Standard Test Receipt
n
Standard Warranty: Two Years (Extended Maintenance Plan Available)
n
Cash Drawer Drivers: Dual with Status (RJ11)
n
Print Zone Widths: 61 mm (2.4 in.) or 72 mm (2.8 in.)
n
Data Buffer: Up to 6K Configurable
n
CPI: 4, 6, 8.5, 10, 12, 15, 17.1, 20, 24
n
APA Bit Map Graphics
n
Portrait or Landscape Printing
n
Simple Loading of Receipt Paper
n
Available Emulations: Ithaca/IBM (PcOS
n
Microline, Star
67 Language Code Pages
n
Self Diagnostics
n
Concealed Cable Entry
n
Bar Codes: Code 39, Code 93, Interleaved 2 of 5, UPC-A and UPC-E,
n
EAN8 and EAN13, Code 128
Interface Parameters: Software Configurable via Buttons or Interface Port
n
* Licensed Command Firmware available as an option.
MEdIA
Paper Roll (One-Ply):
Width: 82.5 mm (3.25 in.) or optional 76 mm (3 in.)
n
Diameter: 89 mm (3.5 in.)
n
Length Per Roll: 73.1 m (240 ft.)
n
One-Ply Maximum Thickness: .11 mm (.0045 in.)
n
Paper Roll (Two-Ply):
Width: 82.5 mm (3.25 in.)
n
Diameter: 89 mm (3.5 in.)
n
Length Per Roll: 38.1 m (125 ft.)
n
Maximum Thickness Per Ply: .09 mm (.0035 in.)
n
Paper Roll (Three-Ply, not for use with Model 151 with Auto-Cut):
Width: 82.5 mm (3.25 in.)
n
Diameter: 89 mm (3.5 in.)
n
Length Per Roll: 26 m (85 ft.)
n
Maximum Thickness Per Ply: .25 mm (.01 in.)
n
Ribbons: 3-4.5 Million Character Life
Ithaca or Genuine Oki Snap-on Ribbon Cassette (Black or Purple)
n
WHo WE ARE
TransAct Technologies Incorporated (Nasdaq:TACT) is the leader in
developing and manufacturing market-specific printers for transaction-
based industries. These industries include gaming, lottery, POS, kiosk,
and banking. Each individual market has distinct, critical requirements for
printing and the transaction isn't complete until the receipt and/or ticket
is produced. TransAct printers are designed from the ground up based on
market specific requirements and are sold under the Ithaca
product brands. TransAct distributes its products through OEMs, value-
added resellers, and selected distributors. TransAct has over two million
printers installed around the world. TransAct has a strong focus on the
after-market side of the business, with a high commitment to printer
service, supplies, and spare parts. TransAct is headquartered in Hamden,
CT. For more information on TransAct, visit www.transact-tech.com
VDE 950
or call 203-859-6800.
WHERE To REACH US
TransAct Technologies Incorporated
Ithaca Facility
20 Bomax Drive
Ithaca, New York 14850
1.877.7ithaca (1.877.748.4222)
Fax: 607.257.3868
www.transact-tech.com
® ), Epson* ESC/POS ® ,
® and Epic
TransAct Technologies Incorporated
Corporate Headquarters Location
One Hamden Center
2319Whitney Avenue, Suite 3B
Hamden, CT 06518
203.859.6800
www.transact-tech.com
TA052108
