  • Page 1 JF VIVA JF Viva Owner’s Handbook...
  • Page 2 Change of name, address or ownership In the event of a Safety Recall, or for various reasons, Holden may need to contact you as the owner of this vehicle. If you have recently changed your address, or name, or purchased this vehicle second-hand, please help us to help you by taking a few minutes to fill in and mail the forms at the beginning of the Service/warranty booklet.

  • Page 3: Table Of Contents

    CHAPTERS Dashboard ........... 1A Audio system ........1B Locks ............2 Know your vehicle ........3 Driving ............4 Fuel ............5 Emergencies ...........6 Weekly checks ........7 Specifications .........8 Tow and load ..........9 Cleaning ..........10 Index...
  • Page 4 We thank you for choosing Holden and want to assure you of our continuing interest in your motoring pleasure and satisfaction and compliment you on your choice. This handbook applies to all Viva models. Due to different models and options, you may find reference in this handbook to some equipment not installed in your own vehicle.
  • Page 5 General information Care of your audio system Glossary of terms Chapter 2 – Locks Keys and keyless entry Manual operation The asterisk signifies equipment options not in all vehicles; model variants, engine options, optional equipment and Genuine Holden Accessories (and Parts).
  • Page 6 ConTEnTS cont. Chapter 6 – Emergencies Chapter 8 – Specifications Customer assistance - Australia Specifications Customer assistance - New Zealand Identification labels Flat tyre Chapter 9 – Tow and load Towing a disabled vehicle Loading the vehicle Engine overheating Towing Flat battery Fuse replacement Chapter 10 –...

  • Page 7: Dashboard

    Accessory power outlet and cigarette lighter ....1A-18 Ashtray and glovebox ....1A-19 Storage compartment and bonnet release ....1A-20 The asterisk signifies equipment options not in all vehicles; model variants, engine options, optional equipment and Genuine Holden Accessories (and Parts).
  • Page 8 1A-2 Chapter 1A DASHBOARD LAyouT J06VF0001 Page LAyouT IndEx Air outlets (side) .....................1A-16  Instrument gauges ...................1A-3  Air outlets (centre)..................1A-16  Hazard warning switch ...................1A-13  Clock ........................1A-5  Glovebox ......................1A-19  Audio system ....................1B-2  Heater and A/C controls .................1A-14 ...
  • Page 9 1A-3 Chapter 1A DASHBOARD GAuGES J06VF0002 Page LAyouT IndEx High beam lamp indicator ................1A-6  Turn signal indicators ..................1A-6  Odometer and tripmeter ...................1A-3  Trip odometer reset button ................1A-3  Speedometer ....................1A-3  Temperature gauge ..................1A-4  Fuel gauge .......................1A-4 ...
  • Page 10 1A-4 Chapter 1A DASHBOARD GAuGES cont. Temperature gauge The temperature gauge (6) indicates the temperature of the engine coolant when the ignition switch is turned to the ON position. Stop-start driving in heavy traffic, driving at high speed in warm weather, hill climbing or towing may cause the temperature to increase.
  • Page 11 1A-5 Chapter 1A DASHBOARD dIMMER And CLoCK Dimmer – instrument lighting adjust instrument lighting brightness, ensure the headlights or park lights are switched on. Turn the dimmer thumb wheel, located to the right-hand side of the steering column, to adjust the instrument lighting to the desired brightness.
  • Page 12 The oil pressure lamp illuminates when the ignition switch is turned to the ON position, and will remain illuminated until the engine is started. If the oil pressure lamp is illuminated while driving, this indicates the oil pressure is dangerously low. Stop the vehicle as soon as possible and check the engine oil level (refer to Engine oil level in chapter 7). Do not drive the vehicle with the oil pressure indicator lamp illuminated, consult your Holden Dealer. Low fuel The low fuel indicator lamp displays when the fuel tank is approaching empty. When the low fuel lamp illuminates add fuel as soon as possible. Brake The brake warning lamp displays when the ignition switch is in the ON position and the engine is not running, as a check to show you it is working properly.
  • Page 13 If the lamp comes on while driving, carefully stop the vehicle and turn off the engine. If the lamp stays on or illuminates again while driving, you should have the system checked by a Holden Dealer. Note This lamp indicates the anti-lock braking system is not operating.
  • Page 14 ON position. If the SRS warning lamp illuminates while driving, it indicates the airbag system or seatbelt pretensioner system may not function correctly, especially in an accident. Contact your Holden Dealer immediately.
  • Page 15 1A-9 Chapter 1A DASHBOARD WIPERS And WASHERS Windscreen wipers To operate the windscreen wipers, turn the ignition switch to the ON position and move the windscreen wiper/washer lever downward. The windscreen wipers operate in the following four positions: • OFF System off. Default position. •...
  • Page 16 1A-10 Chapter 1A DASHBOARD WIPERS And WASHERS cont. Rear wiper and washer To switch the rear wiper on, push the wiper lever toward the dashboard to the first position. To spray washer fluid push the stalk to the second position. J06VF0024...
  • Page 17 1A-11 Chapter 1A DASHBOARD HEAdLAMPS Lamp switch controls The lamp switch controls the following: • Headlamps • Tail lamps • Parking lamps • Number plate lamps • Instrument panel lamps Rotate the band to to switch on your parking and other operating lamps. The headlamps will not come on.
  • Page 18 1A-12 Chapter 1A DASHBOARD TuRn SIGnALS And IGnITIon SWITCH Turn signals The turn signal lever is on the right-hand side of the steering column. Push the lever up to signal a left turn and down to signal a right turn. In some turns (such as changing lanes), the steering wheel is not turned far enough to cancel the turn signal.
  • Page 19 (correctly programmed) is used. Note Any additional or replacement keys must be purchased from and programmed by a Holden Dealer. If the immobiliser system has developed a fault or an incorrectly programmed key is used in an attempt to start the vehicle, the security warning indicator lamp would illuminate.
  • Page 20 1A-14 Chapter 1A DASHBOARD HEATInG And AIR CondITIonInG SySTEM J06VF0014 Page Air temperature selector ................1A-14  Air outlet selector ...................1A-14  Fan speed selector ..................1A-14  Air conditioning switch ...................1A-15  Air recirculation switch ...................1A-15  Rear window demister switch ................1A-17 ...
  • Page 21 1A-15 Chapter 1A DASHBOARD HEATInG And AIR CondITIonInG SySTEM cont. Air conditioning switch Press this button to switch the air conditioning on. The engine must be running in order for the feature to work. Set the fan position to 1, 2, 3, or 4 to begin air circulation. An indicator light illuminates on the button when the air conditioning is in use.
  • Page 22 1A-16 Chapter 1A DASHBOARD HEATInG And AIR CondITIonInG SySTEM cont. Air outlet selector Different vents are selected when the air selector is set in the following positions: Air flows from the four face level outlets in the dashboard. The blending mode directs airflow through both the dashboard outlets and the floor outlets.
  • Page 23 1A-17 Chapter 1A DASHBOARD HEATInG And AIR CondITIonInG SySTEM cont. • Windscreen demister mode will operate with the air conditioner on or off. • Do not use the heating/demisting mode or the demisting mode in extremely humid weather when the temperature control is set to cold. •...
  • Page 24 1A-18 Chapter 1A DASHBOARD ACCESSoRy PoWER ouTLET And CIGARETTE LIGHTER Accessory power outlet The accessory power outlet is located near the ashtray in the dashboard. On the wagon model, an additional power outlet is located in the side wall of the rear cargo area.
  • Page 25 1A-19 Chapter 1A DASHBOARD ASHTRAy And GLoVEBox Ashtray The ashtray should only be used for ash, not for combustible rubbish. To empty the ashtray, pull open the ashtray, then lift the ashtray liner up and out. J06VF0058 Glovebox The glovebox is located on the passenger side of the dashboard.
  • Page 26 1A-20 Chapter 1A DASHBOARD SToRAGE CoMPARTMEnT And BonnET RELEASE Storage compartment Pull the cover downward to open the small pocket, located on the lower, driver’s side of the dashboard. J06VF0065 Bonnet release The bonnet release lever is located inside the vehicle, under the driver’s side of the dashboard.
  • Page 27 ...... 1B-14 General information ..... 1B-16 Care of your audio system ... 1B-17 Glossary of terms ....1B-19 The asterisk signifies equipment options not in all vehicles; model variants, engine options, optional equipment and Genuine Holden Accessories (and Parts).

