Page 1 V2 Series II Owner's Handbook. www.holden.com.au...
Page 2 Holden Ltd, ABN 84 006 893 232 (hereinafter Holden). Change of name, address or ownership In the event of a Safety Recall, or for various reasons, Holden may need to contact you as the owner of this vehicle. Also, if less than three years old, this vehicle will qualify for Roadside Assistance, refer to Chapter 9.
Page 3: Table Of Contents
Specifications 8 Engine and general specifications, capacities, identification plates, dimensions. After Sales 9 Warranty, Holden Retailers, Holden Roadside Assistance, Customer Assistance. Tow and load 10 Loading information, towing equipment, towing precautions. Cleaning 11 Interior cleaning, washing, list of maintenance materials.
Page 4 We thank you for choosing Holden and want to assure you of our continuing interest in your driving pleasure and satisfaction. This handbook applies to the current Monaro model. Therefore, due to different models and options, you may find reference in this Handbook to some equipment not fitted to your own vehicle.
Page 5 Please mail to the address on the back of this page. If Holden Assist is fitted, please also press the Assist button on the rear view mirror to advise of change of address / ownership. Please tick the appropriate box:...
Page 6 Place in an envelope and mail to: The Manager – Warranty Administration Service Department Holden Ltd Box 548D, G.P.O. Melbourne Victoria, 3001...
Page 7 Please mail to the address on the back of this page. If Holden Assist is fitted, please also press the Assist button on the rear view mirror to advise of change of address / ownership. Please tick the appropriate box:...
Page 8 Place in an envelope and mail to: The Manager – Warranty Administration Service Department Holden Ltd Box 548D, G.P.O. Melbourne Victoria, 3001...
Page 9 Please mail to the address on the back of this page. If Holden Assist is fitted, please also press the Assist button on the rear view mirror to advise of change of address / ownership. Please tick the appropriate box:...
Page 10 Place in an envelope and mail to: The Manager – Warranty Administration Service Department Holden Limited Box 548D, G.P.O. Melbourne Victoria, 3001...
Page 11: Dashboard
Dashboard The following page illustrates the dashboard, identifying and locating each function; page numbers refer to each item. Page Layout Gauges Warning / reminder indications 1-14 Turn signals, Horn, Tilt / reach steering 1-15 Trip computer – single-window 1-20 Trip computer – triple-window 1-27 Customisation mode 1-35...
Page 12 Chapter 1 DASHBOARD LAYOUT Page Glovebox ............... 3-14 Cup holders (if fitted) ............. 3-18 Vents ................1-47 Sunlight sensor .............. 1-36 Hazard warning switch ..........1-38 Switches for (depending on model) • Air conditioner and heater controls ......1-44 • Climate controls ............
Page 13 Chapter 1 DASHBOARD...
Page 14 Chapter 1 DASHBOARD GAUGES Speedometer The speedometer shows vehicle speed in kilometres per hour (km/h). Tachometer The tachometer shows engine speed in revolutions per minute (r.p.m.). Sustained operation in the RED zone may cause serious engine damage. Automatic transmission: Under wide open throttle acceleration (accelerator pedal pushed flat to the floor) it is possible that the tachometer needle...
Page 15 System Check is performed and the status is shown on the display. If there are no warnings or service reminders, the display will show a series of Holden welcome screens displaying the Holden logo and finishing with the 'OK!' screen.
Page 16 C h e c k that you should see your Holden Retailer. A l t e r n a t o r The 'Check Alternator' animation displays until...
Page 17 A B S malfunction of the Anti-lock Brake System is indicated and you should see your Holden F a u l t Retailer. The vehicle's brake system will still R N D 3 2 1 operate conventionally, only the anti-lock operation is disabled, refer to Chapter 4.
Page 18 Fault correctly, especially in an accident. You R N D 3 2 1 should see your Holden Retailer immediately. The warning light illuminates after an accident where the pretensioners, or pretensioners and airbag(s), have activated.
Page 19 C t r l O f f traction control system is not working and R N D 3 2 1 you should see your Holden Retailer. The 'Traction Ctrl Off' animation displays for 2 seconds. The animated symbol then reverts...
Page 20 Chapter 1 1-10 DASHBOARD WARNING / REMINDER INDICATIONS cont. Over temperature E n g i n e If the 'Engine Temp Hot' animation illuminates while driving, it indicates that Te m p H o t the engine coolant temperature is dangerously hot.
Page 21 You should have the problem fixed as soon as possible. Your Holden Retailer has the correct diagnostic computer equipment and training to find and fix the problem.
Page 22 If the 'Service Error Contact Retailer' animation illuminates while driving, a fault in the instrument panel is indicated. You should contact your Holden Retailer as soon as possible. The 'Service Error' animation displays until the MODE button on the trip computer O d o m e t e r switch is pressed.
Page 23 Chapter 1 1-13 DASHBOARD WARNING / REMINDER INDICATIONS cont. Overspeed Overspeed is designed to warn you when you have exceeded your pre-selected speed. For information on the Overspeed displays, refer to TRIP COMPUTER further on in this chapter. Power shift (with auto transmission) The automatic transmission 'Power Shift' P o w e r animated symbol and PWR icon display...
Page 24 Chapter 1 1-14 DASHBOARD TURN SIGNALS, HORN, TILT / REACH STEERING Turn signals The turn signals lever is on the right side of the steering column. Push the lever up to signal a left turn, down to signal a right turn. In some turns (such as changing lanes) the steering wheel is not turned far enough to cancel the turn signal.
Page 25 Chapter 1 1-15 DASHBOARD TRIP COMPUTER – SINGLE-WINDOW TYPE Two types of trip computers are available. Depending on the luxury level, your vehicle is fitted with a single-window trip computer or a triple-window trip computer. Explanation regarding the triple-window type is found further on in this chapter. The buttons for the trip computer are located to the left of the gauges.
Page 26 Chapter 1 1-16 DASHBOARD TRIP COMPUTER – SINGLE-WINDOW TYPE cont. TAP MODE BUTTON *Distance / Time to Go At the start of a trip estimate your distance 5 0 0 k m t o G o to arrival (from maps, road signs etc.). Tap 2 3 : 2 0 h r s button until the display shows your estimated trip distance.
Page 27 Chapter 1 1-17 DASHBOARD TRIP COMPUTER – SINGLE-WINDOW TYPE cont. Overspeed The Overspeed sets the speed you do not want to exceed. For example, if driving in a 60 km/h zone, set overspeed to 60, by tapping the button. When vehicle speed exceeds 60 km/h, the overspeed animated warning message in the instrument panel centre displays and an audible chime...
Page 28 Chapter 1 1-18 DASHBOARD TRIP COMPUTER – SINGLE-WINDOW TYPE cont. Overspeed presets Instead of adjusting Overspeed up and down in 5 km increments (see previous page), you can set four commonly used speeds, e.g. 60, 80, 100 and 110 km/h. Hold down the MODE button for 2 seconds Normal overspeed when the Overspeed display is shown.
Page 29 'Additional service requirements' in the service booklet in your glovebox. The Service due message will be reset for you by your Holden Retailer when you take your vehicle there to be serviced.
Page 30 Chapter 1 1-20 DASHBOARD TRIP COMPUTER – TRIPLE-WINDOW TYPE Two types of trip computers are available. Depending on the luxury level, your vehicle is fitted with a single-window trip computer or a triple-window trip computer. Again, depending on your vehicle's luxury level, there are two unique styles of the triple-window trip computer, but the information displayed is the same for both models.
Page 31 Chapter 1 1-21 DASHBOARD TRIP COMPUTER – TRIPLE-WINDOW TYPE cont. AVG FUEL O d o m e t e r AVG SPEED 59.6 12.6 km/h L/100km 0 1 2 , 6 8 9 k m P R N D 3 2 1 Average Speed Odometer Average Fuel...
Page 32 Chapter 1 1-22 DASHBOARD TRIP COMPUTER – TRIPLE-WINDOW TYPE cont. FUEL TIME TO ARRIVAL D i s t t o A r r i v a l REMAINING 12:34 5 0 0 k m P R N D 3 2 1 *Distance to Arrival *Remaining Fuel *Time to Arrival...
Page 33 Chapter 1 1-23 DASHBOARD TRIP COMPUTER – TRIPLE-WINDOW TYPE cont. INST FUEL D i s t t o E m p t y O/SPEED 12.4 L/100km km/h 4 2 0 k m P R N D 3 2 1 Overspeed Distance to Empty Instantaneous Fuel An estimate of how far your...
