- Page 1 ASSEMBLY INSTRUCTIONS : 36X36X48 DINING TOP Description : T-36RXT AND T-30P (PACKED IN SEPARATE BOX) Item No. ITEM NO.: T-36RXT AND Printed in Vietnam T-30P(PACKED IN SEPARATE BOX) REVISED AUG 20, 2014 - 1 -...
- Page 2 Description Sketch Description Sketch Bolt Lock washer ( M6x35mm) (6.5x11mm) Flat washer Allen Key (6.5x13mm) (4x80mm) ITEM NO.: T-36RXT AND Printed in Vietnam T-30P(PACKED IN SEPARATE BOX) REVISED AUG 20, 2014 - 2 -...
- Page 3 STEP 2 Attach Top (A) to the Base (B) by using bolts (1), and washers (2) and (3) as shown below. Tighten with Allen key (4). ITEM NO.: T-36RXT AND Printed in Vietnam T-30P(PACKED IN SEPARATE BOX) REVISED AUG 20, 2014...
- Page 4 Place the leaf in the center of the open table top. Push the table top closed. Lock the mechanism underneath 2 sides of the table top as shown below. ITEM NO.: T-36RXT AND Printed in Vietnam T-30P(PACKED IN SEPARATE BOX)
