  • Page 1 NBL21M-L1 MANUAL 2MP LPR BULLET CAMERA...
  • Page 2 Notes on Safety This product is intended to be supplied by a Listed Power Unit, marked with  'Limited Power Source', 'LPS' on unit, output rated minimum 12V/2 A or POE 48V/ 350mA or AC24V (depending on models), no more than 2000m altitude of operation and Tma=60 Deg.C.
  • Page 3 Disclaimer With regard to the product with internet access, the use of product shall be  wholly at your own risks. Our company shall be irresponsible for abnormal operation, privacy leakage or other damages resulting from cyber-attack, hacker attack, virus inspection, or other internet security risks; however, our company will provide timely technical support if necessary.

  • Page 4: Table Of Contents

    Table of Contents Introduction ........................1 Network Connection ....................2 LAN ................................2 2.1.1 Access through IP-Tool ..................... 2 2.1.2 Directly Access through IE ....................4 WAN ................................. 5 Live View ........................8 Network Camera Configuration ................10 System Configuration ........................11 4.1.1 Basic Information ......................
  • Page 5 Network Camera User Manual 4.6.10 FTP ............................43 4.6.11 HTTPS ..........................44 4.6.12 P2P (Optional) ........................45 4.6.13 QoS ............................46 Security Configuration ........................46 4.7.1 User Configuration ......................46 4.7.2 Online User ........................48 4.7.3 Block and Allow Lists....................... 48 4.7.4 Security Management ....................

  • Page 6: Introduction

    Introduction Main Features  ICR auto switch, true day/night  3D DNR, WDR  BLC, Defog, Anti-flicker, smart IR, corridor mode  ROI coding  Abnormal video signal detection (scene change, video blur detection, video color cast detection), license plate recognition ...

  • Page 7: Network Connection

    2 Network Connection Connect IP-Cam via LAN or WAN. Here only take IE browser for example. The details are as follows: 2.1 LAN In LAN, there are two ways to access IP-Cam: 1. access through IP-Tool; 2. directly access through IE browser. 2.1.1 Access through IP-Tool Network connection: ①...
  • Page 8 situation. For example, the IP address of your computer is 192.168.1.4. So, the IP address of the camera shall be changed to 192.168.1.X. After modification, please enter the password of the administrator and click the “Modify” button to modify the setting. ...

  • Page 9: Directly Access Through Ie

    The system will pop up the above-mentioned textbox to ask you to change the default password. It is strongly recommended to change the default password for account security. If “Do not show again” is checked, the textbox will not appear next time.

  • Page 10: Wan

    Select “Properties” and then select internet protocol according to the actual situation (for example: IPv4). Next, click the “Properties” button to set the network of the PC. ② Open the IE browser and enter the default address of IP-CAM and confirm. ③...
  • Page 11 ① Make sure the camera is connected to the local network and then log in the camera via LAN and go to ConfigNetworkPort menu to set the port number. Port Setup ② Go to Config NetworkTCP/IP menu to modify the IP address. IP Setup ③...
  • Page 12 Router Setup ④ Open the IE browser and enter its WAN IP and http port to access. (For example, if the http port is changed to 81, please enter “192.198.1.201:81” in the address bar of web browser to access). Access through PPPoE dial-up ...

  • Page 13: Live View

    3 Live View After logging in, the following window will be shown. The following table is the instructions of the icons on the live view interface. Icon Description Icon Description Original size Zoom out Fit correct scale Zoom/Focus control Auto (fill the window) SD card recording indicator Full screen Sensor alarm indicator...
  • Page 14 Those smart alarm indicators will flash only when the camera supports those functions and the corresponding events are enabled. In full screen mode, double click on the mouse to exit or press the ESC key on the keyboard. Click AZ control button to show AZ control panel. The descriptions of the control panel are as follows: Icon Description...

  • Page 15: Network Camera Configuration

    4 Network Camera Configuration In the Webcam client, choose “Config” to go to the configuration interface. Note: Wherever applicable, click the “Save” button to save the settings. 4.1 System Configuration 4.1.1 Basic Information In the “Basic Information” interface, the system information of the device is listed. Some versions may support device ID and QR code.

  • Page 16: Date And Time

    Select the time zone and DST as required. Click the “Date and Time” tab to set the time mode. 4.1.3 Local Config Go to ConfigSystemLocal Config to set up the storage path of captured pictures and recorded videos on the local PC. There is also an option to enable or disable the bitrate display in the recorded files.
  • Page 17  SD Card Management Click the “Format” button to format the SD card. All data will be cleared by clicking this button. Click the “Eject” button to stop writing data to SD card. Then the SD card can be ejected safely. Snapshot Quota: Set the capacity proportion of captured pictures on the SD card.
  • Page 18 Weekly schedule Set the alarm time from Monday to Sunday for a single week. Each day is divided in one-hour increments. Green means scheduled. Blank means unscheduled. “Add”: Add the schedule for a special day. Drag the mouse to set the time on the timeline.
  • Page 19  Snapshot Settings Go to Config System Storage Snapshot to go to the interface as shown below.    Set the format, resolution and quality of the image saved on the SD card and the snapshot interval and quantity and the timing snapshot here. Snapshot Quantity: The number you set here is the maximum quantity of snapshots.

