HDMI® to 3G SDI Converter
P/N 11749
User's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 11749 and is the answer not in the manual?

Questions and answers

Related Manuals for Monoprice 11749

Summary of Contents for Monoprice 11749

  • Page 1 HDMI® to 3G SDI Converter P/N 11749 User's Manual...

  • Page 2: Safety Warnings And Guidelines

    SAFETY WARNINGS AND GUIDELINES Please read this entire manual before using this device, paying extra attention to these safety warnings and guidelines. Please keep this manual in a safe place for future reference.  This device is intended for indoor use only. ...
  • Page 3 source, such as a fireplace, stove, radiator, etc. Do not leave it in direct sunlight.  Prior to operation, check the unit and power cord for physical damage. Do not use if physical damage has occurred.  Before plugging the unit into a power outlet, ensure that the outlet provides the same type and level of power required by the device.
  • Page 4  Ensure that power is turned off and disconnected before making any electrical connections.  Clean using a soft, dry cloth only. Do not use chemical cleaners, solvents, or detergents. For stubborn deposits, moisten the cloth with warm water.  This device has no user serviceable parts. Do not attempt to open, service, or modify this device.

  • Page 5: Customer Service

    300m for SD signals, 200m for HD signals, and 100m for 3G signals CUSTOMER SERVICE The Monoprice Customer Service department is dedicated to ensuring that your ordering, purchasing, and delivery experience is second to none. If you have any problem with your order, please give us an opportunity to make it right.

  • Page 6: Package Contents

    PACKAGE CONTENTS Please take an inventory of the package contents to ensure you have all the items listed below. If anything is missing or damaged, please contact Monoprice Customer Service for a replacement. 1x HDMI® to 3G SDI Converter 1x AC Power Adapter (5 VDC, 1A)

  • Page 7: Product Overview

    PRODUCT OVERVIEW 1. DC5V: DC barrel connector for connecting the included AC power adapter. 2. POWER: The LED illuminates when power is applied. 3. HDMI IN: HDMI® connector for connecting the HDMI video source. 4. OUT2: BNC connector for connecting an SDI display. 5.

  • Page 8: Sample Connection Diagram

    SAMPLE CONNECTION DIAGRAM...

  • Page 9: Technical Support

    TECHNICAL SUPPORT Monoprice is pleased to provide free, live, online technical support to assist you with any questions you may have about installation, setup, troubleshooting, or product recommendations. If you ever need assistance with your new product, please come online to talk to one of our friendly and knowledgeable Tech Support Associates.
  • Page 10 225 MHz/channel HDMI Video Bandwidth 675 MHz total 480i@60, 576i@50, 720p@50/59.94/60, Supported HDMI Video 1080i@50/59/94/60, Resolutions 1080p@23.98/24/25/29.97/ 30/50/59/94/60 2.970 Gbps and 2.970/1.001 SDI Transmission Rates Gbps Audio Formats LPCM 48kHz Input Power 5 VDC, 1A AC Adapter Input Power 100 ~ 240 VAC, 50/60 Hz Power Consumption 2.5 watts Operating Temperature...
  • Page 11 20 ~ 90& RH, Operating Humidity noncondensing 3.7" x 2.4" x 1.0" Dimensions (95 x 60 x 25 mm) Weight 9.2 oz. (260g) HDMI®, the HDMI Logo, and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries. Blu-ray Disc™, Blu-ray™, and the logos are trademarks of the Blu-ray Disc Association.