  • Page 28: Audio System

    1B-2 Chapter 1B AUDIO AudIo SySTEM AudIo ConTRoLS Front panel CD/AUX AUX IN T250_VF_060A Display and functions: Tune and previous/next buttons Power/volume and mute rotary button Sound mode selection button SCAN/AST button INFO/DISP button Display screen Preset radio station buttons and Seek tuning buttons <...
  • Page 29 1B-3 Chapter 1B AUDIO AudIo SySTEM cont. AudIo dISPLAy SCREEn lcd layout T250 Display and layout: MP3 play mode indicator MP3/WMA disc play indicator (All directories on the disc) Radio mode indicator MP3 play mode indicator Disc insert indicator (Directory of the disc only) Weak FM signal indicator Equalizer mode indicator FM stereo ON indicator...
  • Page 30 If the Security Card is lost and the PIN Code has not been recorded, the PIN Code can be requested from your GM Holden Dealer. Proof of ownership will be requested before the PIN Code is supplied. There may be a charge for this service.
  • Page 31 1B-5 Chapter 1B AUDIO AudIo SySTEM cont. ConTRoL BuTTonS Power on When the power is OFF press the power/volume and mute rotary button  to activate the audio system. The radio, CD or MP3 function will be shown on the display screen. The operating mode will be the same as before the audio system was turned off.
  • Page 32 1B-6 Chapter 1B AUDIO AudIo SySTEM cont. Bass control Bass control is used to adjust the bass (low frequency) sound quality. 1. Select the bass control mode using the sound mode selection button  . SOUND 2. When “BAS” appears on the display screen  , rotate the power/volume and mute rotary button ...
  • Page 33 1B-7 Chapter 1B AUDIO AudIo SySTEM cont. Balance control Balance control adjusts the volume separation between left and right audio speakers. 1. Select the balance control mode using the sound mode selection button  . SOUND The display screen  will show BAL right or left depending on the last setting used. 2.
  • Page 34 1B-8 Chapter 1B AUDIO AudIo SySTEM cont. Manual tuning 1. Choose either AM or FM band using the input source buttons  . 2. Use the tune and previous/next buttons  to increase or decrease the frequency one step at a time. The frequency of the AM band changes in 9 KHz increments and the frequency of the FM band changes in 0.1 MHz increments.
  • Page 35 1B-9 Chapter 1B AUDIO AudIo SySTEM cont. Manual memory 1. Tune in the desired station using any of the tuning modes listed under “How to tune a station”. 2. Press and hold the desired preset radio station button  for longer than 2 seconds.
  • Page 36 1B-10 Chapter 1B AUDIO AudIo SySTEM cont. Cue and review This function allows desired point-search within an audio track at a faster than normal playback speed. 1. To search for the desired point within the audio track, press and hold the tune and previous/next buttons ...
  • Page 37 1B-11 Chapter 1B AUDIO AudIo SySTEM cont. Track introduction 1. To quickly and conveniently scan the CD disc for a desired audio track, press the button grouped with the preset radio station and CD/MP3 mode function buttons  . “INTRO” will appear on the display screen  and the audio system will play the first few seconds of each audio track on the CD disc.
  • Page 38 1B-12 Chapter 1B AUDIO AudIo SySTEM cont. MP3 file name display When a disc is inserted into the disc insert slot  the audio system checks which type of media, audio CD or MP3 is inserted. The type of media will appear on the display screen ...
  • Page 39 1B-13 Chapter 1B AUDIO AudIo SySTEM cont. Random play: 1. To play MP3 disc audio files in random order, press the button grouped with the preset radio station and CD/MP3 mode function buttons  . “RDM” will appear on the display screen  . By using the track search function while the audio system is in random mode, a new random play selection of audio files is initiated.
  • Page 40 1B-14 Chapter 1B AUDIO AudIo SySTEM cont. AuxILIARy ModE oPERATIon This function enables you listen to audio contents from external portable devices that are connected to the auxiliary input socket located on the front of the audio system panel. 1. Connect the output socket of the portable device to the auxiliary input socket  on the audio system front panel.
  • Page 41 1B-15 Chapter 1B AUDIO AudIo SySTEM cont. Mode button/transition FM1 > FM2 > FMA > AM1 > 1. To change the mode function using AM2 > AM-A > CD > the steering wheel remote control, press the MODE button. J06VF0212 Each time the MODE button is pressed, the mode function will change in the sequence shown.
  • Page 42 AudIo SySTEM cont. GEnERAL InFoRMATIon Audio system faults In case of faulty operation, consult your GM Holden Dealer. Antenna In some vehicles there is a rear window antenna installed. Refer to Interior lamps and antenna in chapter 3. The antenna is part of the heated rear window demister pattern.
  • Page 43 1B-17 Chapter 1B AUDIO AudIo SySTEM cont. Peculiarities of FM mobile reception A mobile FM receiver can not be expected to continuously provide the quality of FM reception you may have experienced on your home receiver. Contrary to popular opinion, FM broadcasts are not static free, and although your new radio has a built-in electronic interference absorption circuit some static will be evident from time to time especially in areas without a direct line of sight to the transmitter.
  • Page 44 1B-18 Chapter 1B AUDIO AudIo SySTEM cont. Care of your CD • Handle the CD by its edge and avoid touching the playing surface. Directly after removal from CD/MP3 slot, place the CD into the CD cover to prevent damage or soiling. •...
  • Page 45 1B-19 Chapter 1B AUDIO AudIo SySTEM cont. GLoSSARy oF TERMS Automatic station search Station search by tuner. The tuner will search until a station is found. Autostore (AS) The best receivable stations in the FM and AM wave bands can automatically be stored.
  • Page 46 1B-20 Chapter 1B AUDIO noTES...