  • Page 20: Image Configuration

    4.2 Image Configuration Image Configuration includes Display, Video/Audio, OSD, Video Mask and ROI Config. 4.2.1 Display Configuration Go to ImageDisplay interface as shown below. The image’s brightness, contrast, hue and saturation and so on for common, day and night mode can be set up separately.
  • Page 21 Noise Reduction: Decrease the noise and make the image more thorough. Increasing the value will make the noise reduction effect better but it will reduce the image resolution. Defog: Activating this function and setting an appropriate value as needed in foggy, dusty, smoggy or rainy environment to get clear images. Backlight Compensation (BLC): Off: disables the backlight compensation function.

  • Page 22: Video / Audio Configuration

    Set full time schedule for common, day, night mode and specified time schedule for day and night. Choose “Schedule” in the drop-down box of schedule as shown below. Drag “ ” icons to set the time of day and night. Blue means day time and blank means night time.
  • Page 23 Three video streams can be adjustable. Resolution: The size of image. Frame rate: The higher the frame rate, the video is smoother. Bitrate type: CBR and VBR are optional. Bitrate is related to image quality. CBR means that no matter how much change is seen in the video scene, the compression bitrate will be kept constant.

  • Page 24: Osd Configuration

    Audio Encoding: G711A and G711U are selectable. Audio Type: LIN or MIC optional. MIC type is available for the model with built-in MIC interface. 4.2.3 OSD Configuration Go to ImageOSD interface as shown below. Set time stamp, device name, OSD content and picture overlap here. After enabling the corresponding display and entering the content, drag them to change their position.

  • Page 25: Roi Configuration

    To set up video mask: 1. Enable video mask. 2. Click the “Draw Area” button and then drag the mouse to draw the video mask area. 3. Click the “Save” button to save the settings. 4. Return to the live to verify that the area has been drawn as shown as blocked out in the image.

  • Page 26: Lens Control

    1. Check “Enable” and then click the “Draw Area” button. 2. Drag the mouse to set the ROI area. 3. Set the level. 4. Click the “Save” button to save the settings. 4.2.6 Lens Control This function is only available for the model with motorized zoom lens. Within this section, zoom and focus can be controlled.

  • Page 27: Ptz Configuration

    4.3 PTZ Configuration This function is only available for the model with RS485 interface. It can be used with a compatible external PTZ enclosure. Go to PTZProtocol interface as shown below. 4.4 Alarm Configuration 4.4.1 Motion Detection Go to AlarmMotion Detection to set motion detection alarm.
  • Page 28 1. Check “Enable” check box to activate motion-based alarms. If unchecked, the camera will not send out any signals to trigger motion-based recording to the NVR or CMS, even if there is motion in the video. Alarm Out: If selected, this would trigger an external relay output that is connected to the camera on detecting a motion-based alarm.

  • Page 29: Other Alarms

    Move the “Sensitivity” scroll bar to set the sensitivity. Higher sensitivity value means that motion will be triggered more easily. Select “Add” and click “Draw”. Drag the mouse to draw the motion detection area; Select “Erase” and drag the mouse to clear motion detection area. After that, click the “Save”...
  • Page 30 2. Click “Enable” and set the alarm holding time. 3. Set alarm trigger options. Trigger alarm out, Email and FTP. The setup steps are the same as motion detection. Please refer to motion detection chapter for details.  IP Address Conflict 1.

  • Page 31: Alarm In

    2. Click “Enable” and set the alarm holding time. 3. Trigger alarm out. When the camera is disconnected, the system will trigger the alarm out. 4.4.3 Alarm In To set sensor alarm (alarm in): Go to ConfigAlarmAlarm In interface as shown below. 1.

  • Page 32: Alarm Out

    4.4.4 Alarm Out This function is only available for some models. Go to ConfigAlarmAlarm Out. Alarm Out ID: For the model with two alarm output interfaces, please select the alarm out ID first as shown in the above left picture. Alarm Out Mode: Alarm linkage, manual operation, day/night switch linkage and timing are optional.

  • Page 33: Alarm Server

    Day/Night Switch Linkage: Having selected this mode, select the alarm type and then choose to open or close alarm out when the camera switches to day mode or night mode. Timing: Select the alarm type. Then click “Add” and drag the mouse on the timeline to set the schedule of alarm out;...

