Dual Ultrawide Monitor
Desk Stand
SKU: STAND-V038F
Instruction Manual
Assembly Video & Product Info
www.vivo-us.com/products/stand-v038f

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the STAND-V038F and is the answer not in the manual?

Questions and answers

Summary of Contents for Vivo STAND-V038F

  • Page 1 Dual Ultrawide Monitor Desk Stand SKU: STAND-V038F Instruction Manual Assembly Video & Product Info www.vivo-us.com/products/stand-v038f...
  • Page 2 If you do not understand these directions, or if you have any doubts about the safety of the installation, please contact our product support team at 309-278-5303 or help@vivo-us.com for further assistance. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
  • Page 3 Package Contents A (x1) B (x1) C (x1) Pole Base D (x2) E (x1) F (x1) VESA Plate Pole Cap Cover G (x4) H (x1) Arm Cable Pole Cable Clips Clip Included Hardware & Tools S-A (x2) M-A (x8) M-B (x8) M-C (x8) M6 Cap Nut M4x12mm...
  • Page 4 ASSEMBLY STEPS STEP 1 Slide Cover (F) and Pole Cable Clips (H) over Pole (A), then thread Pole into Base (B). Press Pole Cap (E) into the top of Pole. Lock Cover into place by tightening Set Screws using 3mm Allen Wrench (T-A). Set Screws STEP 2 Slide Arm (C) onto Pole (A) and secure at desired height using 6mm Allen Wrench (T-B).
  • Page 5 STEP 3 Install VESA Plates (D) onto your monitors using M4x12mm Thumbscrews (M-A) or M4x30mm Screws (M-B) and Spacers (M-C) if needed. Lightly tighten with a Phillips screwdriver. M-A (x4) - OR - Installation Tip: The “V” on VESA Plate should M-B (x4) be pointing down towards bottom edge of monitor.
  • Page 6 STEP 4 Slide your monitors with VESA Plate (D) onto Arm (C). Secure the VESA Plates (D) to the Arm using M6 Cap Nuts (S-A). S-A (x2) STEP 5 Route cables through Arm and Pole Cable Clips (G,H). WARNING Do not extend the arms past the base shown below...
  • Page 7 ADJUSTMENTS Adjust the tilt joint resistance using 6mm Allen Wrench (T-B). Remove the M6 Cap Nuts (S-A) and adjust the VESA height adjustment screws using 3mm Allen Wrench (T-A). Reinstall the M6 Cap Nuts. Height Adjustment Screw...
  • Page 8 LAST UPDATED: 11/22/23 REV1 v1.0 Need Help? Get In Touch Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com 309-278-5303 Chat live with an agent! FOR MORE GREAT VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: WWW.VIVO-US.COM VIVO-us @vivo_us...