  • Page 47: Locks

    Locks Page Keys and keyless entry....2-2 Manual operation ......2-5 The asterisk signifies equipment options not in all vehicles; model variants, engine options, optional equipment and Genuine Holden Accessories (and Parts).
  • Page 48 In the event of the original keys being lost, any additional or replacement keys must be purchased from and programmed by a Holden Dealer, using your key code number. Keyless entry using remote control The range of the remote control unit should be about 6 metres, this may be reduced due to shadowing and reflection of the radio waves.
  • Page 49 Chapter 2 LOCKS KEyS And KEyLESS EnTRy cont. Hatchback and wagon To unlock the vehicle: Press the button on the remote control unit. The indicator light (A) illuminates briefly, the vehicle hazard lamps flash twice and the doors and liftgate unlock. To lock the vehicle: Press the button on the remote control unit.
  • Page 50 Even if only one transmitter is being replaced, you must rematch all of your transmitters at the same time. Up to four transmitters can be matched to your vehicle. See your Holden Dealer to purchase a new transmitter and to have transmitters matched to your vehicle.
  • Page 51 Chapter 2 LOCKS MAnuAL oPERATIon Manual locking system To lock using the key: Insert the key in the driver’s door lock. Turn the key toward the rear of the vehicle. Allow the key to return to its vertical position for removal. To unlock using key: Insert the key in the driver’s door lock.
  • Page 52 Chapter 2 LOCKS MAnuAL oPERATIon cont. Door locks using snib The door is unlocked when the snib is pulled up. The door is locked when the snib is pushed down. All passenger doors may be locked behind you by pressing the snib down when the door is open, then shutting the door.
  • Page 53 Chapter 2 LOCKS MAnuAL oPERATIon cont. Boot release button (sedan only) The boot release button is located on the dashboard to the right of the steering wheel. Push the button to open the boot. J06VF0205 To lock: To close the boot lid, push it down until it latches securely.
  • Page 54 Chapter 2 LOCKS noTES...
  • Page 55 Interior lamps and antenna ...3-20 Sun visors, vanity mirror and assist grip ........3-21 Park brake ........3-22 Cupholders and storage ....3-23 The asterisk signifies equipment options not in all vehicles; model variants, engine options, optional equipment and Genuine Holden Accessories (and Parts).

  • Page 56: Know Your Vehicle

    Chapter 3 KNOW YOUR VEHICLE SEAT AdJuSTMEnT Driver’s seat Lift the lever to unlatch the front seat. Slide the seat as required. Release the lever. Try to move the seat back and forth to check if the catch is fully engaged. WARNING Do not adjust the driver’s seat when the vehicle is moving, as the seat...
  • Page 57 Chapter 3 KNOW YOUR VEHICLE SEAT AdJuSTMEnT cont. Driver’s seat height adjustment Turn the knobs on the outboard side of the seat to raise or lower the seat cushion. Turn the front knob to adjust the height of the front of the seat cushion and the rear knob to adjust the height of the rear of the seat cushion.

  • Page 58: Head Restraint Adjustment

    Chapter 3 KNOW YOUR VEHICLE HEAd RESTRAInT AdJuSTMEnT Adjusting the head restraints To adjust the height of the head restraint, pull up or push down while pressing the lock button in. The upper edge of the head restraint should be approximately at eye level, and not at neck level.

  • Page 59: Seatbelts

    Chapter 3 KNOW YOUR VEHICLE SEATBELTS Seatbelts To put on the retractor seatbelt, pull the metal tongue across your body and clip it into the buckle. When the metal tongue has locked safely into place you will hear a click. After fastening, settle the seatbelt by running your hand under the seatbelt starting at the hip, move your hand across to the buckle then up under the...
  • Page 60 In the event of this occurring contact your Holden Dealer. WARNING The tongue must engage and lock inside the buckle for the seatbelt to function properly.
  • Page 61 This is designed to remind you the pretensioner system has been used and therefore needs to be replaced by your Holden Dealer. The seatbelts would remain operational, apart from this safety feature.
  • Page 62 Maintenance of seatbelts Check the seatbelts regularly. Replace the seatbelts if they become frayed or damaged. The buckle and retractors mechanism operation should also be checked. Your Holden Dealer will regularly do these things as part of the scheduled maintenance plan, refer to the Service/warranty booklet.

