  • Page 1 Easy 12 C...
  • Page 3 INFORMATION ON SOLID FUEL HEATING APPLIANCES According to Regulation (EU) No. 1185/2015 Manufacturer Aico Model identifier(s) Easy 12 C Brand Ravelli Indirect heating functionality Direct heat output 11,3 kW Indirect heat output -- kW Other η Preferred fuel Space heating emissions at...

  • Page 5: Preface

    Incorrect installation, maintenance and improper use of the product relieve the Manufacturer of all liability deriving from use of the stove. For further information and requirements contact your Ravelli-authorised Technical Assistance Centre. All rights reserved. No part of this instructions manual can be reproduced or transmitted through any electronic or mechanical means, including photocopies, recordings or any other storage system, for other purposes that are not exclusively use by the buyer’s staff,...

  • Page 6: Table Of Contents

    Rev.0 23/03/2023 Use and maintenance manual Easy 12 C Pag.6 INDEX Preface..................................5 IDENTIFICATION .........................8 Stove identification ..............................8 Manufacturer identification ............................8 Reference standards ..............................8 Label ................................... 8 WARRANTY ..........................9 Warranty conditions ..............................9 Registration of warranty ............................9 Info and problems ..............................
  • Page 7 Rev.0 23/03/2023 Use and maintenance manual Easy 12 C Pag.7 PPROCEDURES FOR USE ......................26 Checks prior to start-up ............................26 Pellet auger loading ..............................26 Switching the appliance on and off ........................26 Failed ignition ................................27 Set of the room temperature ..........................27 Set of the working power ............................

  • Page 8: Identification

    Chiari (BS) - Italy T. + 39 030 7402939 info@ravelligroup.it www.ravelligroup.it Reference standards The Easy 12 C stoves that this manual refers to are compliant with the regulation: 305/2011, CONSTRUCTION PRODUCT REGULATION and the following directives 2014/53/EU (RED) 2011/65/EU 2015/863/EU, 2017/2102/EU, (RoHS)

  • Page 9: Warranty

    Info and problems Dealers authorised by Ravelli use a trained Technical Service Centre network to meet the Customer’s requirements. For any informa- tion or request for assistance, please contact your Dealer or the Technical Service Centre.

  • Page 10: General Information

    Rev.0 23/03/2023 Use and maintenance manual Easy 12 C Pag.10 GENERAL INFORMATION Supply and safe-keeping The manual is supplied in printed format. Keep this manual safe, with the appliance, so that the user can consult it easily. The manual is an integral part, for safety reasons, therefore: •...

  • Page 11: Residual Risks

    If the chimney catches fire you must call the fire brigade. ⚠ Only use original spare parts. Any tampering and/or replacements that have not been authorised by Ravelli can pose a danger to the user’s safety. ⚠ In the event of particularly adverse weather conditions, the safety systems could intervene and switch off the appliance.

  • Page 12: Description Of The Appliance

    Rev.0 23/03/2023 Use and maintenance manual Easy 12 C Pag.12 Residual Description procedure-related information risk When the appliance is running, it may reach high Risk of temperatures to the touch, especially on its external burns surfaces. Take care to avoid burns and use the specific tools if necessary.

  • Page 13: Obligations And Forbidden Actions

    Rev.0 23/03/2023 Use and maintenance manual Easy 12 C Pag.13 Obligations and forbidden actions Obligations The user must: • read this instructions manual before performing any operation on the appliance; • the appliance must not be used by children under the age of 8 or...

  • Page 14: Characteristics Of The Fuel

    A2 and B. Maintain fuels and other flammables at a suitable distance. Ravelli recommends using wood pellet classified A1 and A2 according to the EN ISO 17225-2:2014 standard, or certified DIN PLUS (more restrictive than the A1 class) or ONORM M 7135. Pellet may be light or dark coloured, it is normally bagged into bags that show the name of the producer, the main characteristics and classification according to standards.

  • Page 15: Technical Characteristics

    The data shown here is provided as a guideline and is not binding, and may change based on what type and quality of wood is used. Ravelli reserves the right to make any changes in order to improve product performance.

  • Page 16: Measurements

    Rev.0 23/03/2023 Use and maintenance manual Easy 12 C Pag.16 Measurements Unit of Easy 12 C measurement Height 1076 Width Depth Weight Technical diagram Easy 12 C 103,5 103,5 Ø50 AIR INLET Ø80 CANALISATION Ø80 CANALISATION TERMINALS FOR ROOM PROBES Ø80 SMOKE OUTLET...

  • Page 17: Main Parts

    Description of operation Ravelli Easy 12 C pellet stoves are appliances for domestic heating powered by wood pellets with automatic loading. They are suitable for use as a secondary heating system or as a support for the main heating system.

