Totevision LCD-1700V Specifications

The Biggest Thing in
LCD Monitors
LCD-1700V
Active Matrix 17" Color LCD Monitors
• LCD -1703VRZ, 17" LCD color monitor in standard 19" rack mount kit
• Occupies 1 Rack Unit
• Monitor automatically turns ON/OFF when tilted up/down
• Rear mounting bracket extends from 24" to 30"

Optional Accessories

DC-1500 Factory approved car cord
HM-400 Under-cabinet hinge mount
WM-30 Wall mount bracket (fixed)
WM-302 Wall mount with swing arm & 4-way adjustable
WMC-1720 Ceiling mount
HM - 400 WM - 302
Touch Screen: order LCD-1700TS for model LCD-1700V
Touch screen not available for model LCD-1703VRZ
Specifications subject to change without notice
P.12
LCD-1700V: Dimensions w/o desk stand (WHD):
LCD-1700V: Dimensions w/ desk stand (WHD):
LCD-1700VR: Dimensions (WHD):
LCD-1703VRZ: Dimensions (WHD):
Includes switching power supply:
©2008 ToteVision 60K
LCD-1700V
LCD-1700VR
LCD-1703VRZ
Display:
17.0" TFT LCD active matrix
Back Light: Built-in (CCFT)
Input Signal: Composite NTSC/PAL (auto switching),
S-Video, component, DVI, Analog RGB
Resolution: SXGA 1280(H) x 1024(V)dots
PC compatibility: IBM / MAC compatible
Dot Pitch: 0.264(H) x 0.264(V)mm
Brightness rating: 350 cd/m² (Nit)
Colors: 16.7M
Contrast Ratio:
500:1
Number of Pixels: 1,310,720 dots
Viewing angle L/R/T/B: 85/85/85/85 degrees
Pixel Configuration: Stripe
Input Signal Level: 1.0V P-P (positive) 75 Ohm
Speakers:
8 ohms, 2W, 28 x 40mm oval type x 2
Stereo Amplifier: 2 W x 2 @ 10% THD, 100 mV
426 x 376 x 67mm / 16.8" x 14.8" x 2.6"
426 x 432 x 162mm / 16.8" x 17" x 6.4"
19" x 14" x 2.5"
19" x 1.75" x 24"
Actual visible screen size (WH): 338 x 270 mm / 13.3" x 10.6"
Operating temperature: 50~104°F or 10~40°C
Power Requirement: Regulated 12VDC, 4A, negative ground
Part No. DC-1500 required for use in vehicles
Power Consumption: LCD-1700V: 45 W (max), 3 W (power saving off mode)
LCD-1700VR/ 1703VRZ: 48 W (max),
100 ~ 240VAC (auto-sensing), 50 ~ 60Hz, 1.2A
Rear Terminal Connections:
BNC video IN/OUT jacks, 3.5 stereo audio IN jack,
RCA video IN, RCA L/R audio IN
2.1mm DC IN jack, S-Video jack
DVI (22 pin) w/ DVI /VGA cable
3.5 mm RS-232 IN, 9-pin component IN
LCD-1700V: Weight:
Net: 7.3 kg./ 16 lbs.
LCD-1700VR: Weight: Net: Est.7.4 kg./ 16.4 lbs Gross: 9.7 kg. / 21.4 lbs.
LCD-1703VRZ: Weight: Net: 14.4 kg. / 13.8 lbs. Gross: 9.5 kg. / 21 lbs.
1319 Dexter Ave. N.• Ste. 020 • Seattle, WA 98109
Tel: 206-623-6000 • FAX: 206- 623-6609
3 W (power saving off mode)
Gross: 9.5 kg. / 21 lbs.
E-mail: sales@totevision.com
http://www.totevision.com
