Page 1 WAGON AND LIGHT COMMERCIAL VZ Wagon and Light Commercial Owner’s Handbook...
Page 2 GM Holden Ltd, ABN 84 006 893 232 (hereinafter Holden) Change of name, address or ownership In the event of a Safety Recall, or for various reasons, Holden may need to contact you as the owner of this vehicle. Also, if less than three years old, this vehicle will qualify for Roadside Assistance, refer to Chapter 6.
Page 3 Dashboard Locks Know your vehicle Driving Fuel Emergencies Weekly checks Specifications Tow and load .. Cleaning Index ............*The asterisk signifies equipment options not in all vehicles (model variants, engine options, optional equipment and Genuine Holden Parts and Accessories).
Page 4 Please note that all information, illustrations and specifications in this Handbook are based on the latest production information available at the time of printing. Holden reserves the right to make changes at any time 'Nithout notice and without incurring any obligation.
Page 5: Table Of Contents
Emission control systems Reducing fuel consumption Chapter 2 Locks Chapter 6 Emergencies Keys Customer assistance Door locks For New Zealand Holden owners Alarm Roadside assistance Ignition lock Flat tyre Child safety and Towing a disabled vehicle free turning door locks Fuses...
Page 6 CONTENTS cont Chapter 8 - Specifications Chapter 10 -Cleaning Specifications Interior cleaning General specifications Exterior cleaning Identification labels Cleaning product Chapter 9 - Tow and load Loading the vehicle Towing Towing equipment Attaching a trailer Towing precautions...
Page 7 NOTES...
Page 9: Layout Gauges
1-46 Standard heater, air conditioner notes 1-48 Ventilation system 1-49 Climate control 1-54 Climate control notes 1-56 Cruise control *The asterisk signifies equipment options not in all vehicles (model variants, engine options, optional equipment and Genuine Holden Parts and Accessories.
Page 10 Chapter 1 DASHBOARD LAYOUT Page Glovebox 3-25 ............... Cup holders * 3-29 .
Page 11 Chapter 1 DASHBOARD G98301001...
Page 12 Chapter 1 DASHBOARD GAUGES Speedometer Lower luxury levels The speedometer shows vehicle speed in kilometres per hour (km/h). Tachometer The tachometer shows engine speed in thousands of revolutions per minute (rpm). Fuel gauge The fuel gauge shows the level of fuel in the fuel tank when the ignition is switched on;...
Page 13 Z150R083 welcome screens displaying the Holden logo and finishing with the 'HOLDEN SYSTEM CHECK OK!' screen. Note: Invoke the Options menu by pressing the MODE button while switching the ignition on. The system check continues to run in the background.
Page 14 'CheckAiternator' animation illuminate while driving, it Check . indicates the alternator is not charging properly. Contact your Holden Dealer. Alternator The 'Check Alternator' animation displays until the MODE button on the trip computer Z150R026...
Page 15 (§) If the warning light and 'ABS Fault' animation illuminate when driving, a malfunction of theABS is indicated. Contact your Holden Dealer. T he vehicle's brake Fault system will still operate conventionally with the anti-lock operation disabled. Refer to Z150R025 Chapter 4.
Page 16 Chapter 7. Do not run the engine when this warning is illuminated. If the oil level is normal, have the system checked at the nearest Holden Odometer Dealer. The 'Check Oil' animation displays until the...
Page 17 Contact your Holden Dealer immediately. The SRS warning light illuminates after an accident where the pretensioners, or pretensioners and airbag(s), have activated.
Page 18 If the light illuminates when driving, the emission system may require servicing. Although the vehicle may still be drivable and not require towing, consult the nearest Holden dealer as soon as possible. However, if the light flashes while driving, reduce speed until the light stops flashing and take the vehicle to a Holden dealer as soon as possible.
Page 19 If the 'Fuel Gauge Error Contact Dealer' animation illuminates while driving, a fault Fuel Gauge Error in the fuel level measurement system is indicated. Contact your Holden Dealer as Contact Dealer soon as possible. � The 'Fuel Gauge Error' animation displays...
Page 20 Service Error animation illuminates while driving, a fault Contact Dealer in the instrument panel is indicated. Contact your Holden Dealer as soon as possible. The 'Service Error' animation displays until Z150R067 the MODE button on the trip computer switch is pressed. The animated symbol...
Page 21 Fault s e r in the vehicle's immobiliser module is indicated. The vehicle will not start with an immobiliser fault. Contact your Holden Z150R129 Dealer to have the fault rectified. The 'lmmobiliser Fault' animation displays until the MODE button on the trip computer Odometer switch is pressed.
Page 22: Warning Indicators I Messages
Chapter 1 1-14 DASHBOARD WARNING INDICATORS I MESSAGES cont. Rest reminder This feature reminds the driver that he or Rest she may have been travelling for too long without a break. The rest reminder appears Reminder only after all warning displays, system check displays and Options menu selections have Z150R063 been completed.
Page 23: Turn Signals
Chapter 1 15 DASHBOARD TURN SIGNALS. HORN AND TILT I REACH STEERING Turn signals The turn signals lever is on the right side of the steering column. To signal a turn, push the lever in the same direction you turn the steering wheel.
Page 24: Trip Computer- Single-Window
1-16 Chapter 1 DASHBOARD TRIP COMPUTER- SINGLE-WINDOW Trip computer switches The buttons for the trip computer are located to the left of the gauges. The single-window for the trip computer is located directly beneath the gauges. Tap the MODE button to scmll between the different sets of displays.
Page 25 Chapter 1 17 DASHBOARD TRIP COMPUTER- SINGLE-WINDOW cont. TAP MODE BUTTON Distance I time to At the start of a trip, estimate the distance 30km to arrival from maps or road signs for . Tap the T or .A. button until the to Go 0 20 m1ns...
Page 26 Chapter 1 1-18 DASHBOARD TRIP COMPUTER SINGLE-WINDOW cont. TAP MODE BUTTON Overs peed T he overspeed sets the speed you do not want to exceed. For example, if driving in 0/Speed km/h a 60 km/h zone, set overspeed to 60, by tapping the Tor_., button.
Page 27 Chapter 1 1 19 DASHBOARD TRIP COMPUTER- SINGLE-WINDOW cont. Overspeed presets Instead of adjusting the overspeed up and Overs peed down in 5 km increments (see previous BOkm/h page), you can set four commonly used speeds, for example 60, 80, 100 and �...
Page 28 Refer to the service booklet in the glovebox. The Service due message is reset when your Holden Dealer services the vehicle. Trip computer notes: lf the wrong buttons are accidentally pressed causing the window to show anything other than normal, switch the ignition off then on again when the vehicle is stationary.
Page 29 Chapter 1 21 DASHBOARD TRIP COMPUTER- TRIPLE-WINDOW Depending on the luxury level, the vehicle is fitted with either a single-window trip computer or a triple-window trip computer. An explanation regarding the single-window trip computer can be found previously in this chapter. The buttons for the trip computer are located to the left of the gauges.
Page 30 Chapter 1 1-22 DASHBOARD TRIP COMPUTER- TRIPLE-WINDOW cont. AVG FUEL Odometer SPEED S 9 . 6 km/h U100km 12.6 012,689 km � Z150R086 Average speed Odometer Average fuel Shows the average speed Records kilometres travelled Shows average fuel used while the engine is running since the vehicle was built.
Page 31 Chapter 1 1 2 3 DASHBOARD TRIP COMPUTER- TRIPLE-WINDOW cont. TAP MODE BUTTON FUEL TIME TO ARRIVAL Dist to Arrival REMAINING 12:3Y SOOkm � Z150R084 Time to arrival* Distance to arrival* Remaining fuel* Shows trip time to arrival in At the start of a trip, estimate Shows the litres of fuel left in hours and minutes, based your distance to arrival...
Page 32 Chapter 1 1-24 DASHBOARD TRIP COMPUTER- TRIPLE-WINDOW cont. INST FUEL Dist to Empty 0/SPEED 1 Q km/h 1 2 . LJ U 100km 420km � Z150ROB5 Overs peed Dis tance to empty Instantaneous fuel (excl ve hicle) The overspeed sets the Shows instantaneous fuel speed you do not want to consumption in litres per...
