BACnet Object Table

Object name
BACnet Thermostat
Type &
Object name
Instance
Current
AI 0
Temperature
Active Temperature
AI 1
Setpoint
Built-in Temperature
Sensor
AI 2
Remote
Temperature
AI 3
Sensor
Current Humidity
AI 4
Current Dew Point
AI 5
Current CO
2
AI 6
Reading
Control Valve
AI 7
Feedback
Modulating/
AI 8
Floating Output 1
Modulating/
AI 9
Floating Output 2
Modulating Fan
AI 10
Output
UM-15095000-AA0
Type & Instance
Device 700001
Readable/
Writable
R
R
R
R
R
R
R
R
R
R
R
Object Property
(Readable/Writable)
Model Name (R)
Application Software Version (R)
Object Identifier (R)
Object Name (R/W)
Max_Master (R/W)
Description
Current Temperature
Active Temperature
Set- Point
Built-in
Temperature
Sensor Reading
Remote
Temperature Sensor
Reading
Current Humidity
(221CH models only)
Current Dew Point
(221CH models only)
Current CO Reading
2
Control Valve Feedback
Modulating/ Floating
Output 1
Modulating/ Floating
Output 2
Modulating Fan Output
Range
32 characters (max.)
1~127
Range and Definition
-999~9999: -99.9〜999.9
℃/°F
°C :0~500 (0.0〜50.0℃)
°F: 320~1220
(32.0~122.0°F)
-999~9999:-99.9~999.9 ℃/°F
-999~9999:-99.9~999.9℃/°F
0~1000: 0.0〜100.0%RH
-999~9999: -99.9~999.9
°C/°F
0~3000: 0~3000 ppm
0〜1000 (0.0%〜100.0%)
0~100: 0〜100 %
0~100: 0〜100 %
0~100: 0〜100 %