  • Page 63: Airbags

    This indicates the airbags are operational. If the light does not blink when the ignition is switched on, or if it illuminates when driving, this may indicate there is a fault in the airbag system. Consult your Holden Dealer as soon as possible.
  • Page 64 Always sit centrally in the seat. Always wear your seatbelt. The system should also be inspected by a Holden Dealer if: • The steering wheel or dashboard area is scratched, cracked or damaged.
  • Page 65 It is recommended that any work to the electrical system, steering column, dashboard area, steering wheel or airbag system be carried out by a Holden Dealer. Bull bar Fitting a bull bar, or making other modifications to the front of the vehicle, may change the impact speed which would normally cause the airbag to inflate, reducing its effectiveness.
  • Page 66 Do not touch any airbag system components or wires. The wires can be identified by yellow tape wrapping or yellow tubing and the connectors are also yellow. Scrapping a vehicle that has an un-inflated airbag can be hazardous. Ask your Holden Dealer for assistance. WARNING •...

  • Page 67: Which Type Of Child Restraint For Your Child

    3-13 Chapter 3 KNOW YOUR VEHICLE WHICH TyPE oF CHILd RESTRAInT FoR youR CHILd? Children should be restrained at all times and fitted with a child restraint appropriate to their size when travelling in a vehicle. The following outlines guidelines about selecting the appropriate restraint.

  • Page 68: Child Restraints

    3-14 Chapter 3 KNOW YOUR VEHICLE CHILd RESTRAInTS WARNING – EXTREME HAZARD: WARNING AVERTISSEMENT ADVERTENCIA • Do not use a rearward facing child restraint on a seat protected by an airbag in front of it. • The child could be seriously injured if the airbag inflates, as the child’s head would be very close to the inflating airbag.
  • Page 69 3-15 Chapter 3 KNOW YOUR VEHICLE CHILd RESTRAInTS cont. AnCHoRAGE FITTInGS The following illustrations show the anchorage points for each model. Sedan models The top strap anchor brackets are already installed in the anchor points on the shelf behind the rear seat. The anchor brackets are installed in three positions.
  • Page 70 3-16 Chapter 3 KNOW YOUR VEHICLE CHILd RESTRAInTS cont. Wagon models For the centre rear seating position, a top strap anchor bracket has already been installed in the ceiling of the rear area. Front of vehicle J06VF0097 For the outboard seating position, top strap anchor brackets have already been installed on the floor of the rear cargo area.

  • Page 71: Mirrors

    3-17 Chapter 3 KNOW YOUR VEHICLE MIRRoRS Inside rear view mirror To adjust the rear view mirror, move the mirror right or left, up or down to gain the required angle. The anti-glare lever on the lower edge of the mirror enables the reflector to be used during night driving.

  • Page 72: Tilt Steering And Windows

    3-18 Chapter 3 KNOW YOUR VEHICLE TILT STEERInG And WIndoWS Tilt steering The tilt steering lever is located on the underside of the steering column. To adjust the height or the reach of the steering wheel, push the lever away from you, this will unlock the steering column.
  • Page 73 3-19 Chapter 3 KNOW YOUR VEHICLE TILT STEERInG And WIndoWS cont. Power windows The main switches for the power windows are located in the driver’s door. The front switches are for the front windows and the rear switches are for the rear windows Individual switches are located on the front passenger door and in the rear doors The switches for the power windows are...

  • Page 74: Interior Lamps And Antenna

    3-20 Chapter 3 KNOW YOUR VEHICLE InTERIoR LAMPS And AnTEnnA Interior lamp The dome lamp is located in the centre of the roof and is operative regardless of the ignition switch position. DOOR The lamp switches on when a door is opened and switches off when all the doors are closed.

  • Page 75: Sun Visors, Vanity Mirror And Assist Grip

    3-21 Chapter 3 KNOW YOUR VEHICLE Sun VISoRS, VAnITy MIRRoR And ASSIST GRIP Sun visors The sun visors are used to block out the sun. They can be pivoted to the side when unhooked. Vanity mirror The vanity mirror is located on the rear side of the sun visor.

  • Page 76: Park Brake

    3-22 Chapter 3 KNOW YOUR VEHICLE PARK BRAKE Park brake lever Never drive with the park brake applied, as this would overheat and damage the park brake. The park brake lever is located between the front seats. Make sure the vehicle is stationary before you apply the park brake.

  • Page 77: Cupholders And Storage

    3-23 Chapter 3 KNOW YOUR VEHICLE CuPHoLdERS And SToRAGE Cupholders To use the front cupholder in the centre console, swing the inner support forward or backward. J06VF0064 Sunglasses holder There is a storage area above the driver’s door for sunglasses. Pull down and hold the upper part of the cover to open it.
  • Page 78 3-24 Chapter 3 KNOW YOUR VEHICLE CuPHoLdERS And SToRAGE cont. Rear storage area (wagon only) The wagon model is equipped with storage compartments located in the right and left side trim panel of the rear cargo area. To open the storage compartment, pull the handle.
  • Page 79 Page Safety ..........4-2 Engine starting........4-3 Driving precautions ......4-4 Manual transmission .....4-7 Automatic transmission ....4-8 Anti-lock brake system (ABS) ..4-12 The asterisk signifies equipment options not in all vehicles; model variants, engine options, optional equipment and Genuine Holden Accessories (and Parts).

  • Page 80: Safety

    Chapter 4 DRIVING SAFETy Before entering the vehicle 1. Check that windows, mirrors and lights are clean. 2. Check if the tyres are not flat. Before driving away 1. Ensure that all doors are closed and secured. 2. Position your seat for comfortable driving. 3.

  • Page 81: Driving

    10 seconds. If the engine still does not start, release the key and pedal. Wait another 15 seconds and then repeat the entire procedure. If the engine still fails to start, contact your Holden Dealer. Engine will not crank or start Remove the key from the ignition switch, insert the key and try starting the engine again.