Page 33 Chapter 1 1 25 DASHBOARD TRIP COMPUTER- TRIPLE-WINDOW cont. Overspeed presets Instead of adjusting overs peed up and down in 5 km increments (see previous page), you can set four commonly used speeds. For example 60, 80, 100 and 110 km/h. Hold down the MODE button for 2 seconds Normal overspeed when the overspeed display is shown.
Page 34 Chapter 1 1-26 DASHBOARD TRIP COMPUTER- TRIPLE-WINDOW cont. TAP MODE BUTTON Digital speedometer* When the digital speedometer is enabled from the Options menu, the vehicle's speed is also displayed numerically on the instrument cluster's centre display. Z150R143 TAP MODE BUTTON Stop watch* The stop watch function, when enabled,...
Page 35 Refer to the service booklet in the glovebox. The Service due message is reset when your Holden Dealer services the vehicle. Trip computer notes: If the wrong buttons are accidentally pressed, causing the display to show anything...
Page 36 Chapter 1 1-28 DASHBOARD OPTIONS MENU The Options menu allows you to customise some of the vehicle features using the trip computer switch and display. Note: Only features that are fitted to the vehicle are displayed. Entering options menu The options menu can be displayed when Options Menu the vehicle is stationary or moving slowly.
Page 37 Chapter 1 1 29 DASHBOARD OPTIONS MENU cont. Navigating the menu To scroll through the different customisable features, press the MODE button. To change the setting, use the T and • buttons. To continue, press the MODE button. To exit the options menu perform one of the following: a.- Press the MODE button to scroll through to the exit screen.
Page 38: Trip Computer - Triple Window
Chapter 1 1-30 DASHBOARD OPTIONS MENU cont. Dist to go default DIST TO GO The distance to go can be reset (when not DEFAULT in the options menu) by pressing the SET � 500km button for less than 2 seconds. The distance resetsto500 km, which isthe default setting.
Page 39 Chapter 1 3 1 DASHBOARD OPTIONS MENU cont. Confirmation beeps This option is used to enable or disable CONFIRMATION the audio system confirmation beeps. This BEEPS function is explained further in the Audio [Q1il System Handbook located in the glovebox. �...
Page 40 Chapter 1 1-32 DASHBOARD OPTIONS MENU cont. Auto headlights sensitivity This option is used to adjust the automatic headlights on sensitivity. This function is � Normal explained further on in this chapter. Use the T or _. button to adjust the sensitivity setting to 'Early', 'Normal' or 'Late' (Default Z150R112 = Normal).
Page 41 Chapter 1 1 33 DASHBOARD OPTIONS MENU cont. Auto lock in drive (automatic transmission only) This option is used to enable or disable � .L:::. .. the automatic door locking when in "Drive" function. This function is explained in detail in Chapter 2.
Page 42: Wipers And Washers
Chapter 1 1-34 DASHBOARD WIPERS AND WASHERS The lever on the left of the steering column controls the wipers and washers, which operate when the ignition is switched to the On or Accessories positions. Wipers and washers Never operate the wipers on dry glass, as this will damage the rubber and scratch the glass.
Page 43: Lights
Chapter 1 1 35 DASHBOARD LIGHTS All lights off. Park lights Dimmer- i nstru me nt Turns on the park, tail, l i ghting rear licence plate and The instruments are automatically instrument panel lights. illuminated when the park lights are switched on.
Page 44 Chapter 1 1-36 DASHBOARD LIGHTS cont. Automatic headlights When the headlight switch is in the AUTO position, the headlights and park lights automatically switch off and on with the ignition switch or through the approach lighting feature, refer to 'Headlights on when approaching the vehicle' below. High and low beam selection must still be manually controlled.
Page 45 Chapter 1 1 37 DASHBOARD LIGHTS cont. Headlights and dimming instruments note When the headlights are switched on, the instruments are automatically illuminated. Once the instruments are illuminated, the driver has the ability to adjust the brightness (see previous page). Some illuminated areas of the vehicle have been linked to the brightness control (for example, the trip computer, headlight switch and radio).
Page 46: Phone
If the call sounds unusually distorted, the volume setting on the phone itself may need to be adjusted until the sound quality is improved. Contact your Holden Dealer, authorised Blaupunkt agent or mobile phone installer for further information.
Page 47 Chapter 1 1 39 DASHBOARD RADIO I CD AND CLOCK Radio, CD and clock Detailed information on the operation of the radio and CD is provided by the Audio System Handbook in the glovebox. Operating information for adjusting time, adjusting the antenna height, Personal Identification Number (PIN) and remote control of the radio via the steering wheel is provided on these pages.
Page 48: Radio I Cd And Clock
Keep a copy of the PIN with other important documents. If the Security Card is lost and the PIN is not recorded elsewhere, the PIN can be requested from your Holden Dealer, after supplying the proof of ownership. There may be a nominal charge for this service.
Page 49: Remote Radio I Cd Controls
Chapter 1 41 D ASHBOARD REMOTE RADIO I CD CONTROLS Remote controls for the radio I CD are provided by buttons located on the left and right side of the steering wheel centre pad. Left side Right side Press the MODE button to alternate Press the VOL •...
Page 50: Antenna
1-42 Chapter 1 DASHBOARD ANTENNA The best reception is gained when the antenna is fully extended. However, to guard against breaking or bending the antenna, it may need to be retracted (for overhanging trees or car wash). Different antennas are fitted to different luxury level vehicles as follows: Manual antenna* Pull up or push down by hand.
Page 51 If the mast antenna becomes bent or is broken, have a replacement antenna fitted by your Holden Dealer as the motor and I or drive mechanism can become damaged by trying to operate a bent or broken antenna. Replacement of a bent or broken mast...
Page 52: Standard Heater, Air Condotioner
Chapter 1 1-44 DASHBOARD STANDARD HEATER. AIR CONDIT IONER* Modedial Recircul ate: In t e r i o r a i r recirculated and directed back through the face-level vents. Refer to operating notes on the following page. Face: Air comes from the face-level •...
Page 53 Chapter 1 1 45 DASHBOARD STANDARD HEATER. AIR CONDI T IONER cont.* Fan dial The fan dial provides speed control of the blower fan in all mode dial positions. Air conditioning The air conditioning is switched on when the A/C switch is pressed. Press the AIC switch again to turn the air conditioner off.
Page 54: Standard Heater, Air Conditioner Notes
The system is protected by switches that guard against abnormal loads and loss of refrigerant. The compressor may switch off permanently. Have the system checked by a Holden Dealer if this occurs. Regular running: It is important that once every...
Page 55 Chapter 1 47 DASHBOARD STANDARD HEATER. AIR CONDITIONER NOTES cont.* Demisting If the side windows or windscreen fog up on a cold day: Switch on the air conditioner. Turn the fan switch to a high speed. Turn the mode dial to floor and demist blend position.
Page 56: Ventilation System
Chapter 1 1-48 DASHBOARD VENTILATION SYSTEM The vehicle features a flow-through ventilation system for comfort. Under reasonable conditions, it should not be necessary to open the windows at any time. Outside air (except when recirculate is selected) is drawn into the vehicle through the opening between the bonnet and the windscreen.
Page 57: Climate Control
Chapter 1 1 49 DASHBOARD CLIMATE CONTROL* The climate control panel is located in the centre of the dashboard. It is designed to maintain the interior of the vehicle at the desired temperature ..... Automatic operation Start the engine. Press the AUTO button if the AUTO icon is not already displayed.
Page 58 Chapter 1 1-50 DASHBOARD CLIMATE CONTROL cont.* MIN I MAX A buttons Pressing the TMIN button moves the temperature to the coldest end of the scale rC). The display shows a 'C' for cold. Subsequent pressing of the TMIN button moves the temperature back to the previous setting.
Page 59 Chapter 1 1 51 DASHBOARD CLIMATE CONTROL cont.* 0/S TEMP & A/C buttons MODE 0/5 TEMP Switches air conditioning between Tap this button to alternate the OFF and ON. display between temperature outside the vehicle and normal display. To conserve fuel, you may wish to switch the air conditioning off in cold weather.