Page 34 Chapter 1 1-24 DASHBOARD TRIP COMPUTER – TRIPLE-WINDOW TYPE cont. Overspeed presets Instead of adjusting Overspeed up and down in 5 km increments (see previous page), you can set four commonly used speeds, e.g. 60, 80, 100 and 110 km/h. Hold down the MODE button for 2 seconds Normal overspeed when the Overspeed display is shown.
Page 35 Chapter 1 1-25 DASHBOARD TRIP COMPUTER – TRIPLE-WINDOW TYPE cont. TAP MODE BUTTON *Stop Watch The Stop Watch function, when enabled, records elapsed time. It can be used, for example, to measure the time taken to travel between two points on a trip. To start / stop the Stop Watch, press the SET button.
Page 36 'Additional service requirements' in the service booklet in your glovebox. The Service due message will be reset for you by your Holden Retailer when you take your vehicle there to be serviced.
Page 37 Chapter 1 1-27 DASHBOARD CUSTOMISATION MODE Customisation Mode enables the driver to customise some of the vehicle features using the trip computer switch and instrument panel centre display. Note: Only features that are fitted to the vehicle will be displayed. Entering customisation mode Customisation Mode is accessible via the Options Menu, which can be displayed when the vehicle is stationary or moving slowly.
Page 38 Chapter 1 1-28 DASHBOARD CUSTOMISATION MODE cont. Options Once in Customisation Mode, the driver can step through the following series of options: RESTORE TO FACTORY SETTINGS RESTORE TO This option restores the instrument panel, FACTORY SETTINGS entertainment system and other general vehicle systems to the factory default Ye s settings.
Page 39 Chapter 1 1-29 DASHBOARD CUSTOMISATION MODE cont. DIST TO GO / ARRIVAL DEFAULT DIST TO GO The Distance to Go (single-window) or DEFAULT Distance to Arrival (triple-window), can be 5 0 0 reset (when not in customisation mode) by pressing the SET button for less than 2 seconds.
Page 40 Chapter 1 1-30 DASHBOARD CUSTOMISATION MODE cont. CONFIRMATION BEEPS CONFIRMATION This option is used to enable / disable the BEEPS audio system confirmation beeps function. O f f This function is explained further in the Audio System Handbook located in the glovebox.
Page 41 Chapter 1 1-31 DASHBOARD CUSTOMISATION MODE cont. HEADLIGHTS APPROACH TIME HEADLIGHTS This option is used to adjust the headlights APPROACH TIME approach illumination time delay. This 5 secs function is explained further on in this chapter. Use the button to adjust the delay setting between zero and 90 seconds (Default = 30 seconds).
Page 42 Chapter 1 1-32 DASHBOARD CUSTOMISATION MODE cont. TWO STAGE UNLOCK This option is used to enable / disable the TWO STAGE UNLOCK two stage door unlock function. This function is explained in detail in Chapter 2. Use the Ye s button to select 'Yes' or 'No'.
Page 43 Chapter 1 1-33 DASHBOARD CUSTOMISATION MODE cont. ENTER CALIBRATION ADJUSTMENT (triple-window only) This option is used to calibrate the trip ENTER computer distance and fuel figures. The trip CALIBRATION ADJUSTMENT computer uses in its calculations different calibration numbers. These figures are Ye s preset for the standard vehicle and do not have to be adjusted.
Page 44 Chapter 1 1-34 DASHBOARD CUSTOMISATION MODE cont. FUEL CALIBRATION FUEL If Fuel Calibration is not required, press the CALIBRATION MODE button to advance to the EXIT 1 0 0 . 0 2 5 0 OPTIONS MENU. If you wish to check / adjust the Fuel Calibration, work out the following BEFORE ENTERING CUSTOMISATION MODE: 1.
Page 45 Chapter 1 1-35 DASHBOARD WIPERS and WASHERS The lever on the left of the steering column controls the wipers and washers, which operate when the ignition is turned to either on or accessories. Wipers and washers Never operate the wipers on dry glass, as this will damage the rubber and scratch the glass.
Page 46 Chapter 1 1-36 DASHBOARD LIGHTS All lights off Park lights Dimmer – instrument lighting Turns on the park, tail, The instruments are automatically rear licence illuminated when the park lights instrument panel lights. are switched on. The lighting can be adjusted anywhere between dim and bright by holding the tab in the bright or dim position until the desired level...
Page 47 Chapter 1 1-37 DASHBOARD LIGHTS cont. Automatic headlights When the headlight switch is left in the AUTO position, the headlights and park lights automatically switch off and on with the ignition switch or through the approach lighting feature (refer to 'Headlights on when approaching the vehicle'). High / low beam selection must still be manually controlled.
Page 48 Chapter 1 1-38 DASHBOARD LIGHTS cont. Fog lights Fog lights are designed to provide a different illumination of the road to the usual headlight beam. Depending on the density of the fog, different combination of lights will improve vision. For instance, in very heavy fog, vision may be improved by turning the headlights off, and just having the park lights and fog lights on.
Page 49 Chapter 1 1-39 DASHBOARD RADIO / CD AND CLOCK Radio, CD and clock Detailed information on the operation of the radio and CD is provided by the Audio System Handbook in the glovebox. Operating information for adjusting time, adjusting the antenna height, the Personal Identification Number (PIN) and remote control of the radio via the steering wheel is provided on these pages.
Page 50 If your Security Card is lost and the PIN is not recorded elsewhere, the PIN can be requested from your Holden Retailer, after supplying the proof of ownership and the Vehicle Identification Number shown on the inside front cover of this handbook. There may be a nominal charge for this service.
Page 51 Chapter 1 1-41 DASHBOARD REMOTE RADIO / CD CONTROLS Remote controls for the radio / CD are provided by buttons located on the left side and right side of the steering wheel centre pad. Left side Pressing the MODE button alternates between different audio modes: radio FM1, radio FM2, radio AM and CD.
Page 52 Chapter 1 1-42 DASHBOARD ANTENNA The antenna shaft should be regularly cleaned with a soft cloth, water and a mild detergent. This not only helps the antenna to retract but also aids radio reception. In addition to the normal external antenna, higher luxury levels have a 'diversity' antenna, which improves FM reception.
Page 53 Chapter 1 1-43 DASHBOARD PHONE Mobile phone connection A power connection for fitting a mobile telephone is provided for all models. The connector is taped under the centre console, on the passenger's side. Mobile phone connector Mobile phone connector Mobile phone connector (taped back) (taped back) (taped back)
Page 54 Chapter 1 1-44 DASHBOARD STANDARD HEATER AND AIR CONDITIONER Mode dial RECIRCULATE. Interior air is recirculated and directed back through the face level vents. Refer to operating notes on following page. FACE. Air comes from the face level vents and the rear seat vents. BI-LEVEL.
Page 55 Chapter 1 1-45 DASHBOARD STANDARD HEATER AND AIR CONDITIONER cont. Fan dial The fan dial provides speed control of the blower fan in all Mode dial positions. Air conditioning The air conditioning is turned on when the A/C switch is pressed. Press the A/C switch again to turn the air conditioner off.
Page 56 The system is protected by switches that guard against abnormal loads and loss of refrigerant. The compressor may switch off permanently. Have the system checked by a Holden Retailer if this occurs. Note: It is important that once every two weeks, with the engine running, to switch the air conditioner on for 5 to 10 minutes (even in Winter) to lubricate the air conditioner system seals.
Page 57 Chapter 1 1-47 DASHBOARD VENTILATION SYSTEM The vehicle features a flow-through ventilation system for your comfort. Under reasonable conditions, it should not be necessary to open the windows at any time. Outside air (except when recirculate is selected) is drawn into the vehicle through the opening between the bonnet and the windscreen.
Page 58 Chapter 1 1-48 DASHBOARD CLIMATE CONTROL (if fitted) The Climate Control panel is located in the centre of the dashboard. It is designed to maintain the interior of your vehicle at your desired temperature. Right and left sides of the vehicle can be maintained at different temperatures (dual zone). Automatic operation 1.
Page 59 Chapter 1 1-49 DASHBOARD CLIMATE CONTROL (if fitted) cont. Dual zone The left and right sides of the vehicle can be set to different temperatures or can be linked to operate identically, i.e., the passenger's side will mirror whatever the driver's side is changed to.
