Summary of Contents for Monoprice 10322
- Page 1 1x4 3G SDI Splitter P/N 10322 User's Manual...
-
Page 2: Safety Warnings And Guidelines
SAFETY WARNINGS AND GUIDELINES Please read this entire manual before using this device, paying extra attention to these safety warnings and guidelines. Please keep this manual in a safe place for future reference. This device is intended for indoor use only. ... - Page 3 Take care to prevent damage to the power cord. Do not allow it to become crimped, pinched, walked on, or become tangled with other cords. Ensure that the power cord does not present a tripping hazard. Never unplug the unit by pulling on the power cord. Always grasp the connector head or adapter body.
-
Page 4: Customer Service
If you have any problem with your order, please give us an opportunity to make it right. You can contact a Monoprice Customer Service representative through the Live Chat link on our website www.monoprice.com or via email at support@monoprice.com. Check the... -
Page 5: Package Contents
PACKAGE CONTENTS Please take an inventory of the package contents to ensure you have all the items listed below. If anything is missing or damaged, please contact Monoprice Customer Service for a replacement. 1x 1x4 3G SDI Splitter 1x AC Power Adapter (5 VDC, 1A) - Page 6 2. POWER: The LED illuminates when power is applied. 3. LOCK: The LED illuminates when an SDI input signal is detected. Rear Panel 1. INPUT: One BNC connector for connecting the SDI video source. 2. OUTPUT: Four BNC connectors for connecting four SDI displays. 3.
-
Page 7: Sample Connection Diagram
SAMPLE CONNECTION DIAGRAM... -
Page 8: Technical Support
TECHNICAL SUPPORT Monoprice is pleased to provide free, live, online technical support to assist you with any questions you may have about installation, setup, troubleshooting, or product recommendations. If you ever need assistance with your new product, please come online to talk to one of our friendly and knowledgeable Tech Support Associates. - Page 9 SD SDI: 984 ft. (300m) Maximum Transmission Distance HD SDI: 656 ft. (200m) 3G SDI: 328 ft. (100m) Input Power 5 ~ 12 VDC AC Adapter Output Power 5 VDC, 1A AC Adapter Input Power 100 ~ 240 VAC, 50/60 Hz Power Consumption 1.5 watts Operating Temperature...