Page 60 Chapter 1 1-52 DASHBOARD CLIMATE CONTROL cont.* RECIRCULATION Switches air intake to recirculated air. The recirculation symbol is shown on the display when recirculation is selected. Note: Recirculate reuses interior air and is therefore not recommended for long periods of time. The recirculate position should not be used if occupants are smoking.
Page 61 1 53 Chapter 1 DASHBOARD CLIMATE CONTROL cont.* Press or .& on the fan switch to increase or decrease the fan speed. Five manual fan speeds are available. When the fan is adjusted manually, the fan blade Z150R166 graphics fill according to the fan speed, for speeds F1 to F4.
Page 62 The system is protected by switches that guard against abnormal loads and loss of refrigerant. If the compressor switches off permanently, Have the system checked by a Holden Dealer. Automatic transmission If the vehicle is stopped for long periods in hot weather with the engine running and the...
Page 63 Something wrong? The X symbol illuminates on the display when there is a fault in the system. Contact your Holden Dealer who has the necessary equipment to diagnose the system. Sensors The climate control uses three different sensors to maintain the desired temperature.
Page 64: Cruise Control
Chapter 1 1-56 DASHBOARD CRUISE CONTROL The cruise control maintains the vehicle's speed without you having your foot on the accelerator pedal. For safety reasons, the cruise control cannot be activated until the foot brake has been operated at least once after the ignition has been switched on.
Page 65 Chapter 1 57 DASHBOARD CRUISE CONTROL cont. To pause the cruise control Depress the brake pedal, or press the clutch pedal (if the vehicle is fitted with a manual transmission) or press the ON-OFF I CANCEL switch once. This deactivates the cruise control.
Page 66 Chapter 1 1-58 DASHBOARD...
Page 67: Locks
Alarm Ignition lock 2-10 Child safety and free turning door locks 2-11 Tailgate lock - wagon 2-12 Bonnet lock The asterisk signifies equipment options not in all vehicles (model variants, engine options, optional equipment and Genuine Holden Parts and Accessories).
Page 68: Keys
Chapter 2 LOCKS KEYS Key (main) T his key operates all locks and ignition, except for the glovebox. Glovebox key The glovebox key locks and unlocks the glovebox. This key can usually be kept in the unlocked glovebox. When leaving the vehicle and master key with a car park attendant you can lock valuables in the glovebox and take the glovebox key with...
Page 69 VIN (PSN) vehicle. If a key is lost, a replacement can XX-XXXXX IGNITION KEY No. XXXX RADIO P.I.N. be ordered through any Holden Dealer XXXX SECURITY CODE. by quoting the key code number, security SCM SECURITY NUMBER. )()()()()( XXXX GLOVE BOX No.
Page 70: Door Locks
Chapter 2 LOCKS DOOR LOCKS Lock Doors are locked when the lock knob is down. Automatic vehicles: Vehicles fitted with an automatic transmission have an 'Auto lock in drive' feature which locks the doors automatically when the transmission selector is shifted out of park. This feature can be selected from the instrument panel Options menu, refer to 'Options Menu' in Chapter 1.
Page 71 Chapter 2 LOCKS DOOR LOCKS cont. To disengage deadlock Press UNLOCK on the key (within 4 metres of the vehicle). This unlocks the doors. Note: Disengaging the deadlock occurs when unlocking the doors in the normal way. Unlock UNLOCK once unlock driver's Press the UNLOCK button on the key within oor;...
Page 72 On, then Off again and remove. Try pressing LOCK on the key again. If it still does not work a replacement key may be needed from your Holden Dealer. if, for any reason, pressing the key buttons does not 'vVork, the doors can be locked and unlocked by turning the key in the driver's door lock.
Page 73: Alarm
Chapter 2 LOCKS ALARM Switching on and off The alarm system is switched on when the LOCK button on the key is pressed, and switched off when UNLOCK is pressed. Therefore, locking the doors by pressing LOCK not only locks all the doors but (after a short delay) also sets the alarm system. When set off The alarm is triggered when any of the doors or the bonnet are opened or a 'hot-wire' attempted;...
Page 74 Chapter 2 LOCKS ALARM cont. Notes about the alarm: The alarm system is turned off and on when the UNLOCK and LOCK buttons on the key are pressed. When the alarm system is switched on, turning the key in the lock and then opening the doors triggers the alarm.
Page 75: Ignition Lock
Chapter 2 LOCKS IGNITION LOCK WARNING: Do not switch the engine off while the vehicle is moving as there would not be any power assist for brakes or steering. Never remove the key while the vehicle is moving, as this would lock the steering.
Page 76: Child Safety And Free Turning Door Locks
The force required to make the key free turn reduces each time. As the force gets easier with each free turn, please do not attempt to demonstrate or test this feature, and always remember to fully insert the key when locking and unlocking the doors. If you have problems contact your Holden Dealer.
Page 77: Tailgate Lock- Wagon
2 11 Chapter LOCKS TAILGATE LOCK- WAGON WARNING: To prevent dangerous exhaust fumes entering the vehicle, close the tailgate when the engine is running. If it is necessary to leave the tailgate open (while carrying bulky cargo) close all windows, switch heater controls to 'fresh' and set fan to highest speed. The tailgate is locked when the doors are locked, and unlocked when all the doors are unlocked.
Page 78: Bonnet Lock
2-12 Chapter 2 LOCKS BONNET LOCK To open From the driver's side of the vehicle, pull the lever towards you, as illustrated. T his allows the bonnet to release but is prevented from opening by the safety catch. To open completely, reach under the centre of the bonnet and move safety catch upwards.
Page 79 Chapter 2...
Page 80 2-14 Chapter 2 LOCKS...
Page 81: Know Your Vehicle
Fuel filler release 3-30 Rear tray I tailgate latches 3-31 Tonneau cover 3-36 Hard Tonneau cover 3-38 Sports bar The asterisk signifies equipment options not in all vehicles (model variants, engine options, optional equipment and Genuine Holden Parts and Accessories).
Page 82: Front Seat Adjustment
Chapter 3 KNOW YOUR VEHICLE FRONT SEAT ADJUSTMENT WARNING - SIDE IMPACT AIRBAGS (SlAB) *= Do not fit unauthorised seat covers as they may impair the deployment of the Side Impact Airbags (SlAB). Do not position your body or any object (including pillows) between front seats and doors.
Page 83 Chapter 3 KNOW YOUR VEHICLE FRONT SEAT ADJUSTMENT cont. Dual switch type Two switches are fitted to these types of seats. The front switch is used to electrically adjust the height, tilt and movement of the seat forward and backward. The rear switch is used to electrically adjust the angle of the back of the seat.
Page 84: Rear Seat- Wagon
Chapter 3 KNOW YOUR VEHICLE REAR SEAT- WAGON Wagon rear seat Some wagon models have an armrest provided in the middle of the rear seat. To fold down the armrest, insert your hand into the top of the armrest and pull down. The armrest should always be tucked back up into the seatback when folding the seatback forwards.
Page 85: Rear Seat Fold Down- Wagon
Chapter 3 KNOW YOUR VEHICLE REAR SEAT FOLD DOWN- WAGON The rear seat is divided into two sections. Either section or both sections may be folded down. To fold down a section: Press the lock button located on the upper edge of the seat. Pull the seatback forward and down.
Page 86: Third Row Seat- Wagon
Chapter 3 KNOW YOUR VEHICLE THIRD ROW SEAT- WAGON* A third row seat provides seating for two children. Each position is supplied with its own seat belt. WARNING: The seat must not be used by a child heavier than 38 kg. The seat must not be in the stowed position when using the child restraint anchorage( s).
Page 87 Chapter 3 KNOW YOUR VEHICLE THIRD ROW SEAT- WAGON cont.* To store the seat: Remove the head restraints by pushing in the clip at the base ofthe head restraint Hook and removing the head restraint. Storage Strap Fold down both seatbacks as described to Pin above.
Page 88: Rear Seat- Crew Cab
Chapter 3 KNOW YOUR VEHICLE REAR SEAT- CREW CAB Lifting the rear seat cushion crew cab T he rear seat cushion lifts up to provide access to the jacking equipment and storage tray. Press the lock button on the front of the cushion to release the seat (as illustrated).
