Totevision LCD-702 Operating Instructions Manual

7.0" 16:9 wide screen universal headrest monitor
Hide thumbs
Table of Contents

Advertisement

Quick Links

OPERATING
INSTRUCTIONS
7.0" 16:9 Wide Screen
Universal Headrest Monitor
FLUSH MOUNTING / PHYSICAL MOUNTING SELECTABLE
It is unlawful in most jurisdictions for a person to drive a motor vehicle which is
equipped with a television or screen that is located in the motor vehicle at
any point forward of the back of the driver's seat, or that is visible directly
or indirectly to the driver while operating the vehicle.
CAUTION
1.
Do not expose to direct sunlight for extended periods of time.
2.
Do not drop the monitor or expose to strong impacts.
3.
Keep the monitor clean and dry.
4.
Do not operate the monitor at temperatures below 32°F (0°C) or above 140°F (60°C).
Before operating the unit, please read these instructions carefully.

Important Notice

e11 022771
OT01004639
05' 12

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LCD-702 and is the answer not in the manual?

Questions and answers

Related Manuals for Totevision LCD-702

Summary of Contents for Totevision LCD-702

  • Page 1: Important Notice

    Do not drop the monitor or expose to strong impacts. Keep the monitor clean and dry. Do not operate the monitor at temperatures below 32°F (0°C) or above 140°F (60°C). Before operating the unit, please read these instructions carefully. Important Notice...

  • Page 2: Installation Guide

    3. Ensure that the interconnect cable will reach from the monitor location to the power supply module. 4. Create the required opening for the monitor and trim ring. Be sure it is not too large, and that there is enough space behind the trim ring to store any excess interconnect cable.

  • Page 3: Electrical Connections

    Electrical Connections: Video-1 Input Video-2 Input Wiring System: Yellow Wire : Battery (+) Red Wire : ACC Black Wire : Ground Note: Please make sure all cables are connected correctly, wrong connections will damage the monitor. Black Fuse Yellow...

  • Page 4: Basic Operation

    Basic Operation: Front Control Panel: 1. LCD Panel 2. Headrest Shroud 3. POWER : ON / OFF / Mode Selection and Enter button (press and hold the button will power off) 4. UP : Positive and Negative Adjustment 5. MENU : Activation of Menu Indicator 7.

  • Page 5: Channel Selection

    Basic Operation(Optional): Remote Control: The remote control includes the following buttons for use with this monitor: Monitor Menu, Mode, Up, Down,Left, Right and Power. POWER ON/OFF ONLY WORK ON IN-DASH WIDE SCREEN COLOR MONITOR Replacement of Battery: 1. Use a small coin to play open battery holder from compartment.

  • Page 6: On-Screen-Display Settings

    On-Screen-Display Settings: MODE: When monitor is power on, press mode button on remote or power button control panel to select video inputs AV1/AV2 NTSC PAL. (Press and hold power button on control panel will power off the monitor.) MONITOR SETTINGS:...
  • Page 7 On-Screen-Display Settings: TINT: Press Menu button on remote or on control panel, OSD menu will show on LCD screen as below (left chart), press up/down button on remote or press and hold up/down button on control panel to select "TINT" setting. "TINT" setting will show as below (right chart).

  • Page 8: Installation Notes

    Always mount the monitor securely using the mounting hardware that is provided. Do not use the monitor unless it is properly secured to the vehicle. Box Contents: The Widescreen Universal Monitor includes the following parts and equipment: 1.
