Item Mnemonic
E13 ESI ESI (DI1) digital sensor contact definition
Modulating Cooling direct/ reverse signal
E14 rE-C
output
Modulating Heating direct/ reverse signal
E15 rE-H
output
Present Temperature is getting from built-in
temperature Sensor, remote temperature
E16 rS
sensor, or assigned through communication
Display present temperature value of or
E17 -SP-
current set-point for LCD
E18 door Door or Windows contact definition (not
applicable to all models)
E19 LFAn Lowest Fan speed in Auto fan mode
E20 Pct Output Percentage (not used)
E21 Baud BACnet MS/TP Baud rate
E22 Addr BACnet MS/TP MAC address
E23 devH Device instance no. - Hi bytes
E24 devL Device instance no. - Low bytes
Max_Master -- The highest allowed MAC
E25 AdrH
address for BACnet MS/TP master nodes
E26 rHSt Relative Humidity Offset (221CH models
only)
E27 F-Ht Fan Output for Heating
E28 dLyC Cooling Short Cycle Delay
Cooling Maximum Cycles per
E29 cycC
Hour
UM-15095000-AA0
Description
°C Scale
Default Range Default
0 0~1
0 0~1
0 0~1
0 0~2
0 0~1
0 0~1
0 0~3
0 0~100
9.6kbps
19.2kbps
38.4 38.4
38.4kbps
57.6kbps
76.8kbps
1
0~127
100 0~4194
0~999
(if ID-H <=
1 4193)
0~302
( if ID-H
= 4194)
127
1~127
0 -30.0〜
30.0
0
0/1
3 1~3
4 2~6
Page 21
°F Scale
Step
Range
0: N.O.
0 0~1
1: N.C.
0 0~1
0: (Direct)
1: (Reverse)
0 0~1
0: (Direct)
1: (Reverse)
0: built-in
1: remote sense
0 0~2
2: assigned
through
BACnet
0: display PV
0 0~1
1: display SP
0: N.O.
0 0~1
1: N.C.
0: stop
0
0~1 1: low
0 0~100 1%
9.6kbps 9.6kbps
19.2kbps 19.2kbps
38.4kbps 38.4kbps
57.6kbps 57.6kbps
76.8kbps 76.8kbps
1 1
0~127
100 0~4194 1
0~999
(if ID-H
1 1
<=4193)
0~302
( if ID-H
= 4194)
127 1
1~127
0 0.1%RH
-30.0〜30.0
0: Disable
0 0/1
1: Enable
1 (minutes)
3 1~3
1 (cycles/hour)
4 2~6