Page 89: Seat Belts
Chapter 3 KNOW YOUR VEHICLE SEAT BELTS sash belts To fasten, pull the metal tongue across your body and clip it into the buckle. When the metal tongue is locked safely into place you will hear a 'click'. After fastening, settle the belt at the hip, and run your hand under the sash from hip to shoulder to ensure the belt fits comfortably and is free from twists.
Page 90 If the SRS light comes on at any other time, or if the warning 'SRS Airbag Fault' is displayed on the instrument panel, contact your Holden Dealer immediately to have the system checked, refer to Chapter 1 for further information about warnings and reminder indications.
Page 91 Chapter 3 3 11 KNOW YOUR VEHICLE SEAT BELTS cont. Seat belts work for everyone, including pregnant women. Like all occupants, they are more likely to be seriously injured if they do not wear a seat belt. A pregnant woman should wear a lap I sash belt with the lap portion of the belt worn as low as possible below the rounding of their stomach, throughout the pregnancy.
Page 92: Which Type Of Child Restraint
Chapter 3 3 12 KNOW YOUR VEHICLE WHICH TYPE OF CHILD RESTRAINT FOR YOUR CHILD? Children should be restrained at all times and fitted with a child restraint appropriate to their size when travelling in a vehicle. Following are some guidelines about selecting the appropriate restraint for your child.
Page 93: Child Restraints
All wagons are fitted with one child restraint anchor in the centre position. Additional anchor fittings may be installed at the other anchorage points in your vehicle as shown on this page. Fittings may be purchased from your Holden Dealer.
Page 94 If you wish to put a child restraint in either of the outer positions, first remove the cover plug. Then, install the additional anchor fitting using the bolt and washer, as illustrated. Ensure the bolts are securely tightened to between 15 and 25 Nm (Newton metres). Check with your Holden Dealer if unsure. Wagon attaching...
Page 95 The following illustrations show how the anchorage fitting was fitted on the vehicle, in case it may have been removed. Ensure the bolts are securely tightened to between 15 and 25 Nm (Newton metres). Check with your Holden Dealer if unsure. Utility...
Page 96 3 16 Chapter 3 KNOW YOUR VEHICLE CHILD RESTRAINTS cont. Anchor fitting (Crew cab) T he vehicle is fitted with three child anchorage points with permanent anchor fittings behind the rear seat, as shown in the following illustrations. To access an anchor fitting: Remove the seatback insert from the desired position.
Page 97: Windows
Chapter 3 3 17 KNOW YOUR VEHICLE WINDOWS Manual windows * Turn the winders on each door to raise or lower the window. Power windows The main window switches are located between the front seats. The switches are operational when the ignition is turned on or the UNLOCK button on the key is pressed.
Page 98: Mirrors
3 18 Chapter 3 KNOW YOUR VEHICLE MIRRORS Internal rear-view mirror Moving the lever on the lower edge of the mirror reduces headlight glare from following vehicles when driving at night. During daylight driving, the lever should be set forward, away from the driver. At night, flick the lever towards the driver.
Page 99 Chapter 3 3 19 KNOW YOUR VEHICLE MIRRORS cont. Vanity mirror with cover* On some models, a vanity mirror with a cover is provided on the driver's sunvisor. Slide the cover to the right to view the mirror. Vanity mirror with light* On higher luxury model vehicles a vanity mirror is provided on both the passenger's and driver's side sunvisors.
Page 100: Interior Lights
3 20 Chapter 3 KNOW YOUR VEHICLE INTERIOR LIGHTS Interior (dome) light The interior light is located either in the centre of the roof (utility) or in the front roof console (crew cab I wagon). The interior light can be switched to any of the following positions: �...
Page 101 Chapter 3 3 21 KNOW YOUR VEHICLE INTERIOR LIGHTS cont. Rear compartment light (Wagon) The light illuminates when the tailgate is open and automatically switches off when the tailgate is closed.
Page 102: Accessory Control
3 22 Chapter 3 KNOW YOUR VEHICLE ACCESSORY CONTROL The vehicle is equipped with an accessory control feature that can be set at the instrument panel to shut down all accessories (radio, power socket, wipers, for example) either when the ignition key is switched to the Off position, or when the driver's door is opened, refer to Chapter 1, 'Options Menu' for details about this setting.
Page 103: Battery Saver
Chapter 3 3 23 KNOW YOUR VEHICLE BATTERY SAVER A battery saver feature has also been built into the vehicle to ensure that all internal lights (for example dome, ignition and glovebox) will switch off automatically after one hour to discourage depletion of your battery. The battery saver will activate when there have been no lights or accessories switched on for one hour after the ignition has been switched off.
Page 104: Glovebox And Centre Console
3 24 Chapter 3 KNOW YOUR VEHICLE GLOVEBOX AND CENTRE CONSOLE Glovebox T he glovebox, is located in the dashboard directly in front of the passenger seat. A specific key is provided solely to lock and unlock the glovebox. For security, the master key is not designed to operate the glovebox lock, refer to Chapter 2 for more information.
Page 105: Storage Compartments
Chapter 3 3 25 KNOW YOUR VEHICLE STORAGE COMPARTMENTS Front and rear storage compartments * The vehicle may come with both front and rear storage compartments. The front storage compartment is beneath the radio system and is fitted with a 'push-push' cover.
Page 106 3 26 Chapter 3 KNOW YOUR VEHICLE STORAGE COMPARTMENTS cont. Storage tray (Crew cab) There is a storage tray located under the rear seat cushion, on the right-hand side. To access the storage tray, refer to 'Lifting the rear seat cushion' previously in this chapter.
Page 107: Ashtray
If required, the vehicle can be fitted with an ashtray and lighter instead of front and I or rear storage compartments. Your Holden Dealer can order and fit the ashtray and lighter for you. Ashtray* The ashtray is fitted with a 'push-push' cover.
Page 108: Cup Holders
Chapter 3 3 28 KNOW YOUR VEHICLE CUP HOLDERS* Front cup holders- centre* T he centre cup holders are located forward of the centre console. T he cup holder bin may be covered by a telephone storage tray* which is removable to allow access to the cup holders.
Page 109: Park Brake
The footrest for the driver's left foot is adjustable to three positions. First remove the caps and undo the two screws on the right hand side of the footrest. Move the footrest forward or backward as required, then replace the screws and caps. Contact your Holden Dealer for assistance with this adjustment if necessary.
Page 110: Rear Tray Tailgate Latches
3 30 Chapter 3 KNOW YOUR VEHICLE REAR TRAY I TAILGATE LATCHES To lower Reach inside, at the middle of the tailgate and move the lever to the left. The tailgate support c a b l e can b e disconnected, i f required.
Page 111 Chapter 3 3 31 KNOW YOUR VEHICLE TONNEAU COVER Installing the tonneau cover Remove the contents of the tonneau cover bag. Installing bows Your vehicle is supplied with two bows and four bow attachments. Bow attachments will normally remain on the vehicle. However, if the bow attachments have been removed, they can be reinstalled by tilting and clipping into place as shown.
Page 112: Tonneau Cover
3 32 Chapter 3 KNOW YOUR VEHICLE TONNEAU COVER cont. Fitting tonneau cover to front bar Normally, the front bar would remain attached to the tonneau cover. However, if the bar has been removed, it will need to be attached before the tonneau cover is fitted to the vehicle.
Page 113 Chapter 3 3 33 KNOW YOUR VEHICLE TONNEAU COVER cont. 10. Fold the magnetic strip forward. 11 . Lay the tonneau cover over the bows. 12. Starting from the rear, use the finger loops to pull the tonneau cover plastic strip over the slot provided in the vehicle.
Page 114 3 34 Chapter 3 KNOW YO U R VEHICLE TONNEAU COVER cont. Removing tonneau cover Using the finger loops provided, remove the tonneau cover as shown. The bows can then be removed by pulling straight up. For your convenience the bows and tonneau cover can be folded and stored in the bag provided.
Page 115 Chapter 3 3 35 KNOW YOUR VEHICLE TONNEAU COVER cont. Roll up the tonneau cover, starting from the point of the triangle. Note: Folding and rolling in this way ensures the plastic sides are not bent. Z170R051 Place the folded tonneau cover and bows in the bag provided.