  • Page 82: Driving Precautions

    If the engine is misfiring, reduce the vehicle speed and do not attempt to tow a caravan or trailer, until the misfiring is corrected by the nearest Holden Dealer. Continued driving while the engine is misfiring could result in the catalytic converter and exhaust system overheating, resulting in vehicle damage.
  • Page 83 Chapter 4 DRIVING dRIVInG PRECAuTIonS cont. Loading the vehicle Loading the vehicle changes the mass distribution and therefore the handling of the vehicle when driving. After loading the vehicle, extra care should be taken to become familiar with the feel of the vehicle while driving. Refer to Tow and load in chapter 9.
  • Page 84 Chapter 4 DRIVING dRIVInG PRECAuTIonS cont. Snow chains When driving or fitting snow chains, ensure the following are observed: • Snow chains may only be used at speeds up to 50 km/h. • When driving on roads that are free of snow, snow chains should only be used for brief periods, as they will wear quickly and may snap.

  • Page 85: Manual Transmission

    • Do not over speed the engine when shifting down to the next lower gear. Clutch pedal If under normal vehicle operation the clutch pedal develops abnormal behaviour, see your Holden Dealer.

  • Page 86: Automatic Transmission

    Chapter 4 DRIVING AuToMATIC TRAnSMISSIon This system has a four-speed automatic transmission. Its shift indicators are arranged with P (park) at one end, followed in sequence by R (reverse), N (neutral) and then the forward driving ranges. To prevent the vehicle from ‘creeping’ you should always have your foot on the brake pedal when shifting out of P or N.
  • Page 87 Chapter 4 DRIVING AuToMATIC TRAnSMISSIon cont. Shifting between gear positions Movement between certain gear positions requires pushing the release button on the front of the selector grip. When the ignition is on, depress the brake pedal and push the release button on the front of the selector grip as indicated by the black/or white arrows as follows: You must apply the brake pedal and push the selector lever to the passenger side in order to shift.
  • Page 88 3. Insert the ignition key into the J06VF0115 transmission shift lock slot. 4. Shift the gear lever to N (neutral). 5. Remove the key from the slot. 6. Start engine shift transmission into the desired position. 7. Refer to your Holden Dealer as soon as possible.
  • Page 89 Lamp illuminates. In this situation, the transmission may not shift automatically, or shifting may be much harsher then normal. Have the vehicle serviced as soon as possible by your Holden Dealer. If the malfunction indicator lamp stays on after starting the engine and the transmission does not shift, see "Shift lock control system"...

  • Page 90: Anti-Lock Brake System (Abs)

    This sound can come and go, or be heard all the time when the wheels are rolling. This noise may stop when the brake pedal is pushed down firmly. Consult your Holden Dealer and have your brakes checked if you hear this noise. Extensive damage can result if the linings are not replaced when needed.

  • Page 91: Fuel

    Fuel Page Fuel..........5-2 Fuel filling ........5-3 Petrol – emission control ....5-4 Reducing fuel consumption ....5-5 The asterisk signifies equipment options not in all vehicles; model variants, engine options, optional equipment and Genuine Holden Accessories (and Parts).
  • Page 92 – whenever the exhaust system, underbody or rear of the vehicle is damaged. • Take the vehicle to your Holden Dealer if you think your vehicle needs inspecting for any of the above reasons. • Do not sit (or leave children or pets) in a parked vehicle for any extended period of time with the engine running.
  • Page 93 Chapter 5 FUEL FuEL FILLInG To release the fuel filler door, pull up on the release lever. The release lever is located near the front corner of the driver’s seat. Remove the fuel cap by turning it anticlockwise. FUEL CAP WARNING If you open the cap rapidly while pressure in the tank is high, fuel may spray out from the tank.
  • Page 94 Service/warranty booklet. It is recommended the necessary servicing be performed by an authorised Holden Dealer who has the specialised servicing equipment and trained personnel available to ensure the...
  • Page 95 Chapter 5 FUEL REduCInG FuEL ConSuMPTIon Engine Maintain the engine in peak mechanical condition by having it serviced regularly in accordance with the maintenance schedule in the Service/warranty booklet. This ensures items such as: the spark plugs and air cleaner are maintained for minimum fuel usage and peak engine performance.
  • Page 96 Chapter 5 FUEL noTES...
  • Page 97 New Zealand ........6-3 Flat tyre...........6-4 Towing a disabled vehicle ....6-7 Engine overheating......6-9 Flat battery........6-12 Fuse replacement ......6-14 Bulb replacement......6-20 The asterisk signifies equipment options not in all vehicles; model variants, engine options, optional equipment and Genuine Holden Accessories (and Parts).

  • Page 98: Customer Assistance

    Normally, any problems with the sales, operation, servicing or the validity of original equipment supplied with your vehicle will be handled by your Holden Dealer’s Sales and Service Department. We realise however that, with the best intentions, misunderstandings sometimes occur.

  • Page 99: Emergencies

    EMERGENCIES FoR nEW ZEALAnd HoLdEn oWnERS The information in this Owner’s Handbook applies primarily to Australian Holden vehicles and there may be some differences to the Warranty and Owner Assistance provisions for New Zealand. Applicable details for New Zealand are set out in the Holden Warranty and Owner Assistance Information booklet enclosed in the New Zealand glovebox wallet.

  • Page 100: Flat Tyre

    Chapter 6 EMERGENCIES FLAT TyRE WARNING • All passengers must be out of the vehicle when it is being jacked. • Do not jack a vehicle with a trailer attached, remove the trailer first. • Only jack the vehicle on hard, level surfaces. •...
  • Page 101 Chapter 6 EMERGENCIES FLAT TyRE cont. 1. Remove the jack, jacking tools and spare tyre from the rear luggage compartment area. 2. If your vehicle has bolt-on wheel covers, remove the wheel covers by completely loosening the plastic nut caps with the aid of the wheel wrench. 3.
  • Page 102 Chapter 6 EMERGENCIES FLAT TyRE cont. 10. Remove any dirt or rust from the wheel nuts and studs, mounting surfaces and spare wheel. 11. Place the spare wheel on the wheel mounting surface. 12. Install the wheel nuts and tighten by hand.