  • Page 34: Exception Settings

    Avoid places that have too much shadowing.  At any time of day or night, please make sure the image of the camera is clear  and with adequate and even light, avoiding overexposure or too much darkness on both sides. 4.5.1 Exception Settings This function can detect changes in the surveillance environment affected by the external factors.

  • Page 35: A-Lpr Settings

    Drag the slider to set the sensitivity value or directly enter the sensitivity value in the textbox. Click “Save” button to save the settings. The sensitivity value of Scene Change Detection: The higher the value is, the more sensitive the system responds to the amplitude of the scene change. The sensitivity value of Video Blur Detection: The higher the value is, the more sensitive the system responds to the blurriness of the image.
  • Page 36 To set the detection area: Click “Draw Area” and drag the border lines of the rectangle to modify its size. Click “Stop Draw” to stop drawing the area. Click “Clear” to clear the area. Then set the detectable size by defining the maximum value and the minimum value (The default size range of a single image occupies from 5% to 50% of the entire image).
  • Page 37  Add vehicles Click “Add” to show a vehicle adding box as shown in the above figure. Enter the license plate number, select list type, start and end time, enter owner and license plate type. Then click “Save” to save the vehicle. List type: unknown vehicle, allow list and block list can be selected.
  • Page 38 linkage” tab to go to the following interface. Set the fault tolerance, alarm list and check “alarm out”. Finally, click “Save” to save all the settings. Allow fault character(s) of the plate number: up to 2 characters are allowed. For example, if “2”...
  • Page 39 When the captured license plate is matched with the license plate of the comparison list, the list type will be displayed under the license plate number. Click the matched license plate picture, the matched details will pop up as shown below. ※...
  • Page 40 The depression angle of the camera will range from 10° to 15°.  If the camera is installed on the side of the road, the pan angle of the camera  shall range from 0° to 20°. If the camera is installed right above the middle of the road, the pan angle of ...

  • Page 41: Network Configuration

    If the captured license plate doesn’t meet the above requirement, you can adjust the pan angle of the camera to correct it. 4.6 Network Configuration 4.6.1 TCP/IP Go to ConfigNetworkTCP/IP interface as shown below. There are two ways for network connection. Use IP address (take IPv4 for example)-There are two options for IP setup: obtain an IP address automatically by DHCP and use the following IP address.

  • Page 42: Port

    frequently. To be notified, the IP change notification function can be used. Click “IP Change Notification Config” to go to the interface as shown below. Trigger Email: when the IP address of the device is changed, the new IP address will be sent to the email address that has been set up. Trigger FTP: when the IP address of the device is changed, the new IP address will be sent to FTP server that has been set up.

  • Page 43: Ddns

    1. Check “Enable”. 2. Check the IP address and port of the transfer media server in the ECMS/NVMS. Then enable the auto report in the ECMS/NVMS when adding a new device. Next, enter the remaining information of the device in the ECMS/NVMS. After that, the system will automatically allot a device ID.

  • Page 44: Snmp

    After the domain name is successfully applied for, the domain name will be listed as below. 3. Enter the username, password, domain you apply for in the DDNS configuration interface. 4. Click the “Save” button to save the settings. 4.6.5 SNMP To get camera status, parameters and alarm information and remotely manage the camera, the SNMP function can be used.

  • Page 45: 802.1X

    2. Check the corresponding version checkbox (Enable SNMPv1, Enable SNMPv2, Enable SNMPv3) according to the version of the SNMP software that will be used. 3. Set the values for “Read SNMP Community”, “Write SNMP Community”, “Trap Address”, “Trap Port” and so on. Please make sure the settings are the same as that of the SNMP software.

  • Page 46: Rtsp

    To use this function, the camera should be connected to a switch supporting 802.1x protocol. The switch can be reckoned as an authentication system to identify the device in a local network. If the camera connected to the network interface of the switch has passed the authentication of the switch, it can be accessed via the local network.

  • Page 47: Upnp

    “rtsp://IP address: rtsp port/profile2?transportmode=mcast”. Third stream: The address format is “rtsp://IP address: rtsp port/profile3?transportmode=mcast”. Audio: Having entered the main/sub stream in a VLC player, the video and audio will play automatically. If “Allow anonymous login…” is checked, there is no need to enter the username and password to view the video.

  • Page 48: Ftp

    Sender Address: sender’s e-mail address. User name and password: sender’s user name and password. Server Address: The SMTP IP address or host name. Select the secure connection type at the “Secure Connection” pull-down list according to what’s required. SMTP Port: The SMTP port. Send Interval(S): The time interval of sending email.

