- Page 1 ASSEMBLY INSTRUCTIONS Description : ROUND TABLE TOP Item No: T-36RT OR T-30RT AND T-30P (PACKED IN SEPARATE BOX) Printed in Vietnam ITEM NO: T-36RT OR T-30RT AND T-30P ( PACKED IN SEPARATE BOX ) REVISED AUG 27, 2014 - 1 -...
- Page 2 Sketch Description Sketch Bolt Flat washer (M6x35mm) (6.5x13mm) Flat washer Lock washer (6.5x19mm) (6.5x11mm) Allen key (4x80mm) Printed in Vietnam ITEM NO: T-36RT OR T-30RT AND T-30P ( PACKED IN SEPARATE BOX ) REVISED AUG 27, 2014 - 2 -...
- Page 3 Carefully put the pedestal on the bottom side of the table top, attach the top (A) to mounting plate (B) with bolts (1), washers (3) and (4) as shown below. Tighten with Allen key (5). Printed in Vietnam ITEM NO: T-36RT OR T-30RT AND T-30P ( PACKED IN SEPARATE BOX ) REVISED AUG 27, 2014 - 3 -...