  • Page 103: Towing A Disabled Vehicle

    Chapter 6 EMERGENCIES ToWInG A dISABLEd VEHICLE Hazard warning Use the hazard warning to warn other drivers any time your vehicle becomes a traffic hazard, day or night. Avoid stopping on the roadway if possible. Switch the hazard warning on or off by pressing the hazard warning switch, which is located in the middle of the dashboard.
  • Page 104 Chapter 6 EMERGENCIES ToWInG A dISABLEd VEHICLE cont. Front towing eyes The front towing eyes are provided under the front bumper. A driver must be in the vehicle to steer it and operate the brakes. Towing in this manner may be done only on hard-surfaced roads for a short distance and at low speeds.

  • Page 105: Engine Overheating

    Chapter 6 EMERGENCIES EnGInE oVERHEATInG WARNING Immediate action is required if the engine overheats. This can be indicated by the temperature gauge needle moving to the red zone, by steam escaping from under the bonnet, a loss of power or a loud knocking or pinging noise. Continued driving even for a short time could result in a fire or vehicle damage.
  • Page 106 6-10 Chapter 6 EMERGENCIES EnGInE oVERHEATInG cont. If you see or hear steam coming from the engine, stop and switch the engine off. Do not open the bonnet until the engine has cooled down. If the temperature gauge is high with no sign of steam: 1.
  • Page 107 10 minutes if the temperature gauge does not again show an overheat condition. If overheating occurs again you should have the vehicle attended to, as soon as possible, by a Holden Dealer. The engine may temporarily operate at high temperatures during demanding operating conditions, especially on hot days, including: Climbing a long hill.

  • Page 108: Flat Battery

    6-12 Chapter 6 EMERGENCIES FLAT BATTERy WARNING • Do not push start or tow start your vehicle. If unburnt fuel were to reach the catalytic converter and ignite, the converter could overheat or be destroyed by backfire. Therefore, if the battery is flat, you can jump start, but not push start your vehicle.
  • Page 109 6-13 Chapter 6 EMERGENCIES FLAT BATTERy cont. 1. The battery in your vehicle has a negative earth and a 12 volt rating. The battery in the other vehicle must also have a negative earth and a 12 volt rating. 2. Position the two vehicles so they are not touching, apply the park brakes, if your vehicle is fitted with an automatic transmission, place in P (park) or for a manual transmission, place into neutral.

  • Page 110: Fuse Replacement

    A blown fuse can be recognised by its melted wire. If a fuse blows twice in a row a fault is indicated. The cause should be located and fixed by a Holden Dealer. Dashboard To open the fuse cover in the dashboard, open the driver’s side door, pull the top of...
  • Page 111 6-15 Chapter 6 EMERGENCIES FuSE REPLACEMEnT cont. dASHBoARd 10 A 25 A 10 A AIR BAG* WIPER AUDIO/CLOCK 10 A 15 A EXTRA JACK* 15 A 10 A 15 A TURN SIGNAL ABS* CIGAR LIGHTER 10 A 10 A 10 A CLUSTER IMMOBILIZER* BACK-UP...
  • Page 112 6-16 Chapter 6 EMERGENCIES FuSE REPLACEMEnT cont. Dashboard index Circuits protected Airbag (10A) Electronic control module (10A) Turn signal (15A) Cluster (15A) Engine (10A) Heating and air conditioning system (20A) Sunroof (if equipped) (15A) Wiper (25A) Anti-lock brake system (if equipped) (10A) Immobiliser (10A) Traction control module (if equipped) (10A) Hazard flashers (15A)
  • Page 113 6-17 Chapter 6 EMERGENCIES FuSE REPLACEMEnT cont. EnGInE CoMPARTMEnT HEADLAMP PASS F/BOX DOOR LOCK FUEL PUMP MIR. HEAT A/C* FOG* HORN IL LH H/L HI INJECTOR SPARE DR’S P/WDO* IL RH SPARE STOP H/L LO LH H/L LO RH SPARE J06VF0156 Engine compartment index Circuits protected...
  • Page 114 6-18 Chapter 6 EMERGENCIES FuSE REPLACEMEnT cont. Engine compartment index cont... Circuits protected Fog lamp (if equipped) (15A) Left illumination (10A) Injector (15A) Engine management system (15A) Left low beam headlamp (10A) Left low beam headlamp (10A) Low speed electric fan (20A) Demister (30A) High speed electric fan (30A) Power windows (20A)
  • Page 115 6-19 Chapter 6 EMERGENCIES FuSE REPLACEMEnT cont. Relays Relays are also contained in this fuse box; their location in the fuse box and their function is indicated on the inside of the fuse box cover. WARNING When replacing a fuse, ensure the replacement fuse is of the specified amperage.

  • Page 116: Bulb Replacement

    Detailed procedures for headlight aiming are given in the relevant service manual for your vehicle. However, because headlamp aiming is a safety item it is recommended that you have it carried out by your Holden Dealer. Headlamps (sedan and wagon) 1.
  • Page 117 6-21 Chapter 6 EMERGENCIES BuLB REPLACEMEnT cont. Front [lamps (sedan and wagon) 1. Open the bonnet. 2. Remove the two bolts, one nut and the headlamp assembly. 3. Turn the bulb socket anticlockwise to remove it. 4. Pull the bulb socket out of the lamp housing.
  • Page 118 6-22 Chapter 6 EMERGENCIES BuLB REPLACEMEnT cont. Parking lamps (hatchback) 1. Open the bonnet. 2. Remove the four screws and the radiator grille. 3. Remove the three bolts. 4. Remove the headlamp cap. 5. Pull out the parking lamp bulb assembly located next to the headlamp bulb.
  • Page 119 6-23 Chapter 6 EMERGENCIES BuLB REPLACEMEnT cont. Side turn signal lamps 1. Pull the lamp assembly rearward and remove it. 2. Turn the bulb socket anticlockwise. 3. Pull the bulb straight out to remove it from the socket. 4. Reverse the steps to install a new bulb.
  • Page 120 6-24 Chapter 6 EMERGENCIES BuLB REPLACEMEnT cont. Reverse lamps (hatchback) 1. Open the rear hatch. 2. Remove the protective cover. 3. Turn the bulb socket anticlockwise to remove it. 4. Gently push in and turn the bulb anticlockwise to remove it from the socket.
  • Page 121 6-25 Chapter 6 EMERGENCIES BuLB REPLACEMEnT cont. Centre high-mounted stop lamp (hatchback) 1. Open the rear hatch. 2. Pry off the trim and remove the two screws. 3. Remove the bulb socket. 4. Pull the bulb straight out to remove it from the socket.
  • Page 122 Luggage/rear compartment lamp 1. Use a flat-blade screwdriver to pry the lamp assembly from the housing. 2. Remove the bulb. 3. Reverse the steps to install a new bulb. J06VF0173 Bulbs to be changed by a Holden Dealer • Glovebox lamp.