Page 116: Hard Tonneau Cover
3 36 Chapter 3 KNOW YOUR VEHICLE HARD TONNEAU COVER* Locking and unlocking To lock the tonneau, lower it to its closed position. Insert the key into the lock and while applying slight downward pressure near the lock, turn the key clockwise. Repeat on both sides.
Page 117 Chapter 3 3 37 KNOW YOUR VEHICLE HARD TONNEAU COVER cont. Removal of tonneau (Crew cab) Open the tonneau cover. With the aid of an assistant, remove the retaining clip from the top of each gas strut where they are attached to the tonneau.
Page 118: Sports Bar
3 38 Chapter 3 KNOW YOUR VEHICLE SPORTS BAR* Sports bar* Note: The sports bar is an appearance item only. It does not provide additional protection in an accident and should not be used as a tie down point for loads.
Page 119 Chapter 3 3 39 KNOW YOUR VEHICLE NOTES...
Page 120 3 40 Chapter 3 KNOW YOUR VEHICLE...
Page 121: Driving
Automatic transmission 4-11 Manual transmission 4-12 Antilock brake system 4-13 Traction control system 4-15 Driving precautions 4-17 Add on equipment The asterisk signifies equipment options not in all vehicles (model variants, engine options, optional equipment and Genuine Holden Parts and Accessories).
Page 122: Safety
Chapter 4 DRIVING Before entering the vehicle Check that windows, mirrors and lights are clean. Visually check tyre inflation. Note: It is recommended the tyre pressures are checked with a pressure gauge each week. Before driving away Ensure that all doors are closed and secured. Position your seat for comfortable driving.
Page 123: Engine Starting
Note: If the 'lmmobiliser Fault' animation illuminates while attempting to start the vehicle, a fault in the vehicle's immobiliser module is indicated. The vehicle will not start with an immobiliser fault. Contact your Holden Dealer to have the fault rectified.
Page 125: Automatic Transmission
Chapter 4 DRIVING AUTOMATIC TRANSMISSION cont.* Note: If any warnings are active on the display, the large animation will not be shown and only the bracketed smaller icon at the bottom middle of the display changes when the transmission gear selector is moved. WARNING: Do not press the accelerator pedal with the brakes on in any gear except P (park) or N (neutral).
Page 126 Chapter 4 DRIVING AUTOMATIC TRANSMISSION cont.* The P W R button is located on the passenger's side of the centre console, next to the transmission gear selector. Press the PWR button to place the transmission in Power shift mode. Press the PWR button again to select Normal shift mode.
Page 127 Chapter 4 DRIVING AUTOMATIC TRANSMISSION cont.* The active select (AIS) mode button is located on the driver's side of the centre console. Press the AIS button to select active select mode. Note: AIS mode can only be enabled when the transmission gear selector is in the drive (D) position.
Page 128 Chapter 4 DRIVING AUTOMATIC TRANSMISSION cont.* Note: Safeguards have been programmed into active select mode preventing the transmission from changing down to a lower gear if the speed of the vehicle exceeds the maximum for the gear selected by the driver. The transmission will not change up to a higher gear if the vehicle speed is too slow for the selected gear.
Page 129 Chapter 4 DRIV I N G AUTOMATIC TRANSMISSION cont.* Four-Speed P (park) This prevents the rear wheels from turning and so should be selected (together with the park brake) when leaving the vehicle. Never select P while the vehicle is still moving. The engine can be started in this position.
Page 130 4-10 Chapter 4 DRIVING AUTOMATIC TRANSMISSION cont.* Five-speed This prevents the rear wheels from turning and so should be selected P (park) (along with the park brake) when leaving the vehicle. Never select P while the vehicle is moving. The engine can be started in this position. R (reverse) Never select R while the vehicle is still moving.
Page 131: Manual Transmission
4 11 Chapter 4 DRIVING MANUAL TRANSMISSION* Shift patterns 6-speed manual - V6 engine The manual transmissions fitted to vehicles with V6 and V8 engines have six forward gears and one reverse gear. The shift pattern illustrated is also found on the top of the gear shift lever.
Page 132 4-12 Chapter 4 DRIVING ANT/LOCK BRAKE SYSTEM The antilock brake system (ABS) is in addition to the vehicle's normal brake system. It continually monitors the vehicle's braking system and prevents the wheels from locking up when braking, irrespective of the road conditions and tyre grip. It starts to regulate the braking as soon as a wheel shows a tendency to lock.
Page 133: Traction Control System
Note: If the Traction Ctrl Off' animation illuminates while driving, a fault is indicated in the system and the TCS is no longer operational. Have your Holden Dealer check the system as soon as possible.
Page 134 Note: If the 'Traction Ctrl Off' animation does not display when the TIC button is pressed, a fault is indicated in the system and traction control may be no longer be operational. Have your Holden Dealer check the system as soon as possible. button again switches...
Page 135: Driving Precautions
Engine misfire Reduce speed and do not tow a caravan or trailer until the misfiring is corrected at the nearest Holden Dealer. Otherwise, the catalytic converter and exhaust system may overheat, resulting in vehicle damage. Power assisted brakes The power assisted brakes fitted to the vehicle use vacuum from the engine when it is running.
Page 136 4-16 Chapter 4 DRIVING DRIVING PRECAUTIONS cont. Loose articles Do not leave loose articles or luggage in the passenger compartment. Whenever possible, stow articles in the rear load area. Loads stowed in the rear load area should be firmly secured. WARNING: Gas cylinders can leak,...
Page 137: Add On Equipment
Chapter 4 4 17 DRIVING ON EQUIPMENT Snow chains Due to lack of clearance, snow chains cannot be fitted to vehicles equipped with the following wheel and tyre configurations: 215 I 65 R 16C 106 R 16 x 7 235 I 45 R 17 93 V 17 x 8 225 I 55 R 16 95 V...
Page 138 Fitting roo/nudge bars If a roo/nudge bar is to be fitted, it is critical the Holden approved roo/nudge bar be used. Other types must not be fitted. The Holden roo/nudge bar is available from your Holden Dealer and has been compatibility tested with the vehicle's design, including the Holden airbag system.
Page 139 Chapter 4 4-19 DRIVING...
Page 140 4 20 Chapter 4 DRIVING...
Page 141: Fuel
LPG. Holden approved LPG powered vehicles have a specially designed engine that is fitted at the assembly plant. The asterisk signifies equipment options not in all vehicles (model variants, engine options, optional equipment and Genuine Holden Parts and Accessories).
Page 142 Take the vehicle to your Holden Dealer if you think your vehicle needs inspecting for any of the above reasons. Do not sit (or leave children or pets) in a parked vehicle for any extended period of time with the engine running.
Page 143 LPG. Holden approved LPG powered vehicles have a specially designed engine that is fitted at the assembly plant. For specific details of the approved Holden LPG system please refer to the LPG Wagon supplement provided for this option.
Page 144: Emission Control Systems
Maintenance Schedule of the vehicle's service booklet which is stored inside the vehicle's glovebox. It is recommended necessary servicing be performed by an authorised Holden Dealer who has the specialised servicing equipmeni and trained personnel available to ensure...
Page 145: Reducing Fuel Consumption
Chapter 5 FUEL REDUCING FUEL CONSUMPTION Engine To keep the engine in peak mechanical condition, have it serviced regularly in accordance with the Maintenance Schedule of the vehicle's service booklet which is stored inside the vehicle's glovebox. This ensures items such as the spark plugs, air cleaner and engine idle speed are maintained for minimum fuel usage and peak engine performance.
Page 146 Chapter 5 FUEL...
Page 147: Emergencies
Flat battery 6-21 Airbags 6-24 Bulb replacement Your new vehicle is covered for 3 years by 24 hour Roadside Assistance. The asterisk signifies equipment options not in all vehicles (model variants, engine options, optional equipment and Genuine Holden Parts and Accessories).
Page 148: Customer Assistance
Sales Manager or Service Manager - go to the General Manager or to the Dealer Principal. By now you should have satisfaction. If not, the Holden Customer Assistance office is at your disposal. The Holden Customer Assistance representatives can be telephoned from anywhere within Australia for only the cost of a local call.
