Dual Ultrawide Monitor Desk Mount
Instruction Manual
SKU: STAND-V038/W
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-v038
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
309-278-5303
Chat live with an agent!
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Vivo STAND-V038/W
Summary of Contents for Vivo STAND-V038/W
- Page 1 Dual Ultrawide Monitor Desk Mount Instruction Manual SKU: STAND-V038/W Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-v038 GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com...
- Page 2 WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
-
Page 3: Package Contents
PACKAGE CONTENTS A (x1) B (x1) C (x1) Pole Clamp Swivel Arm D (x2) E (x1) F (x1) VESA Plate Grommet Soft Pad Base Plate G (x1) H (x1) I (x1) Support Pole Cap Pole Cable Plate Clip J(x4) Arm Cable Clip S-A (x3) S-B (x2) -
Page 4: Assembly Steps
ASSEMBLY STEPS STEP 1 Loosen knob on Clamp (B). *** IMPORTANT NOTE *** Monitor mount can be assembled as a Desk Clamp (2a) or Grommet Mount (2b). Follow steps below for desired mounting method. STEP 2a - Desk Clamp Mount Clamp (B) to Pole (A) using M6x16mm Screws (S-A) and 3mm Allen Wrench (T-A). Secure assembly to desktop by tightening knob on Clamp (B). - Page 5 STEP 2b - Grommet Mount Using a Phillips screwdriver, remove the screw from Clamp (B) and disassemble. Set Knob (B2) aside. Mount Grommet Plate (E) to Pole (A) using M6x16mm Screws (S-A) and 3mm Allen Wrench (T-A). Remove adhesive backing from Soft Pad (F) and adhere to Grommet Plate (E).
- Page 6 STEP 3 Unfold Swivel Arm (C) and extend into one straight line. Slide Pole Cable Clip (I) and Swivel Arm (C) onto Pole (A). Secure Swivel Arm (C) in place using 6mm Allen Wrench (T-B). Attach Pole Cap (H) to Pole (A). Attach Arm Cable Clips (J) to Swivel Arm (C).
- Page 7 STEP 4 Secure VESA Plates (D) to monitors using M4x12mm Thumbscrews (M-A) or M4x30mm Screws (M-B). M6 Spacers (M-C) may be required.
- Page 8 STEP 5 Slide monitors with VESA Plates (D) onto Swivel Arm (C). Secure VESA Plates (D) in place using M6 Security Nuts (S-B). STEP 6 Manage cables using Arm Cable Clips (J) and Pole Cable Clip (I).
- Page 9 ADJUST AS DESIRED +90° to -90° TILT: If monitors are sagging or need repositioned, loosen the bolt on the side of the VESA Head (C1) on Swivel Arm (C). Use 6mm Allen Wrench (T-B) to loosen, then adjust. Tighten to secure. . 180°...
- Page 10 ADJUST MONITOR HEIGHT To level monitors, remove M6 Security Nuts (S-B) and tighten or loosen adjustment screws using 3mm Allen Wrench (T-A). Once level, fasten M6 Security Nuts (S-B) back into place.
- Page 11 [ THIS PAGE INTENTIONALLY LEFT BLANK ]...
- Page 12 : 1HR 8M (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