  • Page 123: Weekly Checks

    Brake and clutch fluid levels ..7-8 Power steering and washer fluid levels ......7-9 Tyres ..........7-10 Battery ..........7-13 The asterisk signifies equipment options not in all vehicles; model variants, engine options, optional equipment and Genuine Holden Accessories (and Parts).

  • Page 124: Miscellaneous Checks

    Chapter 7 WEEKLY CHECKS MISCELLAnEouS CHECKS As well as taking your vehicle to be serviced (refer to the Maintenance schedule in the Service/warranty booklet) there are a few simple, weekly checks the owner (or nominee) is recommended to make. These are shown on the following pages. WARNING •...

  • Page 125: Check Locations

    Chapter 7 WEEKLY CHECKS CHECK LoCATIonS undER BonnET LAyouT � � � � � � � J06VF0127A Page Brake and clutch fluid..................7-8  Engine oil ......................7-5  Engine coolant ....................7-4  Dipstick for engine oil ..................7-5  Power steering fluid ....................7-9 ...

  • Page 126: Engine Coolant Level

    Do not spill coolant on the vehicle’s exterior surfaces. It can damage the paintwork. If you do, wash it off immediately. Failure to use the coolant meeting Holden’s specification or maintaining the specified concentration may result in voiding your warranty.

  • Page 127: Engine Oil Level

    Their use will increase costs, may be detrimental to the operation of your vehicle and may void your New Vehicle Warranty, to the extent that Holden considers the non-recommended fluid to have affected the specifications or quality of your vehicle.

  • Page 128: Engine Oil Consumption

    If, after taking into account the above factors, you are still concerned that your engine has excessive oil consumption then you should discuss the situation with a Holden Dealer. Remember that an engine’s oil consumption should not be judged until it has...

  • Page 129: Automatic Transmission 3 Fluid Level

    The fluid level for automatic transmission will be checked for you when your vehicle is taken to your Holden Dealer for servicing. Refer to the Service/warranty booklet. The automatic transmission fluid level does not require checking by the driver in between...

  • Page 130: Brake And Clutch Fluid Levels

    Note If your master cylinder requires constant topping up it could indicate that J06VF0137 a fault exists. Contact your Holden Dealer immediately. To add brake/clutch fluid, do the following: Wipe the cap and top of the reservoir clean to prevent contamination of the brake/ •...

  • Page 131: Power Steering And Washer Fluid Levels

    For a crystal clear windscreen, use the correct amount of Holden Optikleen. Do not use ordinary soap or detergent as these not only froth up but would also damage the wiper rubbers.

  • Page 132: Tyres

    When parking, ensure the tyres are not pressed against the edge of the curb. Check the tyres regularly for: damage, stones, punctures, cuts, cracks, bulges etc. Check the rims for damage. Consult a Holden Dealer, if in doubt.
  • Page 133 Out-of-balance wheels and tyres can cause annoying vibration and uneven tyre wear. If you suspect either of the above problems exist, have a wheel alignment and balance check carried out by your Holden Dealer. Tyre rotation Front and rear tyres perform different jobs and can wear differently depending on the types of roads driven, your driving habits, wheel alignment, balance, tyre pressures, etc.
  • Page 134 Any doubts about the tyres on your vehicle should be referred to your Holden Dealer. New tyres should be fitted in pairs to the front. If replacing only one tyre, it should be paired on the same axle with the least worn of the other three.

  • Page 135: Battery

    7-13 Chapter 7 WEEKLY CHECKS BATTERy Battery maintenance Your vehicle is fitted with a maintenance free battery, which means the fluid level does not need to be checked. To extend the life of your battery, do the following: • Keep the battery mounted securely. •...
  • Page 136 7-14 Chapter 7 WEEKLY CHECKS noTES...

  • Page 137: Specifications

    Specifications Page Specifications .........8-2 Identification labels ......8-4 The asterisk signifies equipment options not in all vehicles; model variants, engine options, optional equipment and Genuine Holden Accessories (and Parts).
  • Page 138 1796 cc Compression ratio 9.7 : 1 Bore 80.5 mm Stroke 88.2 mm Power kW@ rpm Refer to: holden.com.au Torque Nm@ rpm Refer to: holden.com.au Oil specification SAE 5W or 10W/30 SL GF-3 Refill oil capacity 3.75 Litres (including filter)
  • Page 139 Chapter 8 SPECIFICATIONS SPECIFICATIonS cont. Transmission 5 speed manual 4 speed automatic Transmission transmission transmission Transmission fluid type SAE 75W/90 Esso ATF LT 71141 Clutch fluid type DOT-3 or DOT-4 – Dimensions Vehicle Sedan Hatch Wagon Overall length 4515 mm 4295 mm 4580 mm Overall width...
  • Page 140 Chapter 8 SPECIFICATIONS IdEnTIFICATIon LABELS Compliance label The compliance label is located in the rear luggage compartment in the spare wheel well, adjacent to the spare wheel on the right-hand side. J06VF0210 Breakdown of vehicle identification number The Vehicle Identification Number (VIN) is broken down the following way: Nation of origin Production sequence number...
  • Page 141 Chapter 8 SPECIFICATIONS IdEnTIFICATIon LABELS cont. Vehicle identification number (VIN) This is the legal identifier for your vehicle, and is used for the identification of spare parts. The vehicle identification plate is located inside the engine bay, on the bulkhead. J06VF0202 The vehicle identification plate is also visible through the windscreen on the top...
  • Page 142 Chapter 8 SPECIFICATIONS IdEnTIFICATIon LABELS cont. Tyre label (sedan and hatch) The tyre placard is located in the glovebox for sedan and hatch model vehicles. J06VF0214 Tyre label (wagon) The tyre placard is found on the lower part of the ‘B’ pillar on the driver side on wagon vehicles.

