Type and Function
size
Flash Stores power
Memory 32 management
KB micro-controller
firmware
FRAM 32 KB Stores host
processor power
sequencer micro-
controller
firmware
Flash Stores analog
Memory 64 front end micro-
KB controller
firmware
Flash Stores front
Memory 256 panel micro-
KB controller
firmware
FPGA NOR Stores FPGA
Flash 64 MB configuration
FPGA NOR Stores backup
Flash 64 MB copy of FPGA
configuration
MSO44, MSO46, MSO44B, and MSO46B 4 Series Mixed Signal Oscilloscopes Declassification and Security Instructions
Type of user Method of
info stored modification
None Indirectly
None Indirectly
None Indirectly
None Indirectly
None Indirectly
None Indirectly
Data input Location User
method acce-
ssible
Application Internal to No
software the
operations MC9S08
micro-
controller
on the
acquisition
board
Application Internal to No
software the
operations MSP430
micro-
controller
on the
processor
board
Application Internal to No
software the KL14
operations micro-
controller
on the
Acquisition
board
Application Internal to No
software the TIVA
operations TM4C
micro-
controller
on the front
panel LED
board
Application Acquisition No
software board
operations
Application Acquisition No
software board
operations
Clear and sanitize procedures
To clear To sanitize
Not applicable, does
not contain user data
or settings. Clearing or
sanitizing would disable
instrument functionality.
Not applicable, does
not contain user data
or settings. Clearing or
sanitizing would disable
instrument functionality.
Not applicable, does
not contain user data
or settings. Clearing or
sanitizing would disable
instrument functionality.
Not applicable, does
not contain user data
or settings. Clearing or
sanitizing would disable
instrument functionality.
Not applicable, does
not contain user data
or settings. Clearing or
sanitizing would disable
instrument functionality.
Not applicable, does
not contain user data
or settings. Clearing or
sanitizing would disable
instrument functionality.
