Totevision LCD-1900VRQ User Manual

19" quad lcd display
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LCD-1900VRQ and is the answer not in the manual?

Questions and answers

Related Manuals for Totevision LCD-1900VRQ

Summary of Contents for Totevision LCD-1900VRQ

  • Page 2 PAY ATTENTION to all WARNING and CAUTIONS DO NOT use computer components not recommend by the manufacture Do not attempt to service the monitor your self. If a problem occurs, contact the manufacture's authorized service center ABOUT YOUR MONITOR This monitor is a microprocessor-controlled, color monitor which uses a TFT LCD panel.

  • Page 3: Specifications

    RGB Signals: Video Analog RGB 0.7Vp-pI75Q Sync Separate Display Data Channel: VESA DDC 1/2B Compatibility 19" Quad display LCD monitor Compatibility: IBM and compatible, Apple Environmental Limits: Operating Temp Storage Temp. 10 to 85% without condensation Operating Humidity Storage Humidity...

  • Page 4: Product Package

    1. Before you connect the cables, make sure that the monitor and the system unit power switches are OFF 2. Plug one end of the 15pin signal cable to the monitor and the other end to the video signal connector at the rear of the system.

  • Page 5: Control Functions

    (4) 19" Quad display LCD monitor CONTROL FUNCTIONS The OSD control functions of 19" Quad display LCD monitor are located on the lower side. They are shown in the figure below and described in the following paragraphs.
  • Page 6 .19" Quad display LCD monitor Chapter 3 ADJUSTING THE PC MONITOR The LCO monitor is designed to work with a range of compatible video adapters on the market. Oue to the possible deviations between these video adapters, you may make some adjustment to fit the monitor for adapter used.
  • Page 7 )ad Default- REWARE VERSIC N SXGA 5F211-5140 48KHz 60Hz II II 19" Quad display LCD monitor Adjustment Icon : Auto-adjustment Automatically adjust the pixel clock, HN position and fine tune the screen to get better visual quality. H-position Adjusts the screen's width. The range is from 0-255.

  • Page 8: Brightness Adjustment

    2. Use the 'V & t!.key to move the ~ to the EJ icon ,then press the - & + key to get the stable setting. ~ to the ~ ICON, then ...19" Quad display LCD monitor BRIGHTNESS ADJUSTMENT 1. Use the 'V & t!.key to move the ~ to the press - &+ to get the best brightnessoptimization.

  • Page 9: Adjustment Procedure

    ADJUSTING THE SECURITY SCREEN SETTING The LCD monitor is designed to work with a range of compatible video display on the market. Due to the possible deviations between these video source, you may make some adjustment to fit the monitor for video usage.
  • Page 10 .19"QuaddisplayLCDmonitor Security OSD menu setting When your screen is in A V mode, pressing MENU key to enter into OSD set up menu, you will see the following screen SETUP MENU SYSTEM CAMERA ALARM PLAYBACK VERSION You can use tor j key to move the highlight bar to the desired item, then press J to enter into the sub-menu to change setting.

  • Page 11: Signal Connector

    # display. For example, if you want to see the playback channel 1 in full screen, just pressing !/CH1, the screen will show the full screen of channel 1. .,..19" Quad display LCD monitor APPENDIX SIGNAL CONNECTOR PIN-OUT...
