Contemporary Controls BASstat BAST-121C-B2 User Manual page 34

Type &
Object name
Instance
Temperature Source MSV3
Lowest Fan Speed
Fan Speed Status
Baud Rate
Display Options
Control Type
UM-15095000-AA0
Readable/
Writable
R/W
MSV 4 R/W
MSV 5 R
MSV 6 R/W
MSV 7 R/W
MSV 8 R/W
Description
Current Temperature Source
Lowest Fan speed
in Auto Fan mode
Fan Speed Status
Baud rate
(BACnet
MS/TP)
LCD Display Options
Control Type Selection
Range and Definition
1: Built-In Temp. Sensor 2:
Remote Temp. Sensor 3:
Assigned through BACnet
1: Stop 2: Low
3: Med. 4: Hi.
1: Stop 2: Low
3: Med 4: Hi
1: 9600 bps
2: 19200 bps
3: 38400 bps
4: 57600 bps
5: 76800 bps
1: T & Time (if available) 2:
SP & Time (if available)
& CO2 (if available)
4: CO2 & Time (if available)
5: SP & CO2 (if available)
6: T & RH (if available) 7: T
& Valve (if available)
1: Cool Only
2: 4-Pipe Cooling or Heating
Manual Changeover
3: 4-Pipe Cooling and
Heating Auto Changeover
4: Heating Only
Page 34
3: T