Page 149: For New Zealand Holden Owners
Warranty and Owner Assistance provisions for New Zealand. Applicable details for New Zealand are set out in the Holden Warranty and Owner Assistance Information booklet enclosed in the New Zealand glovebox wallet.
Page 150: Roadside Assistance
Australia wide. We hope the need never arises, but if it does, we'll be there to help through Holden Roadside Assistance. How does Holden Roadside Assistance work?
Page 151 Holden's warranty can be claimed by contacting your local Holden Dealer. What happens if I sell my vehicle? Holden Roadside Assistance stays with the vehicle, so if you sell your vehicle during the 36 month period, it is still eligible for the balance of the Holden Roadside Assistance.
Page 152 Chapter 6 EMERGENCIES HAZARD WARNING FLASHERS Hazard warning flashers Press the switch (as shown) to switch the hazard warning flashers on and off. T he hazard warning flashers work regardless of the ignition position. When switched on, all turn signals flash continuously.
Page 153: Flattyre
Chapter 6 EMERGENCIES FLATTYRE WARNING: All passengers must be out of the vehicle when it is being jacked. Do not jack a vehicle with a trailer attached, remove the trailer first. Only jack the vehicle on hard, level surfaces. Use the jack only at the designated lifting points. Use in other locations may result in the vehicle falling off the jack, or damage to the vehicle.
Page 154 Chapter 6 EMERGENCIES FLAT TYRE cont. Utility Utility Nut cap too The jacking tools are stored behind the passenger's seat. Move the passenger's seat forward to access the jacking tools. Remove the jack, combination jack handle I wheel wrench and spare wheel hoist handle from behind the seat by unscrewing the nut on the retaining bracket and lifting them out...
Page 155 Chapter 6 EMERGENCIES FLAT TYRE cont. Utility and Crew cab Remove the spare wheel as follows: At the rear of the vehicle, insert the hoist • handle through the round hole near the number plate (crew cab shown). Note for crew cab: Pull out the blanking cover in the rear bumper bar to access the hole for the hoist handle.
Page 156 6-10 Chapter 6 EMERGENCIES FLAT TYRE cont. Wagon Open the tailgate, pull up the floor cover and secure it out of y our way with a hook. T he hook is provided underneath the cover. Unclip the hook and attach it to the weather-seal.
Page 157 6-11 Chapter 6 EMERGENCIES FLAT TYRE cont. Fit the jack handle onto the jack by sliding the open end of the handle over the nut end of the jack. WARNING: Failure to position the jack as described below could cause the vehicle to slip off the jack.
Page 158 6-12 Chapter 6 EMERGENCIES FLAT TYRE cont. The front (all vehicles) and rear (utility only) location are marked by half circle cutouts on the vehicle. The rear jack locations on both the utility and crew cab have a raised ridge for mating with the jack head. Note: Always read the label on the jack.
Page 159 6-13 Chapter 6 EMERGENCIES FLAT TYRE cont. 15. Stow all tools and flat tyre as shown previously. Note: When winding the hoist handle clockwise to return the spare wheel to its stored position, there may be a 'tight spot' as the spare tyre nears the top. It is important that this 'tight spot' is not mistaken for the fully raised position.
Page 160: Towing A Disabled Vehicle
6-14 Chapter 6 EMERGENCIES TOWING A DISABLED VEHICLE Towing a disabled vehicle Proper lifting or towing equipment is necessary when lifting or towing the vehicle to prevent damage. State laws must be followed. In an emergency, the vehicle may be towed on all four wheels as described in this section. Fit the towing equipment to the holes at the side of the front cross member.
Page 161 Chapter 6 6-15 EMERGENCIES The main fuse panel is in the instrument panel, below the steering column. Pull the hinged fuse panel down to reveal the fuses. Fuse and relay panel Fuse layout diagram Cabin fuses and relays ACC CTRL RELAY FLASHER UNIT 1 �...
Page 162: Fuses
6-16 Chapter 6 EMERGENCIES cont. FUEL PUMP (15A) ENGINE COOLING ECM/TCM/BCM FAN RELAY RELAY 2 TELE (V6,V8) (10A) & START R.H. HEADLAMP RELAY (20A) L.H. HEADLAMP (20A) AUTO TRANS (15A) ENGINE SSR 1 (15A) INJIIGN ODD (15A) �g� �� 1 �...
Page 163: Engine Overheating
While your vehicle is fitted with this function, it is advisable to stop the vehicle as soon as it is safe to do so and take the vehicle to the nearest Holden Dealer. WARNING: After driving in the overheated engine protection mode and to avoid engine damage, allow the engine to cool before attempting any repair.
Page 164 Air bleeding should be done if a significant amount of coolant has been added, otherwise the engine may overheat. It is recommended that air bleeding be done by your Holden Dealer who has the most up-to-date technical information and equipment for the system.
Page 165: Flat Battery
Please read the following procedure in full before attempting to jump start the vehicle. If, after reading the following procedure, you are still unsure about 'jump starting' Holden strongly recommends for your safety and that of the vehicle that you seek the assistance of a competent mechanic.
Page 166 6-20 Chapter 6 EMERGENCIES FLAT BATTERY cont. Attach one end of the RED jumper lead to the positive terminal of the booster battery (identified by a red colour, and the other end of the RED jumper lead to the positive terminal of the flat battery.
Page 167: Airbags
6-21 Chapter 6 EMERGENCIES AIRBAGS The vehicle is fitted with a driver's airbag, stored inside the steering wheel. 'SRS AIRBAG' is stamped on the steering wheel and a label is attached under the driver's side sunvisor. The v e h icle may also have a front passenger's airbag, stored in the dashboard.
Page 168 This is illuminate when the ignition is switched on, or if it illuminates when driving, you should contact your Holden Dealer immediately, as the airbags and seat belt pretensioners may not function correctly in the event of an accident.
Page 169 Always sit centrally in the seat. Always wear your seat belt. The system should also be inspected by a Holden Dealer if the dashboard area or steering wheel is scratched, cracked or damaged, or, if side impact airbags are fitted, and the front seats are damaged.
Page 170 6-24 Chapter 6 EMERGENCIES BULB REPLACEMENT Notes when replacing bulbs: Always switch off the related switch. It is important to fit only bulbs of the specified wattage. Do not touch new bulbs or reflectors with bare hands. Greasy fingers cause stains which evaporate, eventually resulting in a dull reflector.
Page 171 Chapter 6 6-25 EMERGENCIES BULB REPLACEMENT cont. Higher luxury models Headlights- outboard low beam Open the bonnet. Refer to 'Front lights' previously described in this chapter for access instructions. Turn the outboard dust cap anti clockwise and remove from the rear of the headlight assembly.
Page 172: Bulb Replacement
Chapter 6 6-26 EMERGENCIES BULB REPLACEMENT cont. Higher luxury models Headlights - inboard high beam Open the bonnet. Refer to 'Front lights' previously described in this chapter for access instructions. Turn the inboard dust cap anticlockwise and remove from the rear of the headlight assembly.
Page 173 6-27 Chapter 6 EMERGENCIES BULB REPLACEMENT cont. Higher luxury models Front park lights (5 Watts) higher luxury models Open the bonnet. Refer to 'Front lights' previously described in this chapter. Remove the park light bulb holder by turning it anticlockwise and pulling it straight out.
Page 174 6-28 Chapter 6 EMERGENCIES Side turn signal (5 Watts) Grasp the lens at the rear, push forward and pull away from the body of the vehicle. Separate the bulb holder from the lens assembly by first rotating the bulb holder anticlockwise.
Page 175 Chapter 6 EMERGENCIES BULB REPLACEMENT cont. Fog lights*' instrument panel lights Bulb replacement for these light assemblies should be carried out by a Holden Dealer. Utility & Crew Open the tailgate. From inside the rear tray, remove the rear light cover screws and remove the rear cover.
Page 176 6-30 Chapter 6 EMERGENCIES Rear tailight wagon Open the tailgate. Carefully remove the rearlighttrim cover with a flat-blade screwdriver. R o t a t e the required b u l b h o l d e r anticlockwise and pull outward. T h e bulb holders are colour coded as follows, and the sequence from the top downward White- Reverse (clear bulb)
Page 177 6-31 Chapter 6 EMERGENCIES BULB REPLACEMENT cont. Number plate (5 Watts) Push the locking tang at the end of the lamp housing toward the lens and pull the lamp assembly downward. Remove the bulb holder from the lamp housing by rotating the bulb holder anticlockwise.
