User Manual
Thank you for purchasing our product. If there are any
questions, or requests, do not hesitate to contact the
dealer.
This manual applies to the models below:
Type II
This manual may contain several technical mistakes or
printing errors, and the content is subject to change
without notice. The updates will be added to the new
version of this manual. We will readily improve or
update the products or procedures described in the
manual.
2 MP Bullet Camera
Type
Type I
HiLook Series
User Manual
Model
THC-B129-P
THC-B129-M
THC-B229-M
0101002000102
Advertisement
Table of Contents
Related Manuals for HIKVISION THC-B129-P
Summary of Contents for HIKVISION THC-B129-P
- Page 1 Thank you for purchasing our product. If there are any questions, or requests, do not hesitate to contact the dealer. This manual applies to the models below: Type Model THC-B129-P Type I THC-B129-M Type II THC-B229-M This manual may contain several technical mistakes or printing errors, and the content is subject to change without notice.
-
Page 2: Regulatory Information
Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC compliance: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. - Page 3 Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into “Warnings” and “Cautions”. Warnings: Serious injury or death may occur if any of the warnings are neglected.
-
Page 4: Installation
To avoid heat accumulation, good ventilation is required for the operating environment. Keep the camera away from liquid while in use for non-water-proof device. While in delivery, the camera shall be packed in its original packing, or packing of the same texture. Mark Description Table 0-1 Mark Description Mark... - Page 5 Make sure the wall is strong enough to withstand three times the weight of the camera and the mount. If the product does not function properly, contact your dealer or the nearest service center. Do NOT disassemble the camera for repair or maintenance by yourself.
- Page 6 2). Loosen screw A to adjust the tilt position [0° to 180°]. 3). Loosen screw B to adjust the rotation position [0° to 360°]. 7. Tighten the trim ring and screws to finish the installation. 2.1.2 Ceiling/Wall Mounting with Junction Box Before you start: You need to purchase a junction box in advance.
- Page 7 Figure 2-7 Fix the Junction Box Cover on Its Body Repeat steps 6 to 7 of 2.1.1 Ceiling/Wall Mounting without Junction Box to finish the installation. 2.2 Installation of Type II Camera 2.2.1 Ceiling/Wall Mounting without Junction Box Before you start: The ceiling mounting and wall mounting are similar.
-
Page 8: Menu Description
Figure 2-10 3-Axis Adjustment 1). Loosen the trim ring to adjust the pan position [0° to 360°]. 2). Loosen screw A to adjust the tilt position [0° to 180°]. 3). Loosen screw B to adjust the rotation position [0° to 360°]. 7. -
Page 9: Video Format
VIDEO FORMAT EXPOSURE MODE ANTI- BANDING EXPOSURE BACK EXIT SAVE & EXIT IMAGE MODE WHITE BALANCE BRIGHTNESS CONTRAST VIDEO SHARPNESS SETTINGS SATURATION 3 DNR MIRROR BACK EXIT SAVE & EXIT MAIN MENU LIGHT SMART THRESHOLD LIGHT LEVEL BACK EXIT SAVE & EXIT ALARM MODE BACK FUNCTIONS... -
Page 10: Video Settings
3.3 EXPOSURE EXPOSURE MODE You can set the EXPOSURE MODE to GLOBAL, BLC, HLC, or DWDR. GLOBAL GLOBAL refers to the normal exposure mode which adjusts lighting distribution, variations, and non-standard processing. BLC (Backlight Compensation) BLC (Backlight Compensation) compensates light to the object in the front to make it clear, but this may cause over-exposure of the background where the light is strong. - Page 11 the image. You can set WHITE BALANCE mode to AUTO or MANUAL. AUTO Under AUTO mode, white balance is being adjusted automatically according to the color temperature of the scene illumination. MANUAL You can adjust the R-GAIN and B-GAIN value to correct colors manually.
-
Page 12: Alarm Mode
SMART LIGHT AUTO LIGHT THRESHOLD LEVEL BACK EXIT SAVE & EXIT Figure 3-5 SMART LIGHT AUTO Under the AUTO mode, the white light turns on automatically as the environment becomes dark. The THRESHOLD is the environmental light level at which the white light turns on.
