Totevision LCD-1042TS Setup

1. Connect LCD touch screen to computer.
2. Insert PenMount Driver CD-ROM
-or-
Download PenMount Driver
www.penmount.com
-
Select "Download" from top menu
-
- Scroll down to select "Drivers"
Go to bottom of license agreement to select "I agree with the above license..."
-
Under Driver Downloads, scroll down to select link for your operating system. For Windows XP
-
users, scroll down to Windows
and Other Driver and select "PenMount DMC9000 Windows 2000-XP-2003 Drivers (WHQL
Certified)"
Select link next to right of Download. (For Windows XP: "PenMount DMC9000 Windows
-
2000/XP/2003 Driver V5.0006")
Run download.
-
Unzip files.
-
3. Open folder on disc or from download and select Setup.exe
4. Installation wizard will come up. Select "Next"
5. Accept license and "Next"
6. Select "Install"
7. When installation is done select "Finish" and reboot computer.
8. Select "PM" in menu bar.
10. Click "Calibrate" from PenMount Control Panel.
11 Use your finger or stylus to touch the red squares in a sequence. After the 5
touch screen is done being calibrated.
Now touch screen is ready to be used.
If you have trouble calibrating or getting touch screen to function, try...
1. Check RS-232 connection to computer and LCD touch screen
2. Check that you serial port is working okay.

Setting Up Touch Screen with PenMount Driver

(For ToteVision LCD-1042TS and LCD-1211TS Models)
th
red point the
