HiLook Series
Smart Hybrid Light
Bullet & Turret Camera
User Manual
User Manual
Thank you for purchasing our product. If there are any
questions, or requests, do not hesitate to contact the
dealer.
This manual applies to the models below:
Type
Model
Type I Camera
THC-B129-LPS
Type II Camera
THC-B229-LS
Type III Camera
THC-T129-LPS
Type IV Camera
THC-T229-LMS
This manual may contain several technical mistakes or
printing errors, and the content is subject to change
without notice. The updates will be added to the new
version of this manual. We will readily improve or update
the products or procedures described in the manual.
01000020230713
Advertisement
Table of Contents
Related Manuals for HIKVISION HiLook THC-B129-LPS
Summary of Contents for HIKVISION HiLook THC-B129-LPS
- Page 1 HiLook Series Smart Hybrid Light Bullet & Turret Camera User Manual User Manual Thank you for purchasing our product. If there are any questions, or requests, do not hesitate to contact the dealer. This manual applies to the models below: Type Model Type I Camera...
- Page 2 With the philosophy of “Technology for the Good”, Hikvision requests that every end user of video technology and video products shall comply with all the applicable laws and regulations, as well as ethical customs, aiming to jointly create a better community.
- Page 3 believe that these products will also play an active role in more aspects of social life. Any abuse of video products in violation of human rights or leading to criminal activities are contrary to the original intent of technological innovation and product development. Therefore, each user shall establish an evaluation and tracking mechanism of their product application to ensure that every product is used in a proper and reasonable manner and with good...
- Page 4 DOCUMENTATION, WHETHER BASED ON BREACH OF CONTRACT, TORT (INCLUDING NEGLIGENCE), PRODUCT LIABILITY, OR OTHERWISE, IN CONNECTION WITH THE USE OF THE PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR LOSS. YOU ACKNOWLEDGE THAT THE NATURE OF THE INTERNET...
-
Page 5: Regulatory Information
NUCLEAR FUEL-CYCLE, OR IN SUPPORT OF HUMAN RIGHTS ABUSES. IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATTER PREVAILS. Regulatory Information EU Compliance Statement This product and - if applicable - the supplied accessories too are marked with "CE"... - Page 6 Warnings Follow Cautions Follow these these safeguards to precautions to prevent prevent serious injury potential injury or or death. material damage. Warnings In the use of the product, you must be in strict compliance with the electrical safety regulations of the nation and region.
-
Page 7: Product Features
Keep the camera away from liquid while in use for non- water-proof device. While in delivery, the camera shall be packed in its original packing, or packing of the same texture. The beam of the light at the distance of 200 mm is ... -
Page 8: Installation
1.2.3 Overview of Type III Camera Installation Plate Base Enclosure Switch Button Power Cord Main Body Video Cable Figure 1-3 Overview of Type III Camera Note: Press and hold the switch button for 5 seconds to switch the video output. Four kinds of video outputs are available: TVI, AHD, CVI, and CVBS. - Page 9 Figure 2-1 Secure the Camera to the Ceiling 5. Connect the cables. 6. Power on the camera to adjust the view angle according to the figure below. Figure 2-2 3-Axis Adjustment 2.1.2 Ceiling/Wall Mounting with Junction Box Before you start: You need to purchase a junction box in advance.
- Page 10 Figure 2-5 Fix the Cover to Its Body 9. Refer to Step 6 of 2.1.1 Ceiling/Wall Mounting without Junction Box to finish installation. Installation of Type III & IV Camera 2.2.1 Ceiling Mounting without Junction Box Steps: 1. Paste the drill template (supplied) to the installation location.
- Page 11 3. (Optional) For cement ceiling, drill the screw holes with a 5.5 mm drill and insert the supplied wall plugs. 4. (Optional) Drill the cable hole, when the cables are routed through the ceiling. 5. Secure the junction box body on the ceiling with three or four PA4 ×...
-
Page 12: Menu Description
Figure 2-11 Fix the Installation Plate 4. Refer to steps 3 to 5 of Section 2.2.1 Ceiling Mounting without Junction Box to finish installation. Figure 2-12 Finish Installation 3 Menu Description Please follow the steps below to call the menu. Note: The actual display may vary with your camera model. -
Page 13: Video Format
VIDEO FORMAT EXPOSURE MODE ANTI-BANDING EXPOSURE BACK EXIT SAVE & EXIT LIGHTING MODE IR/WHITE LIGHT SMART IR THRESHOLD LIGHTING SETTINGS LEVEL BACK EXIT SAVE & EXIT IMAGE MODE WHITE BALANCE BRIGHTNESS CONTRAST VIDEO SHARPNESS MAIN MENU SETTINGS SATURATION BACK EXIT SAVE &... -
Page 14: White Light
3.2 EXPOSURE EXPOSURE MODE You can set the EXPOSURE MODE to GLOBAL, BLC, HLC, or DWDR. GLOBAL GLOBAL refers to the normal exposure mode which adjusts lighting distribution, variations, and non-standard processing. BLC (Backlight Compensation) BLC (Backlight Compensation) compensates light to the object in the front to make it clear, but this may cause over-exposure of the background where the light is strong. -
Page 15: Video Settings
THRESHOLD The higher the threshold is, the more sensitive the device is to dark environment. LEVEL You can adjust the maximum brightness of supplement light. 3.4 VIDEO SETTINGS Move the cursor to VIDEO SETTINGS and click Iris+ to enter the submenu. IMAGE MODE, WHITE BALANCE, BRIGHTNESS, CONTRAST, SHARPNESS, SATURATION, and DNR are adjustable. -
Page 16: Audio Settings
SATURATION Saturation is the proportion of pure chromatic color in the total color sensation. Adjust this feature to change the saturation of the color. DNR refers to digital noise reduction. This function reduces noise in video stream. 3.5 AUDIO SETTINGS Under the AUTO SETTINGS sub-menu, you can set the mode to ON or OFF.
