Contemporary Controls BASstat BAST-121C-B2 User Manual page 33

Type &
Object name
Instance
On-Off Control
BV 5
Temperature Scale
BV 6
Relay 1 Control
BV7
Type &
Object name
Instance
Relay 2 Control
BV8
Relay 3 Control
BV9
Relay 4 Control
BV10
Relay 5 Control
BV11
Relay 6 Control
BV12
Relay 7 Control
BV13
Occupancy
BV 14
Command
Fan Output for
BV15
Heating
Heartbeat Signal
BV16
MSV 0
Fan Mode
MSV 1
System Mode
MSV 2
Sleep
UM-15095000-AA0
Readable/
Description
Writable
On/Off Control of
R/W
Thermostat Outputs
°C/ °F
R/W
On/Off Control of Relay
R/W
1 (Stage 1)
Readable/
Description
Writable
On/Off Control of Relay
R/W
2 (Stage 2)
On/Off Control of Relay
R/W
3
On/Off Control of Relay
R/W
4
On/Off Control of Relay 5
R/W
On/Off Control of Relay 6
R/W
On/Off Control of Relay
R/W
7 Fan
Room Occupancy Setting
R/W
Disable/ Enable
Fan Output for
R/W
Heating
Heartbeat Pulse Input
R/W
R/W
Fan Mode
Working Mode: Heat, Cool
or Ventilation
(
Can be changed only within 1
R/W
minute after setting AV37 to
data"1")
Sleep (Only for Models
with Sleep Function
R/W
Available).
Range and Definition
0: Off, 1: On
0: °C
1: °F
0: Off, 1: On
Range and Definition
0: Off, 1: On
0: Off, 1: On
0: Off, 1: On
0: Off, 1: On
0: Off, 1: On
0: Off, 1: On
0: Occupied,
1: Unoccupied
0: Disable
1: Enable
0: Off
1: On
1: Auto 2: Low
3: Med.4: Hi
1: Cool Mode
2: Heat Mode
3: Ventilation @ Cool Mode
4: Ventilation @ Heat Mode
1: Disable,
2: 0 Hr. Sleep
3: 0.5 Hr. Sleep
4: 1 Hr. Sleep
5: 1.5 Hrs. Sleep,
6: 2 Hrs. Sleep
Page 33
