Totevision LCD-1500VB Brochure

The Biggest Thing in
Sunlight Readable
LCD Monitors
LCD-2001VB
20" in Metal Housing
Channel down Channel up
Source Down Up
Select Menu
Active Matrix 20", 17", and 15" Color LCD Monitors
• Ultra-bright technology provides sunlight reability
• PIP: Picture in picture capability
• Wireless remote control allows easy access for monitor adjustment
• 4-stage brightness control
• Built-in ambient light sensor
• Built-in fan provides cooling
• On-screen display for: brightness, contrast, back light, hue, volume
• Component, composite, S-Video, & PC capability
• Slim space saving design
• For color and B&W applications
• Low power consumption
• LCD-2001VB, LCD-1701VB, and LCD-1500VB case
made of black durable steel
• Active matrix technology allows wide viewing angle
• Active matrix technology eliminates distortion
• Includes switching power supply 90-240V, 12V, 100W
• VESA 100mm FPMPMI compliant for LCD-1701VB and LCD-2001VB
VESA 75mm FPMPMI compliant for LCD-1500VB.
• LCD-2001VB and LCD-1701VB come with
built-in speakers for audio enjoyment
• Response Time, LCD-2001VB: 6ms/16ms (rising/falling)
Response Time, LCD-1701VB: 15ms/35ms (rising/falling)
Response Time, LCD-1500VB: 25ms/25ms (rising/falling)
Optional Accessories
DC-1600 Factory approved car cord
HM-400 Under-cabinet hinge mount
WM-302 Wall mount with swing arm & 4-way adjustment
Touch screen is not available for the LCD-2001VB, LCD-1500VB, & LCD-1701VB.
Specifications subject to change without notice
Available through:
P.9
Front button controls
on LCD-2001VB
Power
©2008 ToteVision 60K
LCD-2001VB
LCD-1701VB
LCD-1500VB
LCD-1701VB
17" in Metal Housing
Display: LCD-2001VB: 20.0" TFT LCD active matrix
LCD-1701VB: 17.0" TFT LCD active matrix
LCD-1500VB: 15.0" TFT LCD active matrix
Input Signal: Composite NTSC/PAL , S-Video, analog RGB
Resolution:
LCD-2001VB: 800(H) x 600(V)
LCD-1701VB: 1280(H) x 1024(V)
LCD-1500VB: 1024 (V) x 768 (V)
Brightness / Contrast: LCD-2001VB: 1000 Nit / 500:1
LCD-1701VB: 1300 Nit / 300:1
LCD-1500VB: 1800 Nit / 350:1
Viewing angle L/R/T/B:
80/80/80/80
Speakers: LCD-2001VB: front, 8 ohms, 5 W
LCD-1701VB: rear, 8 ohms, 1 W, 28 x 40mm oval type (x2)
Dimensions (WHD): LCD-2001VB: 506 x 414 x 62mm / 20" x 16.3" x 2.4"
LCD-1701VB: 430 x 360 x 70mm / 16.9" x 14.2" x 2.8"
LCD-1500VB - Front: 14-7/8" x 11-5/8" x 2-1/2"
Actual visible screen size (WH): LCD-2001VB: 408 x 306mm / 16.1" x 12"
LCD-1701VB: 337 x 270mm / 13.3" x 10.6"
LCD-1500VB: 304 x 288mm / 11.9" x 8.2"
Rear Terminal Connections:
LCD-2001VB/1701VB/1500VB: BNC video IN/OUTjacks,
15-pin D-sub (female), S-Video, 4-pin DC IN jack,
9-pin component IN jack
Weight: LCD-2001VB: Net: 8.1 kg. / 17.8 lbs. Gross: 12.6 kg. / 27.8 lbs.
LCD-1701VB: Net: 8 kg. / 17.6 lbs. Gross: 8.6 kg. / 19 lbs.
LCD-1500VB: Net: 6 kg. / 13.2 lbs. Gross: 7.3 kg. / 16 lbs.
1319 Dexter Ave. N.• Ste. 020 • Seattle, WA 98109
LCD-1500VB
15" in Metal Housing
Back: 14-3/16" x 11" x 2-1/2"
Tel: 206-623-6000 • FAX: 206- 623-6609
E-mail: sales@totevision.com
http://www.totevision.com