Page 178 6-32 Chapter 6 EMERGENCIES BULB REPLACEMENT cont. Install the new bulb and ensure both ends of the bulb are firmly in place. Carefully install the lens on to the assembly, ensuring it snaps into place. Check if the lens is flush with the lamp assembly. Front reading- dome (8 Watts*) Front reading lights for some models of vehicle are fitted in the dome light assembly.
Page 179 6-33 Chapter 6 EMERGENCIES BULB REPLACEMENT cont. Console bin (5 Watts-*) Wagon load area (10 Watts) Gently prise away the lens housing with a fine flat-bladed screwdriver. Pull the tab holding the bulb (opposite end to wiring) backward and pull the bulb out.
Page 180 6 34 Chapter 6 EMERGENCIES...
Page 181: Weekly Checks
Brake fluid level Clutch fluid level 7-11 Power steering fluid level 7-12 7-13 Tyres Battery 7-16 Trolley jack locations 7-17 The asterisk signifies equipment options not in all vehicles (model variants, engine options, optional equipment and Genuine Holden Parts and Accessories).
Page 182: Miscellaneous Checks
Chapter 7 WEEKLY CHECKS MISCELLANEOUS CHECKS As well as taking the vehicle to be serviced (refer to the service booklet in the vehicle's glovebox) there are a few simple, weekly checks the owner I operator is recommended to make. These are shown on the following pages. WARNING: If the engine temperature is high, the cooling fan may remain on for several minutes after switching off the ignition.
Page 183: Check Locations
Chapter 7 WEEKLY CHECKS CHECK LOCATIONS Battery page 7-16 0windscreen washer fluid ..............page 7-9 &Brake fluid page 7-10 ................... . . &clutch fluid (if manual transmission*) ..........
Page 184: Engine Oil Level
Their use increases costs, may be detrimental to the operation of the vehicle and may void the New Vehicle Warranty, to the extent that Holden considers the non-recommended fluid to have affected the specifications or quality of the vehicle. Engine oil change intervals...
Page 185: Engine Oil Consumpion
If, after taking into account the above factors, you are still concerned that your engine has excessive oil consumption then consult your Holden Dealer. Remember that an engine's oil consumption should not be judged until it has run at least 10 000 km.
Page 186: Engine Coolant Level
Refer to Chapter 8, Specifications, for engine coolant specifications and water-to coolant ratio. Mix a solution of Holden coolant and clean fresh water in a container as per the ratio specified. Note: Failure to use the coolant or maintain the specified concentration may result in voiding the New Vehicle Warranty.
Page 187 Chapter 7 WEEKLY CHECKS ENGINE COOLANT LEVEL cont. The specified coolant works in three ways: It contains special corrosion inhibitors. It helps the cooling system in hot weather by increasing the boiling point. It protects against freezing down to -3rC, provided the specified concentration is maintained.
Page 188: Automatic Transmission Fluid Level
To add transmission fluid Use only Holden specified automatic transmission fluid. Refer to Chapter 8, Specifications for the correct type. Add fluid to the transmission through the dipstick tube (the same opening as the dipstick is stored in).
Page 189: Washer Fluid Level
As washer fluid is constantly used, top up the level weekly. For a crystal clear windscreen, the correct amount of Holden washer fluid additive can be added. Refer to Chapter 10, Cleaning. Note: Do not use ordinary soap or detergent as these not only froth up but also damage the wiper rubbers.
Page 190: Brake Fluid Level
To add brake fluid Ensure the ignition is switched off. Wipe the sides of the cap clean and remove the cap. Top up with heavy duty brake fluid which meets Holden specifications. Refer to WARNING: Use only new brake fluid. Use of...
Page 191 To add clutch fluid Ensure the ignition is switched off. Wipe clean the sides of the cap and remove the cap. Top up with heavy duty brake fluid which meets Holden specifications. Refer to Chapter 8, Specifications, for the correct specification. WARNING: Use only new fluid.
Page 192: Power Steering Fluid Level
Top up with power steering fluid which meets Holden specifications. Do not overfill the reservoir. Secure the cap and clean up any spilled fluid. Note: If the power steering fluid requires constant topping up, it could indicate that a fault exists. Contact your Holden Dealer.
Page 193: Tyres
Chapter 7 7 13 WEEKLY CHECKS TYRES Air pressure Tyre Placard Weekly checking of the air pressure of the tyres (including the spare) ensures your safety, as well as reducing fuel consumption and increasing the life of the tyres. For constant long distance or rough road driving, daily checking is recommended.
Page 194 Tyre condition is checked when the vehicle is serviced by a Holden Dealer. They are able to diagnose any unusual signs of wear. If the tyres are rotated it is �...
Page 195 Chapter 7 7 15 WEEKLY CHECKS TYRES cont. Tyres should be replaced when: They are worn to the point where the tread indicators appear, or the cord or Tread wear indicator fabric is showing. The tyres originally fitted to the vehicle have built-in tread indicators.
Page 196: Battery
Fluid level check The fluid level of the battery is checked when the vehicle is serviced by a Holden Dealer. If the vehicle is operated in hot temperatures or at constant high speed the battery fluid level should be checked each month.
Page 197: Trolley Jack Locations
Chapter 7 7 17 WEEKLY CHECKS TROLLEY JACK LOCATIONS Note: Always use the jack locations shown in Chapter 6, Emergencies, when using the original jack supplied with the vehicle. This jack has been designed to correctly and safely lift the vehicle, provided the warnings in Chapter 6, Emergencies, are observed. WARNING: Do not jack under the suspension control arms.
Page 198 Chapter 7 7 18 WEEKLY CHECKS...
Page 199 Power and torque Capacities Specifications V8 Lubricants and fluids Power and torque Capacities General specifications Dimensions Body lubricants Identification labels The asterisk signifies equipment options not in all vehicles (model variants, engine options, optional equipment and Genuine Holden Parts and Accessories).
Page 200 6.4 litres approximately (including the filter) capacity Rear differential oil Synthetic Hypoid Gear Oil SAE 80W-140, such as Mobil Mobilube SHC ID or equivelant lubricant to Holden specification number HN2040, 1.7 litres approximately Coolant specification 50% clean fresh water and 50% extended life anti-freeze...
Page 201 6.2 litres approximately (including the filter) capacity Rear differential oil Synthetic Hypoid Gear Oil SAE 80W-140, such as Mobil Mobilube SHC ID or equivelant lubricant to Holden specification number HN2040, 1.7 litres approximately Coolant specification 50% clean fresh water and 50% extended life anti-freeze...
Page 202 Chapter 8 SPECIFICATIONS GENERAL SPECIFICATIONS Dimensions (mm) Utility - Base Utility- 5V6 Utility- 55 5052 Length 5058 5058 Width (with mirrors) 2046 2046 2046 1487 1488 Height 1457 2939 2939 Wheel base 2939 Front overhang 1174 1176 Rear overhang 1176 1569 Front track- steel wheels 1559...
Page 203 Body lubricants Area Lubricant Bonnet catch NLGI No. 1 Lithium Grease (with Zinc Oxide) meeting Holden Specification HN 1225 Door hinges NLGI No. 1 Lithium Grease (with Zinc Oxide) meeting Holden Specification HN 1225 Check link housing NLGI No.2 Polyurea Grease (mineral oil base) 1.2 g...
Page 204 Chapter 8 SPECIFICATIONS IDENTIFICATION LABELS Safety Compliance label Shown on the label are the vehicle Make, Model Series, Date of Manufacture, Vehicle Identification Number (VIN), approved seating capacity, Gross Vehicle Mass (GVM) on utility and Approval Number. Cooling system I air conditioning label This label shows the warnings for the air conditioning and cooling system as well as...
Page 205 4 = active belts with driver, passenger and side airbags Body Style: 4 = Utility, 3 = Crew cab, 8 = Wagon Luxury Level: K =Base models, S, SV6, SS, L = Berlina Model Series: Z = VZ World Manufacturer Identifier: 6 = Oceania G = Australia 1 =Holden...