Page 60 Chapter 1 1-50 DASHBOARD CLIMATE CONTROL (if fitted) cont. FLOOR DEMIST AND BI-LEVEL FACE FLOOR (BLEND) Air is directed to the Cooler air is directed Air is directed to the floor vents. Air is directed to to the face and rear face and rear vents.
Page 61 Chapter 1 1-51 DASHBOARD CLIMATE CONTROL (if fitted) cont. RECIRCULATION Switches air intake to recirculated air. Recirculate reuses interior air and is therefore not recommended for long periods of time. Recirculate position should NOT be used if occupants are smoking. Recirculation automatically switches off after 40 minutes, or it can be manually turned off by pressing the switch again.
Page 62 Chapter 1 1-52 DASHBOARD CLIMATE CONTROL (if fitted) cont. Press on the fan switch to increase or decrease the fan speed. Five manual fan speeds are available. When the fan has been adjusted manually the fan blades will fill according to the fan speed, for speeds 1 to 4.
Page 63 Chapter 1 1-53 DASHBOARD CLIMATE CONTROL NOTES Ignition keys Vehicles fitted with 'priority key locking' systems (refer to Chapter 2 'Locks') have the ability to remember individual adjustments for different keys. When the key is inserted in the ignition and turned on, the system identifies the key and sets the climate control to the last adjustments used for that key.
Page 64 Something wrong? This symbol shows on the display when there is a fault in the system. You should see your Holden Retailer, who has the necessary equipment to diagnose the system. Sensors The climate control uses different sensors to maintain your desired temperature.
Page 65 Chapter 1 1-55 DASHBOARD CRUISE CONTROL The cruise control maintains your vehicle's speed without you having your foot on the accelerator pedal. The cruise control lever is on the right side of the steering column. The ON-OFF / CANCEL switch is at the end of the lever and is activated by pushing in towards the direction of the steering column.
Page 66 Chapter 1 1-56 DASHBOARD CRUISE CONTROL cont. TO ADJUST YOUR SET SPEED you may either: • Rotate the lever down to the SET-DECEL position until the vehicle slows down to the desired speed, then release. • Rotate the lever up to the RES-ACCEL position until the vehicle accelerates up to the desired speed, then release.
Page 67 Chapter 1 1-57 DASHBOARD CRUISE CONTROL cont. WARNING: • Do not use the cruise control when road or driving conditions require varying speeds. A constant speed isn't practical in heavy or varying traffic, or on winding, slippery or rough roads. •...
Page 68 Chapter 1 1-58 DASHBOARD REVERSE PARKING AID (if fitted) Reverse Parking Aid (if fitted) Reverse Parking Aid (RPA) is designed to help the driver reverse the vehicle by indicating (with varying tones) the distance to the nearest obstacle behind the vehicle. The RPA starts automatically when the ignition is on and reverse gear is selected.
Page 69 Tow bar: When a tow bar is fitted to the vehicle, the RPA requires adjustment to allow for the protrusion of the tow bar. Your Holden Retailer will automatically adjust the RPA when fitting the tow bar. If the RPA should require tow bar adjustment by the owner due to the removal or installation of a tow bar, proceed as follows: •...
Page 70 • No tones or a deep continuous warning tone after engaging reverse gear – system defective (contact your local Holden Retailer). Safety Instructions When reversing the vehicle, the driver must still drive in such a way as to avoid all risks to others on the road.
Page 71 Chapter 1 1-61 DASHBOARD NAVIGATION SYSTEM (if fitted) Navigation System (if fitted) Detailed information on the operation of the in-car navigation system (SATNAV) is provided by the supplement in the glovebox. Note: If a vehicle fitted with a SATNAV system is towed, the antenna will need to redefine the position of the vehicle, as only the previous location prior to towing is stored in the memory.
Page 72 Chapter 1 1-62 DASHBOARD NOTES...
Page 73: Locks
Chapter 2 LOCKS Locks Page Keys Door locks Alarm Ignition lock 2-10 Free turning door locks 2-11 Boot lock 2-12 Bonnet lock...
Page 74 PIN. Please keep the card in a safe place, away from your vehicle. If a key is lost, a replacement can be ordered through any Holden Retailer by quoting the key code number, security number and providing proof of ownership.
Page 75 Chapter 2 LOCKS KEYS cont. Personal identity keys (if fitted) This system provides two different memories of electronic settings, for different keys. For instance, one driver may have a preferred radio station. Pressing the UNLOCK button on their key will automatically customise the radio for that driver. However, the other driver may prefer a different station.
Page 76 Chapter 2 LOCKS DOOR LOCKS Lock Doors are locked when the lock knob is down. Automatic vehicles – have an 'Auto lock in drive' feature which locks the doors automatically when the transmission selector is shifted out of Park. This feature can be selected from the instrument panel Customisation Mode (refer to CUSTOMISATION MODE in Chapter 1).
Page 77 Chapter 2 LOCKS DOOR LOCKS cont. To disengage deadlock Press UNLOCK on the key (within 4 metres of the vehicle). This will unlock the doors. Therefore, undeadlocking happens naturally, when unlocking the doors. Unlock Press UNLOCK once to unlock driver’s Press the UNLOCK button on the key within door;...
Page 78 Try pressing LOCK on the key again. If it still does not work a replacement key may be needed from your Holden Retailer. If, for any reason, pressing the key buttons will not work, the doors can still be locked and unlocked by turning the key in the driver's door lock.
Page 79 Chapter 2 LOCKS ALARM Switching on and off The alarm system is turned on when the LOCK button on the key is pressed, and turned off when UNLOCK is pressed. Therefore, locking the doors by pressing LOCK not only locks both the doors but (after a short delay) also sets the alarm system. When set off The alarm is triggered when any of the doors, bonnet or boot are opened or a hot-wire attempted;...
Page 80 Chapter 2 LOCKS ALARM cont. Notes • Remember, the alarm system is turned off and on when the UNLOCK and LOCK buttons on the key are pressed. When the alarm system is switched on, turning the key in the lock and then opening a door triggers the alarm. The alarm system thinks a break-in has occurred.
Page 81 Chapter 2 LOCKS IGNITION LOCK WARNING: Do not turn the engine off while the vehicle is moving or there will not be any power assist for brakes or steering. Never remove the key while the vehicle is moving, as this will lock the steering.
Page 82 If you have problems contact your Holden Retailer. Remember that your vehicle is covered for the first 3 years by Roadside Assist, refer to Chapter 9.
Page 83 Chapter 2 2-11 LOCKS BOOT LOCK Use one of the methods shown below to unlock the boot. After partly opening the boot lid, gas struts automatically take over to lift and hold the boot lid in the fully open position. The boot locks automatically when pushed shut, so be careful not to leave keys in the boot, as they will be locked in when it is shut.
Page 84 Chapter 2 2-12 LOCKS BONNET LOCK To open From the driver's side of the vehicle, pull the lever shown towards you. P U L L This allows the bonnet to release but is prevented from opening by the safety catch. To open completely, reach under the centre of the bonnet and move safety catch upwards.
Page 85 Chapter 3 KNOW YOUR VEHICLE Know your vehicle Page Front seat Rear seat entry Seat belts Which type of child restraint for your child? Child restraints 3-10 Windows 3-11 Mirrors 3-12 Interior lights 3-13 Accessory control and battery saver 3-14 Glovebox and centre console 3-15 Storage compartments...
Page 86: Know Your Vehicle
Chapter 3 KNOW YOUR VEHICLE FRONT SEAT Two switches are fitted to the front seats. The front switch is used to electrically adjust the height, the tilt and the movement of the seat forwards and backwards. The rear switch is used to electrically adjust the recline angle of the back of the seat. Adjustment to lumbar support and head restraints are made manually.
Page 87 Chapter 3 KNOW YOUR VEHICLE FRONT SEAT cont. WARNING – SIDE IMPACT AIRBAGS Do not fit unauthorised seat covers as they may impair the deployment of the Side Impact Airbags. Do not position your body or any object (including pillows) between front seats and doors.
Page 88 Chapter 3 KNOW YOUR VEHICLE REAR SEAT ENTRY Moving the seat forward Both front seats have a lever on the outside edge to enable rear seat entry and exit. WARNING: Seats can be moved at any time, regardless of the ignition key position. It is therefore important not to leave children unsupervised in the vehicle.
Page 89 Chapter 3 KNOW YOUR VEHICLE REAR SEAT ENTRY cont. Moving the seat rearwards WARNING: Before moving the seat rearwards, ensure that nobody in the rear can become pinned between the front and rear seats. Before moving the seat, ensure there are no objects in front or behind the seat.