  • Page 18: User Training

    User training Once installation is complete, the user must always be fully trained in the functions and characteristics of the stove by the technician authorized by Ravelli to ensure optimal and safe use. The training should cover the following topics: •...

  • Page 19: Shipping And Installation

    Rev.0 23/03/2023 Use and maintenance manual Easy 12 C Pag.19 SHIPPING AND INSTALLATION Safety warnings for transportation and installation �� The appliance must be installed by a qualified technician, who must issue a declaration of conformity of the system to the purchaser, taking full responsibility for appliance installation and correct operation.

  • Page 20: Set-Ups For The Smoke Evacuation System

    Rev.0 23/03/2023 Use and maintenance manual Easy 12 C Pag.20 ⚠ Use suitable equipment to remove the boards or wooden parts of packing. �� The end user is responsible for disposing of the packaging in accordance with the laws in force in the country of installation.

  • Page 21: Installation

    �� Ravelli shall not be held liable if these precautions are not followed. Requirements for the installation premises The appliance installation room must be sufficiently ventilated. To fulfil this requisite it is necessary to equip the room with an air intake connected to the outdoors.
  • Page 22 Rev.0 23/03/2023 Use and maintenance manual Easy 12 C Pag.22 Installation example This type of installation (See Fig.1) requires an insulated chimney pot, even if the entire conduit is installed inside the building. Besides, the structure must be inserted into a properly ventilated skylight shaft.
  • Page 23 Rev.0 23/03/2023 Use and maintenance manual Easy 12 C Pag.23 This type of installation (See Fig.4) requires an insulated chimney pot, even if the entire smoke conduit is installed outside the Protection from rain building. In the lower part of the chimney there is a "T" type fitting installed with inspection cap.

  • Page 24: Connections

    Rev.0 23/03/2023 Use and maintenance manual Easy 12 C Pag.24 CONNECTIONS �� The connections must be set up by a technician that is qualified and/or authorised by the Manufacturer. �� By the installer the type of cable, with relative section, to be installed in case of replacement is: H05RR-F sez.3G0,75 Connection with external air intake The stove has been designed for hermetic installations.

  • Page 25: Connection Of External Thermostat

    Rev.0 23/03/2023 Use and maintenance manual Easy 12 C Pag.25 Connection of external thermostat To manage the stove using an external thermostat (optional), connect it to the appropriate “TERM” terminals on the board, as shown in the Electric scheme. ��...

  • Page 26: Description Of The Functioning And Symbology Of The Display

    Rev.0 23/03/2023 Use and maintenance manual Easy 12 C Pag.26 DESCRIPTION OF THE FUNCTIONING AND SYMBOLOGY OF THE DISPLAY The display of the handheld set is described below (in “Home” mode): Key OK, on/off Date Clock Key 2, increase value...

  • Page 27: Failed Ignition

    Rev.0 23/03/2023 Use and maintenance manual Easy 12 C Pag.27 Failed ignition If the system does not detect the ignition of the flame within the preset time, operation will be blocked with the “No ignition” alarm. Before relighting the stove, check that there are pellets in the hopper, that the door and ash drawer compartment are closed, that there are no obstructions to the combustion air inlet system and above all that, in models without self-cleaning fire pot, the fire pot is empty, clean and correctly positioned.

  • Page 28: Set Of The Working Power

    Rev.0 23/03/2023 Use and maintenance manual Easy 12 C Pag.28 Set of the working power To modify the working power press key 2 to enter in the dedicated menu and with keys 1 and 2 to set the power you desire from 1 to 5 and confirm with key OK.
  • Page 29 Rev.0 23/03/2023 Use and maintenance manual Easy 12 C Pag.29 The submenus of the USER MENU (the only one accessible for the end user) are the following: • Menu STOVE STATUS • Menu SET TEMPER. ROOM • Menu SET POWER •...
  • Page 30 Rev.0 23/03/2023 Use and maintenance manual Easy 12 C Pag.30 Menu SET TEMPERATURE ROOM To modify the setting please reference to paragraph “Set of the room temperature” Menu SET POWER To modify the setting please reference to paragraph “Set of the working power”...
  • Page 31 Rev.0 23/03/2023 Use and maintenance manual Easy 12 C Pag.31 Description Description Settable values START From OFF to 23:50 by step of 10’ STOP From OFF to 23:50 by step of 10’ On/off for the days from Monday to Sunday...
  • Page 32 Rev.0 23/03/2023 Use and maintenance manual Easy 12 C Pag.32 Menu COMFORT CLIMA To modify the settings use keys 1 and 2 and by pressing OK you confirm the data and go on to the following one. By last confirmation with OK you save all settings and return automatically to the screen with the icons.
  • Page 33 Rev.0 23/03/2023 Use and maintenance manual Easy 12 C Pag.33 Mode SILENCE Enable or disable the function by using key OK. Mode SILENCE has been realized for reducing noise level of fan. It reduce the speed of the fan in all five working power.