Page 206 Chapter 8 SPECIFICATIONS...
Page 207 Cargo barrier 9-11 Vertical convenience net 9-12 Cargo blind 9-13 T ie downs 9-15 Convenience net 9-16 Load anchoring warnings The asterisk signifies equipment options not in all vehicles (model variants, engine options, optional equipment and Genuine Holden Parts and Accessories).
Page 208 Chapter 10 TOW and LOAD LOADING THE VEHICLE Maximum front and rear axle loads Do not exceed the maximum axle loads shown in the diagram, including the weight of any fitted accessories. If unsure, the vehicle should be weighed at a weigh bridge. This ensures the vehicle's axles have sufficient strength to carry the total weight of body and mechanicals, plus cargo and passengers, and still retain a considerable capacity safety margin to cope with weight transfer as the vehicle brakes, accelerates, corners and goes...
Page 209 Chapter 1 0 TOW and LOAD LOADING THE VEHICLE cont. Roof racks* Distribute the load evenly and secure tightly with straps so that it can not slip. Roof rack loads alter the handling of a vehicle, due to a change in the centre of gravity. When carrying loads on the roof rack, avoid hard braking, abrupt swerving or sharp steering.
Page 210 V ehicle Warranty, to the extent that Holden considers the non-recommended equipment affects the specifications or quality of your Holden vehicle. It is not advisable to mix and match different brands of towing equipment, as equipment is usually designed as an...
Page 211 TOW and LOAD TOWING EQUIPMENT TOW LOAD ESSENTIAL EQUIPMENT RECOMMENDED EQUIPMENT Holden 1600 kg rated tow bar Holden trailer wiring harness A load distribution hitch is recommended if towing Electric or hydraulic brakes on the Up to a single axle trailer that...
Page 212 Ensure the weight of the packed trailer is not greater than the towing capacity of the Holden approved tow bar package. Running-in when towing It is recommended the new vehicle be driven for at least 1500 km before towing. If the vehicle must tow before this do not exceed 80 km/h.
Page 213 It must not be fitted to the front brake system, only to the rear brake system. While no recommendation is made by Holden with regard to the manufacturer of the brake system, the specifications issued by brake manufacturer PBR indicate...
Page 214 Chapter 10 TOW and LOAD CARGO BARRIER * The cargo barrier has been designed to fit at two positions. It can be fitted behind the rear seats when they are upright, or behind the front seats when the rear seat is folded down.
Page 215 Chapter 1 0 TOW and LOAD CARGO BARRIER cont. * Behind front seats - with rear seat folded WARNING: It is recommended to correctly anchor the load in the rear cargo area, even if the cargo barrier is in position. Note: When fitting the cargo barrier behind the front seats, the long straps and centre legs are required.
Page 216 Do not attach (drill, rivet, stick and so forth) objects to the front or rear of the cargo The maximum load for a genuine Holden cargo barrier is 60 kg single mass. That is, if an object weighs 60 kg, only one object is permitted behind the cargo barrier.
Page 217 Chapter 10 9-11 TOW and LOAD VERTICAL CONVENIENCE NET* The vertical convenience net has been designed to fit behind the rear seats to help contain light objects stored in the rear cargo area. Fitting vertical convenience net Unroll the vertical convenience net. Place the vertical convenience net directly behind the rear seat.
Page 218 Chapter 10 9-12 TOW and LOAD CARGO BLIND The cargo blind is located in the rear compartment of the wagon. When the blind is required, it can be extended to provide protection from the sun and added security for goods stored in the back of the wagon.
Page 219 TIE-DOWNS* Recommended procedure for using tie-downs When carrying heavy loads in the cargo area, Holden recommends using the tie-down system. It is designed to hold loads in place and reduce load impact to passengers in an accident. Remove the protective strips* along the two tie-down rails running the length of the rear cargo area.
Page 220 The protective strips* should be in place. WARNING: The maximum load for the tie-down system is 80 kg single mass when used in conjunction with the Holden-approved straps. That is, if an object weighs 80 kg, only one object can be held by the tie-down system.
Page 221 CONVENIENCE NET Recommended procedure for using the convenience net Holden recommends using the convenience net when carrying light loads in the cargo area. It is designed to keep light objects in the load area tidy, not for anchoring. Remove the protective strips* along the two tie-down rails running the length of the rear cargo area.
Page 222 Unsecured loads increase the risk of injury during heavy braking, sudden avoidance manoeuvres or a collision. Use only the Holden recommended and approved tie-down straps and convenience net to secure your loads. Do not use elasticised straps. Never attach more than one tie-do\�vn strap to any single t!e-dovvn anchor.
Page 223 Chapter 10 g 17 TOW and LOAD NOTES...
Page 224 9-18 Chapter 10 TOW and LOAD...
Page 225 11 0 Cleaning Pa g e 10-2 Interior cleanin g 1 0-4 Exterior cleanin g 1 0-8 Cleanin g products The asterisk signifies equipment options not in all vehicles (model variants, engine options, optional equipment and Genuine Holden Parts and Accessories).
Page 226 Chapter 10 10-2 CLEANING INTERIOR CLEANING WARNING: Many cleaners are toxic, flammable or may damage the interior. When cleaning the interior, avoid volatile cleaners such as acetone, lacquer thinners, enamel reducers, nail polish removers, or cleaners such as laundry soaps, bleaches or reducing agents. Never use carbon tetrachloride, petrol or naphtha for any cleaning purpose.
Page 227 Do not bleach or dye seat belts as this may severely weaken them. Interior glass Clean interior glass of the vehicle using a good quality glass cleaner, such as Holden Glass Cleaner, and a clean soft cloth. Take care when cleaning inside the rear window so as not to damage the rear window demister or radio antenna.
Page 228 Do not use a sponge or cloth at this point. Fill a bucket with lukewarm water and add no more than two capfuls of gentle detergent, such as Holden Hi Suds Car Wash. Do not use hot water, strong soap or chemical detergents.
Page 229 10 1 Chapter CLEANING EXTERIOR CLEANING cont. WARNING: Take care when moving the vehicle after washing, in case water has affected the brakes. Applying the brakes lightly will indicate whether they have been affected. To dry them quickly, lightly apply the brakes while maintaining a slow forward speed with a clear area ahead, until brake performance returns to normal.
Page 230 Use a good quality glass cleaner, such as Holden Glass Cleaner, and wash each section of glass in turn, making sure the water, its container and the sponge are quite clean and free from grit. Clean, old linen cloth is better than new material for polishing glass.
Page 231 After the windscreen has been cleaned with a wet sponge, wipe it over with a soft, lint free cloth or chamois. It is recommended that a good quality windscreen washer additive, such as Holden Optikleen, be added to the windscreen washer reservoir.
Page 232 Chapter 10 10-8 CLEAN I N G CLEANING PRODUCTS Size Description Usage Part Number 92145132 237 ml Quick and Easy Seals in a deep, lustrous glazed Speed Finish finish. Long life protection from oxidation, salt and weather damage. 92145418 437 ml Quick and Easy Seals in a deep, lustrous glazed Speed Finish...
Page 233 10 1 Chapter CLEANING...
Page 234 Chapter 10 1 0 1 0 CLEANING...
Page 235 INDEX 4-12 Battery ..........6-19 ..........ABS warning light..
Page 237 INDEX cont. Dashboard Layout with climate control. 1-53 ......... . .
Page 238 INDEX cont. Ignition switch ........lmmobiliser fault 1-13 .
Page 239 INDEX cont. Mud flaps 4-17 ........Layout Dashboard .
Page 241 INDEX cont. Airbags 6-21 Trip computer - single window 1-16 ........
Page 242 INDEX cont. Water crossing ..4-16 ... . . Wheel ..........Unidirectional tyres Alignment 7-14...

This manual is also suitable for:

Vz light commercial 2006

HOLDEN VZ WAGON 2006 Owner's Handbook Manual

Quick Links

Need help?

Questions and answers

Related Manuals for HOLDEN VZ WAGON 2006

Summary of Contents for HOLDEN VZ WAGON 2006

This manual is also suitable for:

Table of Contents