Page 90 Chapter 3 KNOW YOUR VEHICLE SEAT BELTS Lap / sash belts To fasten, pull the metal tongue across your body and clip it into the buckle. When the metal tongue is locked safely into place you will hear a 'click'. After fastening, settle the belt at the hip, and run your hand under the sash from hip to shoulder to ensure that the belt fits comfortably and is free from twists.
Page 91 If the SRS warning light comes on at any other time, or if the warning 'SRS Airbag Fault' displays on the instrument panel, you should see your Holden Retailer immediately to have the system checked. Refer to Chapter 1 for further information about warnings and reminder indications.
Page 92 Chapter 3 KNOW YOUR VEHICLE WHICH TYPE OF CHILD RESTRAINT FOR YOUR CHILD? Children should be restrained at all times and fitted with a child restraint appropriate to their size when travelling in a vehicle. Following are some guidelines about selecting the appropriate restraint for your child.
Page 93 Chapter 3 KNOW YOUR VEHICLE CHILD RESTRAINTS WARNING – EXTREME HAZARD: • Do not use a rearward facing child restraint on a seat protected by an airbag in front of it. • NEVER install a child restraint in the front seat of a Monaro. The Monaro is fitted with Passenger and Side Impact Airbags and the child could be seriously injured if either airbag inflates, as the...
Page 94 Chapter 3 3-10 KNOW YOUR VEHICLE WINDOWS Power windows The window switches are located between the front seats. The switches also remain operational when the ignition is turned off for 60 minutes while the doors remain closed and for 45 seconds after a door is opened.
Page 95 Chapter 3 3-11 KNOW YOUR VEHICLE MIRRORS Internal rear view mirror Moving the lever on the lower edge of the mirror reduces headlight glare from following vehicles when driving at night. During daylight driving, the lever should be set forward, away from the driver. At night, flick the lever towards the driver.
Page 96 Chapter 3 3-12 KNOW YOUR VEHICLE INTERIOR LIGHTS Interior (dome) light DOOR The interior light is located in the centre of the roof. It can be switched to: OFF (always off), ON (always on), or DOOR DOOR: The light automatically switches on Reading when a door is opened and switches off light...
Page 97 Chapter 3 3-13 KNOW YOUR VEHICLE ACCESSORY CONTROL AND BATTERY SAVER Accessory Control Your vehicle is equipped with an accessory control feature that can be set at the instrument panel to shut down all accessories (radio, power socket, wipers etc.) either when the ignition key is turned off, or when the driver's door is opened (refer to Chapter 1, CUSTOMISATION MODE for details about this setting).
Page 98 Chapter 3 3-14 KNOW YOUR VEHICLE GLOVEBOX AND CENTRE CONSOLE Glovebox The glovebox is located in the dashboard directly in front of the passenger’s seat. A specific key is provided solely to lock and unlock the glovebox. For security, the master key is not designed to operate the glovebox lock.
Page 99 Chapter 3 3-15 KNOW YOUR VEHICLE STORAGE COMPARTMENTS Front and rear storage compartments All vehicles are built with storage compartments, front and rear, which are fitted with a 'push-push' cover. The front storage compartment is located beneath the radio system, and the rear storage compartment is at the rear of the centre console.
Page 100 If required, your vehicle can be fitted with an ashtray and lighter instead of front and / or rear storage compartments. Your Holden Retailer can order and fit the ashtray and lighter for you. Ashtray (if fitted) The ashtrays are fitted with a 'push-push' cover.
Page 101 Chapter 3 3-17 KNOW YOUR VEHICLE POWER SOCKET Power socket All vehicles have a power socket located inside the centre console. The power socket is operational when the ignition is turned to either on or accessories. Note: Any accessory device (mobile phone, car fridge etc.) connected to the power socket must not exceed a current draw of 10 amps.
Page 102 Chapter 3 3-18 KNOW YOUR VEHICLE CUP HOLDERS WARNING: Do not forget full cups when accelerating and braking! To avoid spillage, it is recommended that any cups placed in the holders have lids. Cup holders are designed for holding standard size soft drink cans and smaller size bottles.
Page 103 Chapter 3 3-19 KNOW YOUR VEHICLE CUP HOLDERS cont. Front cup holders – centre (if fitted) The centre cup holders are located forward of the centre console. The cup holder bin may be covered by a telephone storage tray (if fitted) which is removable to allow access to the cup holders.
Page 104 The footrest for the driver’s left foot is adjustable to three positions. First undo the two screws on the right hand side of the footrest. Move the footrest forward or backward as required, then replace the screws. See your Holden Retailer for assistance with this adjustment if necessary.
Page 105 Chapter 3 3-21 KNOW YOUR VEHICLE NOTES...
Page 106 Chapter 3 3-22 KNOW YOUR VEHICLE NOTES...
Page 107: Driving
Chapter 4 DRIVING Driving Page Safety Engine starting Automatic transmission Manual transmission Anti-lock brake system Traction control 4-11 Driving precautions Running-in 4-13 Add on equipment...
Page 108 Chapter 4 DRIVING SAFETY Before entering the vehicle 1. Check that windows, mirrors and lights are clean. 2. Visually check tyre inflation (check with a pressure gauge each week). Before driving off 1. Be sure that all doors are closed and secured. 2.
Page 109 Chapter 4 DRIVING ENGINE STARTING 1. Ensure the park brake is firmly applied and release it only after you have started the engine and are ready to drive off. 2. Manual: Press the clutch pedal and shift the gear lever to Neutral position. The clutch pedal can now be released.
Page 110 Chapter 4 DRIVING AUTOMATIC TRANSMISSION (if fitted) Floor mounted shift Push in the button on top of the transmission selector lever when shifting into any position indicated by the blue arrow. When the position of the transmission selector is changed, a large symbol is illuminated on the instrument panel centre display in conjunction with the PRND321 constant icon at the bottom of the display.
Page 111 Chapter 4 DRIVING AUTOMATIC TRANSMISSION (if fitted) cont. Power / normal / cruise mode The transmission operates in three modes: power, normal and cruise. Power mode has revised automatic transmission shift points, to give the vehicle a more responsive feel. Normal mode is recommended for normal or freeway driving, as it gives better fuel economy.
Page 112 Chapter 4 DRIVING AUTOMATIC TRANSMISSION (if fitted) cont. P (park) This prevents the rear wheels from turning and so should be selected (together with the park brake) when leaving the vehicle. Never select P while your vehicle is still moving. The engine can be started in this position.
Page 113 Chapter 4 DRIVING MANUAL TRANSMISSION (if fitted) Shift patterns The shift pattern illustrated, is also found on the top of the gear shift lever. When selecting Reverse gear you must shift the gear lever sideways against spring pressure in order to pass into the gear. Shift speeds The chart shows the recommended change speeds at which gear changes should be...
Page 114 'ABS Fault' animation illuminate when driving, a malfunction of the Anti-lock Brake System is indicated and you should see your Holden Retailer. The vehicle's brake system will still operate conventionally, only the anti-lock operation is impaired.
Page 115 Chapter 4 DRIVING TRACTION CONTROL Traction control helps prevent the driving wheels (rear) from spinning. As soon as even one driving wheel starts to spin traction control reduces the power from the engine and applies the brakes, as necessary. This improves the vehicle's stability, particularly on snow and ice, as well as on wet or slippery roads.
Page 116 You should contact your Holden Retailer. Pressing the T/C button again switches the Tr a c t i o n system on, bringing up the 'Traction Ctrl On' C t r l O n animated display.
Page 117 Engine misfire warning Reduce speed and do not tow a caravan or trailer until the misfiring is corrected at the nearest Holden Retailer. Otherwise, the catalytic converter and exhaust system may overheat, resulting in vehicle damage. Brakes The power assisted brakes fitted to your vehicle use vacuum from the engine when it is running.
Page 118 Chapter 4 4-12 DRIVING DRIVING PRECAUTIONS cont. Loose articles Do not leave loose articles or luggage in the passenger compartment. Whenever possible, stow articles in the luggage compartment. WARNING: Gas cylinders can leak, creating a risk of fire or explosion. As a precaution, ensure adequate ventilation when carrying gas cylinders.
