Totevision LCD-1510V Specifications

The Biggest Thing
in LCD Monitors
• HD compatible (supports 480p/i, 720p)
• RS-232 feature allows external devices to
control the monitor through the serial port.
• Hot key allows toggeling between video, S-Video, and PC modes
• PIP: Picture in picture capability
• Front controls for power menu, up/down, +/-
• On-screen display for: brightness, contrast, back light, hue, volume
• Composite, S-Video, component, and PC capability
• Case made of durable ABS plastic
• Built-in removable desk stand included
• Response Time: 30mS/20mS (rising/falling)

Optional Accessories

DC-1500 Factory approved car cord
HM-1215 Under-cabinet hinge mount bracket
HM-400 Under-cabinet hinge mount
LM-1510V Flush mount kit, Black metal
17" (W) x 15"(H) x 2.4"(D)
Installer's Cut-out: 15.5"(W) x 14.8"(H)
PLT-1000 VESA compliant pl)ate (75mm) FPMPMI
WM-31 Wall mount bracket (fixed) (order w/ PLT-1000)
WM-302 Wall mount with swing arm & 4-way adjustable (order w/ PLT-1000)
WM-1000 2-way adjustable wall mount bracket
WMC-1015 Ceiling mount (order PLT-1000)
HM - 400
Touch screen not available for the LCD-1510V.
Specifications subject to change without notice
P.14
Active Matrix 15.1" Color LCD Monitors
WM - 302
©2008 ToteVision 60K
Display:
15.1" TFT LCD active matrix
Back Light: Built-in (CCFT)
Input Signal: Composite NTSC/PAL (auto switching),
S-Video, Analog
Resolution:
XGA 1024 (H) x 768 (V)dots
PC compatibility: XGA, SVGA, VGA, MAC II
Dot Pitch: 0.297 (H) x 0.297(V)mm
Brightness rating: LCD-1510V: 500 cd/m² (Nit)
Colors: 16.7M
Contrast Ratio: 400 : 1
Number of Pixels: 786,432 dots
Viewing angle L/R/T/B: LCD-1510V: 60/60/60/60 degrees
Pixel Configuration: Stripe
Input Signal Level:
1.0V P-P (positive) 75 Ohm
Speakers: 8 ohms, 2 W, 28 x 40mm oval type x 2
Speaker Amplifier:
2 W x 2 @ 10% THD, 100 mV
Dimensions w/o desk stand (WHD): 378 x 322 x 60mm / 14.9" x 12.7" x 2.4"
Dimensions w/ desk stand (WHD):
378 x 355 x 162mm / 14.9" x 14" x 6.4"
Actual visible screen size (WH): 309 x 232mm / 12.1" x 9.1"
Operating temperature: 32~122°F or 0~50°C
Power Requirement: Regulated 12VDC, 3500mA, negative ground
Part No. DC-1500 required for use in vehicles
Power Consumption: 35 W (max)
Includes switching power supply: 100 ~ 240VAC, 1A/47 ~63Hz
Rear Terminal Connections: BNC video IN/OUT, S-Video jack
3 RCA IN jacks (composite, audio L/R),
3.5 stereo audio OUT jack, 2.1mm DC IN jack
15-pin mini D-sub (female), 9-pin Component IN jack,
RS-232, DVI
Weight: Net: 4.82 kg. / 10.62 lbs. Gross: 6.72 kg. / 14.82 lbs.
1319 Dexter Ave. N. • Ste. 020 • Seattle, WA 98109
Tel: 206-623-6000 • FAX: 206- 623-6609
E-mail: sales@totevision.com
http://www.totevision.com
LCD-1510V
Shown with RM-1510V Rack Mount
Shown with LM-1510V Flush Mount