  • Page 49: Https

    Server Name: The name of the FTP server. Server Address: The IP address or domain name of the FTP. Upload Path: The directory where files will be uploaded to. Port: The port of the FTP server. User Name and Password: The username and password that are used to login to the FTP server.

  • Page 50: P2P (Optional)

    displayed. * If there is a signed certificate, click “Browse” to select it and then click “Install” to install it. * Click “Create a private certificate” to enter the following creation interface. Click the “Create” button to create a private certificate. Enter the country (only two letters available), domain (camera’s IP address/domain), validity date, password, province/state, region and so on.

  • Page 51: Qos

    4.6.13 QoS QoS (Quality of Service) function is used to provide different quality of services for different network applications. With the deficient bandwidth, the router or switch will sort the data streams and transfer them according to their priority to solve the network delay and network congestion by using this function.
  • Page 52 2. Enter user name in the “User Name” text box. 3. Enter the password in the “Password” and “Confirm Password” text box. Please set the password according to the requirement of the password security level (Go to ConfigSecurity Security ManagementPassword Security interface to set the security level).

  • Page 53: Online User

    3. Enter the old password of the user in the “Old Password” text box. 4. Enter the new password in the “New password” and “Confirm Password” text box. 5. Enter computer’s MAC address as necessary. 6. Click the “OK” button to save the settings. Note: To change the access level of a user, the user must be deleted and added again with the new access level.

  • Page 54: Security Management

    The setup steps are as follows: Check the “Enable address filtering” check box. Select “Block/Allow the following address”, IPv4/IPv6/MAC and then enter IP address or MAC address in the address box and click the “Add” button. 4.7.4 Security Management Go to ConfigSecuritySecurity Management as shown below. In order to prevent against malicious password unlocking, “locking once illegal login”...

  • Page 55: Maintenance Configuration

    You can choose one of them or any combination of them when setting the password. Medium Level: 9~15 characters, including at least two of the following categories: numbers, special characters, upper case letters and lower-case letters. Strong Level: 9~15 characters. Numbers, special characters, upper case letters and lower-case letters must be included.

  • Page 56: Reboot

    4.8.2 Reboot Go to ConfigMaintenanceReboot. Click the “Reboot” button to reboot the device. Timed Reboot Setting: If necessary, the camera can be set up to reboot on a time interval. Enable “Time Settings”, set the date and time and then click the “Save” button to save the settings.

  • Page 57: Search

    5 Search 5.1 Image Search Click Search to go to the interface as shown below. Images that are saved on the SD card can be found here.  Local Image Search Choose “Picture”— “Local”. Set time: Select date and choose the start and end time. Click to search the images.
  • Page 58  SD Card Image Search Choose “Picture”— “SD Card”. Set time: Select date and choose the start and end time. Choose the alarm events at the bottom of the interface. Click to search the images. Double click a file name in the list to view the captured photos. Click to return to the previous interface.

  • Page 59: Video Search

    5.2 Video Search 5.2.1 Local Video Search Click Search to go to the interface as shown below. Videos were recorded locally to the PC can be played in this interface. Choose “Record”— “Local”. Set search time: Select the date and choose the start and end time. Click to search the images.
  • Page 60 Icon Description Icon Description Play button. After pausing the video, click Pause button this button to continue playing. Stop button Speed down Speed up Watermark display Enable / disable audio; drag the slider to adjust the volume after enabling audio. 5.2.2 SD Card Video Search Click Search to go to the interface as shown below.

  • Page 61: Sd Card Video Search

    The time table can be shown in 24H/12H/2H/1H format by clicking the corresponding buttons. Video clip and downloading Search the video files according to the above-mentioned steps. Select the start time by clicking on the time table. Click to set the start time and then this button turns blue ( Select the end time by clicking on the time table.

  • Page 62: Appendix

    Appendix Appendix 1 Troubleshooting How to find the password? A：Reset the device to the default factory settings. Default IP: 192.168.226.201; User name: admin; Password: 123456 Fail to connect devices through IE browser. A: Network is not well connected. Check the connection and make sure it is connected well.
  • Page 63 No sound can be heard. A：Audio input device is not connected. Please connect and try again. B: Audio function is not enabled at the corresponding channel. Please enable this function.
  • Page 64 Specification /Model AVC-NBL21M-L1 Bullet Network Camera Image Sensor 1/2.8＂CMOS Image Size 1920×1080 Electronic Shutter 1/25s~1/100000s Iris Type DC Iris 0.0026lux@F1.2, AGC ON; 0 lux with IR; Min. llumination 0.005 lux@F1.4, AGC ON; 0 lux with IR 2.8~12mm@F1.4, (motorized), horizontal field of view:103.4°~32.4° Camera Lens 7~22mm@F1.4, (motorized), horizontal field of view:44°~17.6°...

  • Page 65: Appendix 2 Specifications