Page 119 Chapter 4 4-13 DRIVING ADD ON EQUIPMENT Snow chains Due to lack of clearance, snow chains cannot be fitted to wheel and tyre configurations built with your vehicle. If your vehicle needs to be driven in the snow, the owner should consider changing to the following wheel and tyre configuration: 215 / 60R16 95V 16 x 7 (for V8 and V6 engines)
Page 120 Chapter 4 4-14 DRIVING...
Page 121: Fuel
Chapter 5 FUEL Fuel Page Fuel Emission control Reducing fuel consumption Measuring fuel consumption WARNING: The Monaro has NOT been designed for conversion to LPG. The performance and safety of the vehicle would be seriously jeopardised (refer also to ‘Traction control’ in Chapter 4).
Page 122 • whenever the exhaust system, underbody or rear of the vehicle is damaged. Take the vehicle to your Holden Retailer if you think your vehicle needs inspecting for any of the above reasons. DO NOT SIT (OR LEAVE CHILDREN OR PETS) IN A PARKED VEHICLE FOR ANY EXTENDED PERIOD OF TIME WITH THE ENGINE RUNNING.
Page 123 Chapter 5 FUEL FUEL cont. Petrol – general Petrol tanks should always be filled at the intermediate or fast fill rate. Do not add any more petrol after the petrol filler first clicks off or petrol blows back – as this allows room for the petrol to expand inside the tank.
Page 124 Maintenance schedule of your vehicle's service booklet which is inside the glovebox of your vehicle. It is recommended that the necessary servicing be performed by an authorised Holden Retailer who has the specialised servicing equipment and trained personnel available to...
Page 125 Chapter 5 FUEL REDUCING FUEL CONSUMPTION Engine Maintain the engine in peak mechanical condition by having it serviced regularly in accordance with the Maintenance schedule in your vehicle's service booklet inside the glovebox of your vehicle. This will ensure items such as the spark plugs, air cleaner, engine idle speed etc.
Page 126 Chapter 5 FUEL MEASURING FUEL CONSUMPTION Before checking • Fuel consumption should not be judged until the engine has been 'run-in'. You should wait at least 1,500 km before checking fuel consumption. • Please read information on the preceding page regarding fuel consumption. •...
Page 127: Emergencies
Chapter 6 EMERGENCIES Emergencies Page Accidents Being involved Being a witness Medical assistance Flat tyre Towing a disabled vehicle 6-10 Fuses 6-12 Engine overheating 6-15 Flat battery 6-17 Airbags 6-20 Bulb replacement Your new vehicle is covered for 3 years by 24 hour Roadside Assistance.
Page 128 Chapter 6 EMERGENCIES ACCIDENTS All drivers are advised to learn what to do at the scene of an accident, particularly where people are injured. Injured people can choke to death if their air passages are not cleared, they can bleed to death unless the bleeding is stopped, they may require mouth-to-mouth resuscitation or may have to be moved, even though badly injured.
Page 129 Chapter 6 EMERGENCIES ACCIDENTS cont. Medical assistance This information is intended only as a guide to basic first aid and may not be applicable in all situations. You should always defer to a trained medical officer or other person with first aid knowledge.
Page 130 Chapter 6 EMERGENCIES FLAT TYRE WARNING: • Use the jack only for lifting the vehicle when changing wheels. • Never get beneath the vehicle when it is only supported by the jack. • Do not start or run the engine while the vehicle is only supported by the jack. •...
Page 131 Chapter 6 EMERGENCIES FLAT TYRE cont. 1. Park on a hard, level surface, in a safe location, and set the park brake firmly. Turn the hazard warning flashers on. 2. Remove the ignition key and place manual transmissions in REVERSE gear or automatic transmissions in PARK.
Page 132 Chapter 6 EMERGENCIES FLAT TYRE cont. Undo the nut in the centre of the spare wheel anticlockwise and lift the wheel out of the vehicle. The jack, combination jack handle / wheel wrench and nut cap tool (if fitted) are stored in a special container in the floor, which is tool under the spare wheel.
Page 133 Chapter 6 EMERGENCIES FLAT TYRE cont. 5. If the wheel trim covers the wheel nuts, remove as follows: If individual wheel nut caps are fitted, remove each nut cap individually, using the nut cap tool provided. Insert the nut cap tool into the nut cavity, squeeze the tool to grasp the nut cap and pull outwards to remove it.
Page 134 Chapter 6 EMERGENCIES FLAT TYRE cont. 10. Raise the vehicle until the tyre is clear of the ground. Remove the wheel nuts and place together in a dry place to avoid getting dirt in the threads. Exchange the wheel on the vehicle with the spare wheel. Note: The tyres fitted to your vehicle may have an arrow on the tyre wall, showing the direction the tyre is designed to rotate when the vehicle is moving forward.
Page 135 Chapter 6 EMERGENCIES TOWING A DISABLED VEHICLE Towing a disabled vehicle Proper lifting or towing equipment is necessary when lifting or towing the vehicle to prevent damage. State and Local laws must be followed. In an emergency, your vehicle may be towed on all four wheels in the following manner: •...
Page 136 Chapter 6 6-10 EMERGENCIES FUSES The main fuse panel is in the instrument panel, below the steering column. Pull the hinged fuse panel down to reveal the fuses. Fuse and relay panel Fuse layout diagram The separate, fuse / relay box is located in the engine compartment, marked 'Fuses'.
Page 137 Chapter 6 6-11 EMERGENCIES FUSES cont.
Page 138 Chapter 6 6-12 EMERGENCIES ENGINE OVERHEATING WARNING: Immediate action is required if the engine overheats. This can be indicated by the temperature gauge needle moving over to the 'H' or the animated warning 'Engine Temp Hot' appearing on the central display (refer to Chapter 1), by steam escaping from under the bonnet, a loss of power or a loud knocking or pinging noise.
Page 139 Chapter 6 6-13 EMERGENCIES ENGINE OVERHEATING cont. When the engine has cooled sufficiently, check the radiator level as follows. Cover the radiator cap with a thick cloth and turn it slowly anticlockwise (without pressing down) until it reaches a 'stop'. This is the pressure relief stop, which allows any remaining pressure (indicated by a hissing sound) to escape.
Page 140 This is particularly important if the engine is supercharged, as these engines have three air bleed points. It is recommended that air bleeding be done by your Holden Retailer who has the most up-to-date technical information and equipment for the system. You should have the air bled as soon as possible on supercharged engines or they may be damaged due to overheating.
Page 141 Chapter 6 6-15 EMERGENCIES FLAT BATTERY WARNING: DO NOT 'push start' or 'tow start' your vehicle, either manual or automatic. If unburnt fuel were to reach the catalytic converter and ignite, the converter could overheat or be destroyed by backfire. Therefore, if the battery is flat, you can 'jump start', but not 'push start' your vehicle.
Page 142 Chapter 6 6-16 EMERGENCIES FLAT BATTERY cont. 3. Attach one end of the RED jumper lead to the positive terminal (A) of the booster battery (identified by a red colour, + or P) and the other end of the RED jumper lead to the positive terminal (B) of the flat battery.
Page 143 Chapter 6 6-17 EMERGENCIES AIRBAGS Your vehicle is fitted with a driver's airbag, stored inside the steering wheel ('SRS AIRBAG' is stamped on the steering wheel and a label is attached under the driver's side sunvisor). Your vehicle also has a front passenger's airbag, stored in the dash panel.
Page 144 This is to indicate that the airbags are operational. If the light does not show when the ignition is switched on, or if it illuminates when driving, you should contact your Holden Retailer immediately, as the airbags and seat belt pretensioners may not function correctly in the event of an accident.
Page 145 6-19 EMERGENCIES AIRBAGS cont. The system should also be inspected by a Holden Retailer if the dashboard area or steering wheel is scratched, cracked or damaged, or, if side impact airbags are fitted, the front seats are damaged. Extensive design and testing has gone into the Holden airbag system. However, it should be treated with respect.
Page 146 Chapter 6 6-20 EMERGENCIES BULB REPLACEMENT Notes when replacing bulbs: • Always turn off the related switch. • It is important to fit only bulbs of the specified wattage. • Do not touch new bulbs or reflectors with bare hands. Greasy fingers cause stains which evaporate, eventually resulting in a dull reflector.
Page 147 Chapter 6 6-21 EMERGENCIES BULB REPLACEMENT cont. Headlights – outboard low beam (55 Watts) H11 1. Open the bonnet. Refer to 'Front lights' previously described in this chapter for access instructions. 2. Turn the outboard dust cap anticlockwise and remove from the rear of the headlight assembly.
