Contemporary Controls BASstat BAST-121C-B2 User Manual page 22

Item Mnemonic
E30 dLyH
Heating Short Cycle
Heating Maximum Cycles per Hour
E31 cycH
E32 tyPE
Control Type
E33 OPL2 Minimum Output for AO2 (not used)
E34 SPA2 Span Offset for AO2 (not used)
E35 Hrtr Communication Heartbeat Minimum Rate
E36 CO2H CO2 Input High Value (not used)
E37 C2PB CO2 Control Output Proportional
Band (not used)
E38 C2SP CO2 Setpoint (not used)
E39 C2Lo CO2 Control Minimum Output (not used)
E40 AFtH After Hour Extension Time (not used)
E41 VALL Input Low Value of Valve Feedback
(not used)
E42 VALH Input High Value of Valve Feedback
(not used)
E43 OPts Options (mode reset)
E44 AI-H Analog Input High Value (not used)
E45 Hrt Communication Heartbeat Flip-Flop
E46 CSPL Minimum Cooling Temperature Setpoint
E47 HSPH Maximum Heating Setpoint
E48 nFAn Minimum Fan Output (not used)
E49 hFAn Maximum Fan Output (not used)
E50 FAnL Low Fan Speed Setting (not used)
E51 FAn2 Med. Fan Speed Setting (not used)
E52 FAnH Hi Fan Speed Setting (not used)
E53 Ob/Ab Reversing Valve Polarity
E54 OFFt Minimum Off Time
E55 On-t Minimum On Time
E56 Str Floating Motor Full Stroke Time (not used)
E57 tESt Self-Diagnostic – toggle all LCD features and
all relays. NOTE: Use only to test with
outputs disconnected from control circuits.
UM-15095000-AA0
Description
°C Scale
Default Range Default
3 0~3
4 2~6
2 1~2
60 10~3600 60
0 0/1
0 0/1
18.0 0.0-50.0 65.0
25.0 0.0-50.0 77.0
180 0~600
0 0~600
Page 22
°F Scale
Step
Range
1 (minutes)
3 0~3
4 2~6 1 (cycles/hour)
0: Cooling Only
1: C&H Manual
2: C&H Auto
3: Heating Only
2 1~2
4. Single Mode
10~3600 10s
0 0/1 0: Disable
1: Enable
0 0/1 0: Off 1: On
32.0-122.0 0.1 (°C/°F)
32.0-122.0 0.1 (°C/°F)
180 0~600
5 (seconds)
0 0~600
5 (seconds)
Use
Press MODE
Caution!
to engage test