  • Page 143: Tow And Load

    Tow and load Page Loading the vehicle......9-2 Towing ..........9-4 The asterisk signifies equipment options not in all vehicles; model variants, engine options, optional equipment and Genuine Holden Accessories (and Parts).
  • Page 144 Chapter 9 TOW AND LOAD LoAdInG THE VEHICLE MAxIMuM VEHICLE PAyLoAdS Overloading is a safety hazard and could also shorten the life of the vehicle. The typical recommended carrying capacity of the vehicle is as shown in the table below. Do not exceed the maximum axle loads shown below in the diagram, including the weight of any options or accessories fitted to the vehicle.
  • Page 145 When carrying loads on the roof rack, avoid hard braking, abrupt swerving or sharp steering. For occupant safety, and to avoid damaging the vehicle's roof, refer to your Holden Dealer for the approved rack system for your vehicle.
  • Page 146 Refer to the table further on in this chapter for the mandatory equipment required for the weight you are towing. Your Holden Dealer will help supply and install towing equipment to suit your requirements.
  • Page 147 Ensure the weight of the packed trailer is not greater than the towing capacity of the Holden approved tow bar package fitted to the vehicle.
  • Page 148 ToWInG cont. ToWInG EquIPMEnT Tow load Tow ball load Mandatory equipment Up to Less than Holden 1,200 kg rated tow bar. or equal to 610 kg Holden trailer wiring harness. 75 kg. Up to More than Holden 1,200 kg rated tow bar.
  • Page 149 Chapter 9 TOW AND LOAD ToWInG cont. ToWInG PRECAuTIonS • When heavily loading the vehicle or when towing, the tyres should be inflated to the maximum recommended pressure. Refer to Identification labels in chapter 8 for tyre placard location. • Tighten the tow ball retaining nut to 140 Nm (Newton metres) and check the torque frequently.
  • Page 150 Chapter 9 TOW AND LOAD noTES...

  • Page 151: Cleaning

    Cleaning Page Interior cleaning ......10-2 Exterior cleaning ......10-4 Cleaning products......10-8 The asterisk signifies equipment options not in all vehicles; model variants, engine options, optional equipment and Genuine Holden Accessories (and Parts).
  • Page 152 10-2 Chapter 10 CLEANING InTERIoR CLEAnInG WARNING Many cleaners may be toxic, flammable or may damage the interior. When cleaning the interior, avoid volatile cleaners such as: acetone, lacquer thinners, enamel reducers, nail polish removers, or cleaners such as: laundry soaps, bleaches or reducing agents.
  • Page 153 Do not bleach or dye seatbelts since this may severely weaken them. Cleaning interior glass The interior glass area of the vehicle should be cleaned using Holden Glass Cleaner with a clean soft cloth. Care must be taken when cleaning inside the rear window, not to damage the demister.
  • Page 154 10-4 Chapter 10 CLEANING ExTERIoR CLEAnInG CARInG FoR PAInT To help preserve the shiny new vehicle finish, special attention should be given to correctly treat those conditions that can damage the paint. Road bloom: If, over a long period of time, oils, dirt, exhaust and other pollutants are allowed to build up, they may combine to affect the paint finish.
  • Page 155 10-5 Chapter 10 CLEANING ExTERIoR CLEAnInG cont. WARNING Care should be taken when moving the vehicle after washing, in case water has affected the brakes. Applying the brakes lightly will indicate if they have been affected. To dry them quickly, lightly apply the brakes while maintaining a slow forward speed with a clear area ahead, until brake performance returns to normal.
  • Page 156 PVC coating should be checked and, if necessary, restored to perfect condition. Commercial bitumen and rubber materials can damage PVC coating. Have all work on the underbody performed by a Holden Dealership, as it requires knowledge of the specified materials and experience concerning their application.
  • Page 157 Flush off any mud on the glass when washing the body, but leave the final cleaning and polishing until afterwards. Use Holden Glass Cleaner and wash each section of glass in turn, making sure the water, its container and the sponge are quite clean and free from grit.
  • Page 158 10-8 Chapter 10 CLEANING CLEAnInG PRoduCTS Part number Size Description Usage Seals in a deep, lustrous glazed finish. Quick and Easy 92145132 237 ml Long life protection from oxidation, salt Speed Finish and weather damage. Seals in a deep, lustrous glazed finish. Quick and Easy 92145418 437 ml...

  • Page 159: Index

    IndEx Bonnet release ......1A-20 Boot compartment ajar lamp ...1A-7 ABS ..........4-12 Boot release button ......2-7 Accessories warranty. Brakes ..........4-5 See Service/warranty booklet. Accessory power outlet ....1A-18 Fluid level ........7-8 Airbags ..........3-9 Park brake ......... 3-22 Airbag warning lamp ......1A-8 Warning lamp ......1A-6 Bulb replacement......
  • Page 160 IndEx cont. Emission control system ....5-4 Gauges ..........1A-3 Engine Glovebox ........1A-19 Cooling system ......7-4 Identification number ....8-4 Handbrake ........3-22 Overheating ......... 6-9 Hazard warning flashers ..1A-6, 1A-13 Specifications ....... 8-2 Headlamp switch ......1A-11 Starting ........4-3 Head restraints ........
  • Page 161 IndEx cont. Lamps cont... Interior (dome) lamp ....3-20 Capacity ........8-2 Licence plate lamp ..... 6-25 Consumption ........ 7-6 Map lamp ........3-20 Level ..........7-5 Loading information ....4-5, 9-3 Low pressure warning ....1A-6 Locks ..........2-5 Overheating ........6-9 Bonnet ........1A-20 Owner responsibility Child proof ........
  • Page 162 IndEx cont. Tripmeter .........1A-3 Turn signal Safer driving precautions ....4-4 Bulb replacement ....... 6-21 Safety ..........4-2 Operation .........1A-12 Seat adjustment......... 3-2 Tyres Seatbelt pretensioners....... 3-7 General ........7-10 Seatbelt reminder lamp ....1A-8 Grip ..........4-5 Seatbelts..........3-5 Inflation pressure ....... 7-10 Serial number ........

This manual is also suitable for:

Viva 2008

Table of Contents

Save PDF