Page 148 Chapter 6 6-22 EMERGENCIES BULB REPLACEMENT cont. Headlights – inboard high beam (65 Watts) H9 1. Open the bonnet. Refer to 'Front lights' previously described in this chapter for access instructions. 2. Turn the inboard dust cap anticlockwise and remove from the rear of the headlight assembly.
Page 149 Chapter 6 6-23 EMERGENCIES BULB REPLACEMENT cont. Front park lights (5 Watts) 1. Open the bonnet. Refer to 'Front lights' previously described in this chapter for access instructions. 2. Turn the inboard dust cap anticlockwise and remove from the rear of the headlight assembly.
Page 150 Chapter 6 6-24 EMERGENCIES BULB REPLACEMENT cont. Side turn signal (5 Watts) 1. Grasp the lens at the rear, push forwards and pull away from the body of the vehicle. Separate the bulb holder from the lens assembly by first rotating the bulb holder anticlockwise.
Page 151 Chapter 6 6-25 EMERGENCIES BULB REPLACEMENT cont. Rear turn signal (21 Watts), stop / tail (21/5 Watts), reverse (21 Watts) 1. Open the boot. 2. Remove the two screws attaching the rear quarter light assembly to the body. 3. Pull the rear quarter light assembly sideways out from the panel so that locating pegs on the side of the light assembly snap free from the clips.
Page 152 6. Install the dome lens and push back into place with your hand. Fog lights, instrument panel lights, vanity mirror lights, high mounted stop lights Bulb replacement for these light assemblies should be carried out by a Holden Retailer.
Page 153 Chapter 6 6-27 EMERGENCIES BULB REPLACEMENT cont. Footwell lights, if fitted (2.7 Watts) Socket, bulb and sheath in position Socket, bulb and sheath in position Socket, bulb and sheath in position Front footwell light bulbs are located on either side of the vehicle in the following Bulb Bulb locations:...
Page 154 Chapter 6 6-28 EMERGENCIES...
Page 155: Weekly Checks
Chapter 7 WEEKLY CHECKS Weekly checks Page Miscellaneous checks Check locations Engine oil level Engine oil consumption Engine coolant level – V6 Engine coolant level – V8 Automatic transmission level Washer fluid level 7-10 Brake fluid level 7-11 Clutch fluid level 7-12 Power steering fluid level 7-13...
Page 156 Chapter 7 WEEKLY CHECKS MISCELLANEOUS CHECKS As well as taking your vehicle to be serviced (refer to service booklet in your vehicle’s glovebox) there are a few simple, weekly checks that the owner / operator is recommended to make. These are shown on the following pages. WARNING: •...
Page 157 Chapter 7 WEEKLY CHECKS CHECK LOCATIONS V6 engine Engine coolant – V6 ..........page 7-6 Engine coolant – V8 ..........page 7-7 Windscreen washer fluid .......... page 7-9 Brake fluid .............. page 7-10 Dipstick for automatic transmission (if fitted) ... page 7-8 Engine oil cap ............
Page 158 Their use increases costs, may be detrimental to the operation of your vehicle and may void your New Vehicle Warranty, to the extent that Holden considers the non-recommended fluid to have affected the specifications or quality of your Holden vehicle.
Page 159 If, after taking into account the above factors, you are still concerned that your engine has excessive oil consumption then you should discuss the situation with a Holden Retailer. Remember that an engine’s oil consumption should not be judged until it has run at least...
Page 160 If the coolant requires topping up, mix a solution of Holden coolant and clean fresh water in a container as per the ratio specified in Chapter 8 ‘Specifications’. Pour the fluid into the dipstick tube (the same opening as the dipstick is stored in).
Page 161 If the coolant requires topping up, mix a solution of Holden coolant and clean fresh water in a container as per the ratio specified in Chapter 8 ‘Specifications’. Then, when the engine is cold, undo the cap and pour the fluid into the plastic tank.
Page 162 The level should NEVER read over the FULL HOT mark, so be careful not to add too much. If adding fluid, use only Holden specified automatic transmission fluid (refer to Chapter 8 for the correct specification). Add the fluid in the dipstick tube (the same...
Page 163 As washer fluid is constantly used the level should be topped up weekly. For a crystal clear windscreen, the correct amount of Holden washer fluid additive can be added (refer to Chapter 11 ‘Cleaning’). Do not use ordinary soap or detergent as these not only froth up but will also damage the wiper rubbers.
Page 164 OFF. Wipe clean the sides of the top cover. Then, unclip and lift off the top cover. Top up with heavy duty brake fluid which meets Holden specifications (refer to Chapter 8 for the correct specification). Remember to secure the cap at each end and clean up any spilled fluid.
Page 165 Top up with heavy duty brake fluid (both the clutch system and the brake system use brake fluid) which meets Holden specifications (refer to Chapter 8 for the correct specification). Remember to replace the cap and clean up any spilled fluid.
Page 166 Refer to Chapter 8 ‘Specifications’ for the correct power steering fluid to use. Do not over fill and remember to replace the cap tightly. If you often need to add fluid, you should see your Holden Retailer. Remember to secure the cap when the level is correct and clean up any spillage.
Page 167 / balance, tyre pressures etc. Tyre condition is checked for you when you take your vehicle to be serviced by your Holden Retailer, who is able to diagnose any unusual signs of wear. If the tyres are rotated it is recommended that the balance be checked at the same time.
Page 168 Out-of-balance wheels and tyres can cause annoying vibration and uneven tyre wear. If you suspect either of the above problems exist have a wheel alignment and balance check carried out by your Holden Retailer. Replacement and repair Replacing your factory fitted wheels and tyres with non-specified wheels and tyres may affect your warranty as well as your insurance policy.
Page 169 The fluid level of the battery will be checked for you when you take your vehicle to be serviced by your Holden Retailer. If your vehicle is operated in hot temperatures or at constant high speed the battery fluid level should be checked each month.
Page 170 Chapter 7 7-16 WEEKLY CHECKS TROLLEY JACK LOCATIONS You should always use the jack locations shown in Chapter 6 when using the original jack supplied with your vehicle. This jack has been designed to correctly and safely lift your vehicle, provided the warnings in Chapter 6 are observed.
Page 171: Specifications
Chapter 8 SPECIFICATIONS Specifications Page Specifications Lubricants and fluids Power and torque Capacities General specifications Dimensions Body lubricants Identification labels...
Page 172 Chapter 8 SPECIFICATIONS SPECIFICATIONS I I I y t i l i o i t p i f i o i t l i o f I . l i o a l i , e l , l i h t i y t i l i f...
Page 173 Rear track 1587 Body lubricants Bonnet catch NLGI No. 1 Lithium Grease (with Zinc Oxide) meeting Holden Specification HN 1225. Door hinge grease NLGI No. 1 Lithium Grease (with Zinc Oxide) meeting Holden Specification HN 1225. Check link housing NLGI No. 2 Polyurea Grease (mineral oil base) 1.2 g applied to housing.
Page 174 Chapter 8 SPECIFICATIONS IDENTIFICATION LABELS Safety Compliance Plate (Australian vehicles) Shown on the plate are the vehicle Make, Model Series, Date of Manufacture, Vehicle Identification Number (VIN), approved seating capacity, Gross Vehicle Mass (GVM) on utility and Approval Number. Body and Option Plate This plate shows model identification, Vehicle Identification Number (VIN), paint and trim colour combination, air conditioning, paint number, engine, transmission, axle ratio options, suspension options (where applicable) and build date.
Page 175 Restraint Code: 1 = seatbelts, 2 = driver and passengers, 3 = driver, 4 = driver, passenger and sides Body Style Code: 1 = Coupe Luxury Level: K = CV6, X = CV8 Model Series: 2 = V2 World Manufacturer Identifier: 6G1 = Holden...
Page 176 Chapter 8 SPECIFICATIONS...
Page 177: After Sales
Parts and accessories warranty Warranty questions answers Roadside assistance 9-10 Customer assistance 9-11 For New Zealand Holden owners 9-12 Australian Holden Retailers 9-26 New Zealand Holden Retailers Note: The names and details of Retail Premises may change after the printing of this Handbook.
Page 178 NEW VEHICLE WARRANTY CERTIFICATE New Vehicle Warranty application This Warranty is given by Holden Ltd, ABN 84 006 893 232, ('Holden'). The Warranty applies to the vehicle identified on the inside front cover of the service booklet in your vehicle’s glovebox.
