Summary of Contents for ICON WEILDER CROSS BAR LEGEND
Page 1
Model No. WESY59933 Serial No. Write the serial number in the space above for future reference. Serial Number Decal (under seat) QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction. If you have questions, or if there are missing or damaged parts, we will guarantee complete satis- faction through direct assis-...
1-877-992-5999, Monday through Friday, 6 a.m. until 6 p.m. Mountain Time, to order a free replacement decal. Apply the decal in the location shown. Keep hands and fingers clear of this area. CrossBar by WEIDER is a trademark of ICON IP, Inc.
35 or persons with pre-existing health problems. Read all instructions before using. ICON assumes no responsibility for personal injury or property damage sustained by or through the use of this product.
BEFORE YOU BEGIN Thank you for selecting the innovative CrossBar by after reading this manual, please call our Customer WEIDER LEGEND resistance system. The resistance Service Department toll-free at 1-877-992-5999, ™ system offers a selection of stations designed to devel- Monday through Friday, 6 a.m.
ASSEMBLY • Tighten all parts as you assemble them, unless Make Things Easier for Yourself instructed to do otherwise. This manual is designed to ensure that the resist- • As you assemble the resistance system, make ance system can be assembled successfully by sure all parts are oriented as shown in the draw- most people.
Page 6
2. Attach a Wheel (31) to the outside of the Base (1) with an M10 x 108mm Bolt (81), three M10 Washers (75), and an M10 Nylon Locknut (76). Do not overtighten the Locknut; the Wheel must be able to turn easily. Attach the other Wheel (not shown) in the same manner.
Page 7
6. Pull the Seat Knob (45, not shown) out as far as Third it will go, and slide the Seat Carriage (12) onto Hole the Bench Rail (5). Engage the Seat Knob into the third hole from the end of the Bench Rail. See the inset drawing.
Page 8
9. Press two 38mm Round Inner Caps (38) into the ends of the Top Frame (10). Attach two Eyebolts (34) to the Top Frame (10) with two M8 Washers (59) and two M8 Nylon Locknuts (65). Do not overtighten the Locknuts; the Eyebolts must be able to rotate freely.
Page 9
12. Press two 25mm Square Inner Caps (54) into the indicated end of the Backrest Frame (15). Attach a Plastic Foot (53) to the Backrest Frame (15) with an M4 x 16mm Screw (62). Orient the Backrest (14) and the Backrest Backing (8) as shown.
Page 10
15. Slide the Leg Developer (19) into the Bench Rail (5). Align the hole in the Leg Developer with a hole in the Front Leg (6). Tighten the Bench Knob (42) into the hole in the Leg Developer. Connect the eyebolt on the Leg Lever Cable (32) to indicated side of the Leg Lever (7) with an M8 Nylon Locknut (65).
Page 11
19. Wrap the Long Cable (80) under a 90mm Pulley (28) as shown. Attach the Pulley and a Pulley Guard (29) to the Upright (3) with an M10 x 113mm Button Head Bolt (40) and an M10 Nylon Locknut (76). Make sure the flat edge of the Pulley Guard is on the bottom.
Page 12
23. Locate the two Short Cables (33). Wrap one of the Cables around a 90mm Pulley (28). Attach the Pulley to a High Pulley Housing (21) with an M10 x 42mm Button Head Bolt (71) and an M10 Nylon Locknut (76). Repeat this step with the other Short Cable (33).
ADJUSTMENTS This section explains how to adjust the resistance system. See the EXERCISE GUIDELINES on page 17 for important information about how to get the most benefit from your exercise program. Also, refer to the accompa- nying exercise guide to see the correct form for each exercise. Make sure all parts are properly tightened each time the resistance system is used.
Page 14
ATTACHING THE ACCESSORIES To attach a Short Handle (49) to a high pulley, first attach the high pulley to the resistance system (see ATTACHING THE HIGH PULLEYS AND LEG LEVER on page 13). Then, attach the Short Handle to the Short Cable (33) with a Cable Clip (51).
Page 15
ADJUSTING THE BACKREST The Backrest (14) can be used in a level position or one of three inclined positions. To use the Backrest in a level position, secure the Seat Carriage (12) at the hole Slot in the Bench Rail (5) closest to the Leg Developer (19) (see ADJUSTING THE SEAT on page 13).
USING THE REMOVABLE RESISTANCE BARS The Removable Resistance Bars (36, 67) can be used to exercise apart from the resistance system, as shown in the video or on the exercise guide. To remove a Resistance Bar, pull it out of the Tray (35). To replace the Removable Resistance Bars (36, 67), slide them into the Tray (35) from the side shown, so that the arrows on the rings point toward the Tray.
EXERCISE GUIDELINES THE FOUR BASIC TYPES OF WORKOUTS PERSONALIZING YOUR EXERCISE PROGRAM Muscle Building Determining the exact length of time for each workout, To increase the size and strength of your muscles, as well as the number of repetitions or sets completed, push them close to their maximum capacity.
Page 18
Rest for a short period of time after each set. The slowly as you stretch and do not bounce. Ease into ideal resting periods are: each stretch gradually and go only as far as you can • Rest for three minutes after each set for a muscle without strain.
Page 19
MONDAY EXERCISE RESISTANCE SETS REPS Date: TUESDAY AEROBIC EXERCISE Date: WEDNESDAY EXERCISE RESISTANCE SETS REPS Date: THURSDAY AEROBIC EXERCISE Date: FRIDAY EXERCISE RESISTANCE SETS REPS Date: Make photocopies of this page for scheduling and recording your workouts.
Page 20
PART IDENTIFICATION CHART Refer to the drawings below to identify small parts used in assembly. The number in parentheses below each drawing is the key number of the part, from the PART LIST on the reverse side of this page. Note: Some small parts may have been pre-attached.
Page 21
M6 Black Nylon Locknut (69) M10 x 42mm Button Head Bolt (71) M10 Nut (47) M6 x 45mm Screw (58) M8 Nylon Locknut (65) M10 Nylon Locknut (76) M10 x 65mm Button Head Screw (70) M10 x 25mm Button Head Screw (87) M10 x 69mm Bolt (60) M8 x 25mm Button Head Screw (46)
Page 22
PART LIST—Model No. WESY59933 R0704A Key No. Qty. Description Key No. Qty. Description Base 50mm Round Inner Cap Base Plate M6 x 45mm Screw Upright M8 Washer Lat Tower M10 x 69mm Bolt Bench Rail Seat Wheel Front Leg M4 x 16mm Screw Leg Lever M6 Zinc Nylon Locknut Backrest Backing...
All repairs for which warranty claims are made must be pre-author- ized by ICON. This warranty does not extend to any product or damage to a product caused by or attrib- utable to freight damage, abuse, misuse, improper or abnormal usage or repairs not provided by an ICON authorized service center;...
