- Page 1 Solar 200W 2.4kWh Extension Solution VERSION A0...
-
Page 2: Before Getting Started
Renogy is not responsible or liable for any failure, damage, or injury resulting from repair attempts by unqualified personnel, improper installation, or inappropriate operation. -
Page 3: System Wiring
Tray Cables 4 AWG 2 ft ANL 1000W 200Ah AGM Fuse Cable Battery Inverter 100A ANL Fuse 2. Get to Know Renogy Solar 200W 2.4kWh Extension Solution Battery █ 200Ah AGM Battery × 1 Charge Controller █ SELECT ENTER 5V 2.4A... -
Page 4: Solar Panels
Solar Panels █ × 8 × 4 × 4 × 4 × 8 × 4 × 8 200W Rigid Solar Panel × 1 Solar Panel Mounting Z Bracket × 1 15A Solar Connector Fuse × 1 12 AWG 10 ft Adapter Kit Solar Entry Gland ×... - Page 5 3. Required Tools & Accessories Phillips Wrench Wrench Screwdriver (#2) (7/16 in) (9/16 in) Impact Drill Phillips Driver Bit (#2) Masonry Drill Bit (21/64 in) Wire Stripper Ground Fault Circuit MS Adhesive and Interrupter (GFCI) (≥10A) MS Applicator Gun Slootted Screwdriver Insulating Gloves (4 mm) —...
- Page 6 4. How to Install the Solar Panel Mounting Z Bracket 70.8-106.2 in·lbs (8-12 N•m) Solar Panel — 06 —...
- Page 7 5. How to Install the Solar Entry Gland 12 AWG 10 ft Solar Panel to Charge Controller Adapter Kit Run the Adapter Kit Drill a hole in the RV roof. through the hole. Do not move the entry Apply MS gland before the MS adhesive to adhesive is fully dry.
- Page 8 Step 1. Connect the Charge Controller to the Battery Note: Connect the battery first and then the solar panel to avoid irreversible damage to the charge controller. 30A PWM Flush Mount STEP-1 Install the cables on the charge controller. Charge Controller SELECT ENTER 5V 2.4A...
- Page 9 30A PWM Flush Mount Charge Controller BT-1 Bluetooth Module SELECT POWER LINK ENTER BT-1 5V 2.4A Bluetooth Module ADVENTURER SOLAR CHARGE CONTROLLER My Renogy My Renogy RNG-CTRL-ADV30 HUB Mode NOT CHARGING Add Devices History PV Screen RNG-CTRL-ADV Total Energy Solar Volts...
- Page 10 Step 3. Connect the Solar Panel to the Charge Controller Note: Connect the battery first and then the solar panel to avoid irreversible damage to the charge controller. 200W Rigid Solar Panel STEP-1 Install a 15A Solar Connector Fuse STEP-2 Install the adapter kit on the solar panel. 15A Solar Connector Fuse...
- Page 11 Step 4. Install the Inverter and Loads STEP-1 Install the cables on the battery. 88.5 in·lbs (10 N·m) 200Ah AGM Battery 4 AWG 2 ft ANL Fuse Cable 88.5 in·lbs (10 N·m) 100A ANL Fuse STEP-2 Install a 100A ANL fuse 4 AWG 5 ft Battery Inverter Cables...
- Page 12 To explore more possibilities of solar systems, visit Renogy Learning Center at: renogy.com/learning-center For technical questions about your product in the U.S., contact the Renogy technical support team through: renogy.com/contact-us 1(909)2877111 For technical support outside the U.S., visit the local website below: Canada ca.renogy.com...
-
Page 13: Safety Information
Safety Information General z Wear proper protective equipment and use insulated tools during installation and operation. Do not wear jewelry or other metal objects when working on or around the devices. z Keep the devices out of the reach of children. z Do not dispose of the devices as household waste. - Page 14 Save 105 gallons of water from being consumed Renogy Power PLUS Renogy Power Plus allows you to stay in the loop with upcoming solar energy innovations, share your experiences with your solar energy journey, and connect with like-minded people who are changing the world in the Renogy Power Plus community.