Page 179 (d) use of incorrect types and grades of fuel, oil or lubricants (e) alteration of the vehicle by anyone not authorised by Holden (f) fitting of parts or accessories not recommended by Holden (g) any work carried out on the vehicle by anyone except an...
Page 180 Purchased at retail or trade • Parts and Accessories purchased at trade or retail and installed by other than a Holden Retailer or authorised Service Outlet are warranted for 1 year from the date of purchase. Please keep a receipt to support warranty claims.
Page 181 Vehicle Warranty) is required to enable your vehicle to be operated safely and it is not practical for you to go to an Authorised Holden Retailer, the service (to the extent that it is necessary to enable your vehicle to be operated safely) may be performed by any other qualified mechanic or repairer.
Page 182 Q 5. Will I have to pay for maintenance costs during the Warranty Period? Maintenance costs are not covered by the Holden New Vehicle Warranty. The Maintenance Schedules in the service booklet (in your vehicle’s glovebox) specify the minimum maintenance required for your vehicle operating under normal conditions.
Page 183 Holden Retailer it is your responsibility to deliver your vehicle to the servicing Holden Retailer’s premises. If, as a result of a defect which is covered by the Holden New Vehicle Warranty, your vehicle cannot be driven safely and you arrange for the nearest Authorised Holden Retailer to carry out the required Holden Warranty service, Holden will accept reasonable towing costs to move your vehicle to the nearest Holden Retailer’s premises.
Page 184 Australia wide. We hope the need never arises, but if it does, we’ll be there to help through Holden Roadside Assistance. How does Holden Roadside Assistance work?
Page 185 Holden Roadside Assistance stays with the vehicle, so if you sell your vehicle during the 36 month period, it is still eligible for the balance of the Holden Roadside Assistance. The new owner simply registers for the service by using the change of ownership form supplied in the Roadside Assistance booklet.
Page 186 Sales Manager or Service Manager – go to the General Manager or to the Retailer Principal. By now you should have satisfaction. If not, the Holden Customer Assistance office is at your disposal. The Holden Customer Assistance representatives can be telephoned from anywhere within Australia for only the cost of a local call.
Page 187 AFTER SALES FOR NEW ZEALAND HOLDEN OWNERS The information in this Owner's Handbook applies primarily to Australian Holden vehicles and there may be some differences to the Warranty and Owner Assistance provisions for New Zealand. Applicable details for New Zealand are set out in the Holden Warranty and Owner Assistance Information booklet enclosed in the New Zealand glovebox wallet.
Page 188 P: (02) 9642 0233 Fax: (02) 9642 7798 Hunter Holden DEE WHY 603~619 Victoria Road Peninsula Holden Dee Why P: (02) 9808 9123 Fax: (02) 9809 6592 Cnr May & Mooramba Roads ST LEONARDS P: (02) 9982 1311 Fax: (02) 9982 3755...
Page 189 Chapter 9 9-13 AFTER SALES AUSTRALIAN HOLDEN RETAILERS cont. WAITARA COBAR Suttons Motors Waitara P/L Cobar Holden 90 Pacific Hwy Cnr Lewis St & Louth Road P: (02) 9487 2222 Fax: (02) 9489 0009 P: (02) 6836 4005 Fax: (02) 6836 3409 WINDSOR COFF’S HARBOUR...
Page 190 Chapter 9 9-14 AFTER SALES AUSTRALIAN HOLDEN RETAILERS cont. FORBES KEMPSEY Frank Spice Holden Thoroughgood Holden 20~22 Dowling Street 118~132 Belgrave Street P: (02) 6851 1755 Fax: (02) 6852 2825 P: (02) 6562 1381 Fax: (02) 6562 1383 GATESHEAD KIAMA...
Page 191 Chapter 9 9-15 AFTER SALES AUSTRALIAN HOLDEN RETAILERS cont. MURWILLUMBAH TEMORA Tweed Motors Rod Lovering Holden 29 Prospero Street 607-608 Stockinbingal Road P: (02) 6672 4444 Fax: (02) 6672 5811 P: (02) 6977 2255 Fax: (02) 6977 2033 MUSWELLBROOK TENTERFIELD Upper Hunter Motors Pty Ltd Sexton &...
Page 192 P: (03) 9396 8000 Fax: (03) 9396 8001 Vic. Metropolitan FRANKSTON BACCHUS MARSH Bay City Holden Alan Mance Holden Bacchus March 140 Dandenong Road 4 Graham Street P: (03) 9784 4444 Fax: (03) 9784 4419 P: (03) 5367 4300 Fax: (03) 53674299...
Page 193 Chapter 9 9-17 AFTER SALES AUSTRALIAN HOLDEN RETAILERS cont. GLENHUNTLY SUNSHINE Booran Holden Kevin Dennis Holden 1234 Glenhuntly Road 272 Ballarat Road P: (03) 9571 9313 Fax: (03) 9571 8374 P: (03) 9292 9292 Fax: (03) 9292 9200 GLEN WAVERLEY...
Page 194 Chapter 9 9-18 AFTER SALES AUSTRALIAN HOLDEN RETAILERS cont. COHUNA LEONGATHA Hare Motors Holden Gleeson Holden 105~107 King George Street 37~43 Bair Street P: (03) 5456 4488 Fax: (03) 5456 4448 P: (03) 5662 2361 Fax: (03) 5655 1839 COLAC MANSFIELD Parker Bros.
Page 195 Chapter 9 9-19 AFTER SALES AUSTRALIAN HOLDEN RETAILERS cont. SHEPPARTON YARRAM Parker Bros. Auto Co. John Palmer Holden Benalla Road 150 Commercial Road P: (03) 5822 2666 Fax: (03) 5831 2507 P: (03) 5182 5122 Fax: (03) 5182 6166 STAWELL...
Page 196 Chapter 9 9-20 AFTER SALES AUSTRALIAN HOLDEN RETAILERS cont. SPRINGWOOD CHARTERS TOWERS Motorama Holden Peters Holden 3455 Pacific Highway 57 Mosman Street P: (07) 3804 4888 Fax: (07) 3208 7018 P: (07) 4787 1177 Fax: (07) 4787 4858 WINDSOR CHINCHILLA Eagers Holden Ainsworth Motors &...
Page 197 Chapter 9 9-21 AFTER SALES AUSTRALIAN HOLDEN RETAILERS cont. KINGAROY SOUTHPORT John Dundas Pty Ltd Lockhart Holden 79 Kingaroy Street Cnr Nerang Road & Olsen Avenue P: (07) 4162 1722 Fax: (07) 4162 3756 P: (07) 5597 2900 Fax: (07) 5597 2542...
Page 198 Chapter 9 9-22 AFTER SALES AUSTRALIAN HOLDEN RETAILERS cont. BERRI S.A. Metropolitan Rosenthal Bros Pty Ltd ADELAIDE Vaughan Terrace City Holden P: (08) 8582 3644 Fax: (08) 8582 3515 223 Grenfell Street BORDERTOWN P: (08) 8223 7666 Fax: (08) 8359 2588...
Page 199 Chapter 9 9-23 AFTER SALES AUSTRALIAN HOLDEN RETAILERS cont. MT. GAMBIER W.A. Metropolitan O.G. Roberts & Co CANNINGTON Jubilee Highway West Brian Gardner Holden P: (08) 8724 1111 Fax: (08) 8724 1100 1308~1324 Albany Hwy MURRAY BRIDGE P: (08) 9356 9000 Fax: (08) 9458 9144...
Page 200 Chapter 9 9-24 AFTER SALES AUSTRALIAN HOLDEN RETAILERS cont. BRIDGETOWN KARRATHA Kordics Bridgetown Moxham Motors 183 Hampton Street Lot 4551 Balmoral Road P: (08) 9761 1377 Fax: (08) 9761 2151 P: (08) 9144 1225 Fax: (08) 9144 1258 BROOKTON KATANNING...
Page 201 Chapter 9 9-25 AFTER SALES AUSTRALIAN HOLDEN RETAILERS cont. KARRATHA Moxham Motors Lot 4551 Balmoral Road P: (08) 9144 1225 Fax: (08) 9144 1258 KATANNING Edwards Holden 159 Clive Street P: (08) 9821 2388 Fax: (08) 9821 2429 KELLERBERRIN Dowding Motors...
Page 202 Chapter 9 9-26 AFTER SALES NEW ZEALAND HOLDEN RETAILERS GISBORNE Auckland Metropolitan Enterprise Cars (1992) Limited HENDERSON 323 Gladstone Street West City Holden P: (06) 867 8368 Fax: (06) 867 1280 435 Great North Road HAMILTON P: (09) 836 0097 Fax: (09) 837 5291...
Page 203 Chapter 9 9-27 AFTER SALES NEW ZEALAND HOLDEN RETAILERS cont. TAURANGA NELSON Nelson Bays Holden Ebbett Tauranga 2 Selwyn Place Cnr. Wharf Street & Cameron Road P: (03) 545 7222 Fax: (03) 545 6057 P: (07) 578 2843 Fax: (07) 578 6044...
Page 204 Chapter 9 9-28 AFTER SALES...
Page 205: Towing Precautions
Tow and load Page 10-2 Towing 10-3 Towing equipment 10-4 Loading the vehicle Maximum front and rear axle loads Notes on loading the vehicle Carrying gas cylinders in vehicles 10-5 Attaching a trailer 10-6 Towing and loading equipment Load distribution hitch 10-7 Towing precautions Running-in when towing...
Page 206 Holden will not accept liability for defects occurring in towing equipment not marketed by Holden or for defects in the vehicle arising from the use of such equipment or for loss or injury caused by use of such equipment. The use of such...
Page 207 Chapter 10 10-3 TOW and LOAD TOWING EQUIPMENT Essential Holden 1,600 kg rated tow bar Essential Holden trailer wiring harness Up to 1,600 kg Recommended A load distribution hitch is recommended if towing a single axle trailer / caravan that weighs more than...
Page 208 However, do not exceed the maximum axle loads shown below in the diagram, including the weight of any fitted Holden approved accessories. If unsure, the vehicle should be weighed at a weighbridge. Remember that weight on a roof rack must be included in calculating the total load.
Page 209 The coupe and trailer are now correctly loaded, as this weight within the 54 kg limit. 2. Ensure the weight of the packed trailer is not greater than the towing capacity of your Holden approved tow bar package. 3. Connect the trailer to the vehicle.
Page 210 Chapter 10 10-6 TOW and LOAD TOWING AND LOADING EQUIPMENT Load distribution hitch • A load distribution hitch is recommended when towing more than 750 kg. • A load distribution hitch is designed to raise the rear of the vehicle and transfer a portion of the load to the front wheels when the loaded trailer / caravan is hitched.
Page 211 0.21 cc of fluid during braking. It must not be fitted to the front brake system, only to the rear brake system. While no recommendation is made by Holden with regard to the manufacturer of the brake system, the specifications issued by PBR indicate that their unit meets Holden requirements.
Page 212 Chapter 10 10-8 TOW and LOAD TOWING PRECAUTIONS cont. Running-in when towing It is recommended that you drive your new vehicle for at least 1,500 km before towing. If you must tow before this do not exceed 80 km/h. The same applies if you have a new or reconditioned engine, transmission or rear axle.
Page 213 Chapter 10 10-9 TOW and LOAD NOTES...
Page 214 Chapter 10 10-10 TOW and LOAD...
Page 215: Cleaning
Chapter 11 11-1 CLEANING Cleaning Page 11-2 Interior cleaning Upholstery Suede door trim Vinyl Cloth Carpet Leather Seat belts Interior glass 11-4 Exterior cleaning Caring for paint Paint inspection Washing your vehicle Removing stains Door drain holes Polishing Tyres Alloy wheels Glass cleaning –...
Page 216 Chapter 11 11-2 CLEANING INTERIOR CLEANING WARNING: Many cleaners may be toxic, flammable or may damage the interior. When cleaning the interior, avoid volatile cleaners such as: acetone, lacquer thinners, enamel reducers, nail polish removers, or cleaners such as laundry soaps, bleaches or reducing agents. Never use carbon tetrachloride, petrol or naphtha for any cleaning purpose.
Page 217 Clean leather every 3 months with Holden Leather Cleaner or a mild saddle soap and a damp soft cloth to remove in-ground dirt which is not visible. Allow leather to dry naturally and apply Holden Leather Protector or a colourless bee's wax dressing.
Page 218 Do not use a sponge or cloth yet. 5. Fill a bucket with luke warm water and add no more than 2 capfuls of gentle detergent, such as Holden Hi Suds Car Wash. Do not use hot water, strong soap or chemical detergents.
Page 219 Chapter 11 11-5 CLEANING EXTERIOR CLEANING cont. WARNING: Care should be taken when moving the vehicle after washing, in case water has affected the brakes. Applying the brakes lightly will indicate whether they have been affected. To dry them quickly, lightly apply the brakes while maintaining a slow forward speed with a clear area ahead, until brake performance returns to normal.
Page 220 However, the use of a good quality Polymer Glaze, such as Holden Quick and Easy Speed Finish, about every 3 months will reduce the effects of road bloom by removing natural contaminants which can build up on the paint.
Page 221 The blades can be cleaned by lifting them off the windscreen and cleaning with Holden Optikleen and a clean cloth.
Page 222 Chapter 11 11-8 CLEANING CLEANING PRODUCTS e f i o i t o i t t l a e f i o i t o i t t l a , r u , y r i n i , s t .
Page 223 Chapter 11 11-9 CLEANING NOTES...
Page 224: Index
INDEX ABS ........... 4-8 Battery ..........6-15 ABS warning light ......1-7 Disconnection ......7-15 Accessories ........3-13 Flat ..........6-15 Accessory control ..... 1-32, 3-13 Fluid level ........7-15 Battery saver ....1-32, 3-13 Jump starting ....... 6-15 Power socket ....... 3-17 Battery saver ........
Page 225 INDEX cont. Cooling system ......... 7-6 Engine temperature Car key ..........2-2 warning light ......1-10 Caravan, towing ......10-2 Fluid level ........7-6 Carbon monoxide, warning ....5-2 Low coolant warning light ... 1-10 CD ........... 1-39 Temperature gauge ....... 1-4 Remote controls ......
Page 226 INDEX cont. Dimmer, instrument lights ....1-36 Turn signals ......... 1-12 Dipstick ..........7-4 Flat battery ........6-15 Doors Flat tyre ..........6-4 Key ..........2-2 Flooded engine ......... 4-3 Lock ..........2-4 Fluid levels ........7-10 Lock knobs, interior ....... 2-5 Automatic transmission ....
Page 227 INDEX cont. Generator warning light ....1-6 Interior lights ......3-12, 6-26 Globe replacement ......6-20 Boot ..........6-27 Glovebox ......... 3-14 Bulb replacement ......6-26 Boot lock release button ..... 2-11 Console bin ......... 6-27 Key ..........2-2 Courtesy lamp ......3-12 Dome ...........
Page 228 INDEX cont. Tail lights ........6-25 Consumption ......... 7-5 Turn signals ......... 1-14 Dipstick .......... 7-4 Loading capacity ......10-4 Level check ........7-4 Locks Low pressure warning light ... 1-9 Bonnet ......... 2-12 One-direction tyres ......6-4 Boot lock ........2-11 Options menu, instrument panel ..
Page 229 INDEX cont. Speed warning preset ..1-17, 1-23 Speedometer ........1-4 Radiator ..........7-6 Steering Radio ..........1-39 Power steering ......4-11 Personal identification number ... 1-40 Tilt ..........1-14 Radio display ....... 1-29 Stopwatch ........1-19 Remote controls ......1-41 Storage compartments ....
Page 230 INDEX cont. Load distribution hitch ....10-6 Cleaning ........11-6 Precautions ......... 10-7 Flat, changing ........ 6-4 Trailer, towing ......... 10-2 Grip ..........4-12 Transmission Inflation pressure ......7-13 Automatic ........4-4 One-direction ......... 6-4 Fluid level, automatic ....7-8 Replacement and repair .....
Page 231 INDEX cont. Washer fluid ........7-9 Water crossing ........ 4-12 Wheel ..........6-7 Alignment ........7-14 Change .......... 6-7 Chocks .......... 6-7 Nuts ..........6-7 Spare ..........6-7 Trim ..........6-7 Wheel changing ........ 6-7 Wheel nuts ........6-7 Wheel trim ......... 6-7 Windows .........

HOLDEN Monaro V2 II 2003 Series Owner's Handbook Manual

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for HOLDEN Monaro V2 II 2003 Series

Summary of Contents for HOLDEN Monaro V2 II 2003 Series

Table of Contents