  • Page 34: Remote Control

    Rev.0 23/03/2023 Use and maintenance manual Easy 12 C Pag.34 In the menu VIEW WORKING HOURS you can check the total or partial working hours and also the number of ignitions of the stove. This menu is used by the After Sales Center to evaluate the total working hours of the stove during the season and consequently to evaluate the need of cleaning (“service hours”).

  • Page 35: Double Ducting

    Rev.0 23/03/2023 Use and maintenance manual Easy 12 C Pag.35 Double ducting This function allows you to manage distribution of warm air between the room where the stove is installed and the room where the duct arrives. The function has two operating modes: manual and automatic.
  • Page 36 Rev.0 23/03/2023 Use and maintenance manual Easy 12 C Pag.36 The upper part of the display allows you to change the power of the front venti- lation. The settable value ranges from 0 (fan off) to 5. With setting on A (auto) the power of the fans follows the power of the stove.
  • Page 37 Rev.0 23/03/2023 Use and maintenance manual Easy 12 C Pag.37 Modify the setting with keys 1 “decrease” and 2 “increase”. You may choose from three options: = (EQUAL): if the cubature of the two rooms are more or less the same;...

  • Page 38: Stove Phase General Layout

    Rev.0 23/03/2023 Use and maintenance manual Easy 12 C Pag.38 Stove phase general layout Phase Description FINAL CLEANING The stove is switching off, the cooling phase is not yet completed IGNITION The ignition phase has started,the pellets are loaded into firebox...

  • Page 39: Description Of Alarms

    Rev.0 23/03/2023 Use and maintenance manual Easy 12 C Pag.39 Description of alarms Warning Reason Solution Press the off button and repeat switching on the No electricity supply during working phase stove AL 01 BLACK - OUT If the problem continues, contact the area Techni- cal Assistance Centre.

  • Page 40: Maintenance

    Rev.0 23/03/2023 Use and maintenance manual Easy 12 C Pag.40 MAINTENANCE ⚠ Safety warnings for maintenance Maintenance of the stove must be performed at least once a year and should be planned in advance with the Technical ⚠ Assistance Service.
  • Page 41 Rev.0 23/03/2023 Use and maintenance manual Easy 12 C Pag.41 Fire pot cleaning It is necessary to check that the fire pot where combustion takes place is well cleaned and that slag or residues do not obstruct the holes. This precaution will ensure excellent combustion, avoiding the failed ignition of the stove. Cleaning must be carried out daily, before each ignition.

  • Page 42: Extraordinary Maintenance

    Schedule the above extraordinary maintenance activities with the Authorised Assistance Centre. Deep combustion chamber cleaning �� This operation must be carried out by a Ravelli Assistance Centre. �� Schedule this type of cleaning with the Ravelli Assistance Centre. To clean the combustion chamber, proceed as described below:...
  • Page 43 Rev.0 23/03/2023 Use and maintenance manual Easy 12 C Pag.43 Loosen...
  • Page 44 Checking the gaskets �� This operation must be carried out by a Ravelli Service Centre. Plan this type of cleaning with the Ravelli Service Centre. When thoroughly cleaning the stove, the authorised technician must check that the gaskets of - door - inspection hatches are intact.

  • Page 45: Troubleshooting

    Rev.0 23/03/2023 Use and maintenance manual Easy 12 C Pag.45 TROUBLESHOOTING The appliance does not work • Closely follow the directions in the dedicated chapter of this manual; • make sure that the air intake duct is not obstructed; •...
  • Page 46 Rev.0 23/03/2023 Use and maintenance manual Easy 12 C Pag.46 - Cables - Motors - Fans - Circulators - Displays ELECTRICAL AND - Sensors ELECTRONIC - Spark plugs COMPONENTS - Electronic boards - Batteries Dispose of separately at authorised centres, in accordance with WEEE 2012/19/EU and its national...
  • Page 47 ITA-Informazioni per la gestione di rifiuti di apparecchiature elettriche ed elettroniche contenenti pile e accumulatori Questo simbolo che appare sul prodotto, sulle pile, sugli accumulatori oppure sulla loro confezione o sulla loro documentazione, indica che il prodotto e le pile o gli accumulatori inclusi al termine del ciclo di vita utile non devono essere raccolti, recuperati o smaltiti assieme ai rifiuti domestici.
  • Page 48 ESP-Información para la gestión de residuos de aparatos eléctricos y electrónicos con pilas y acumuladores Este símbolo que aparece en el producto, en las pilas, los acumuladores o en su embalaje o su documentación indica que el producto y las pilas o acumuladores que contiene, al final de su vida útil, no deben recogerse, recuperarse o desecharse junto con los residuos domésticos.
  • Page 52 Aico S.p.A. Headquarter Via Consorzio Agrario, 3/D - 25032 Chiari (BS) - Italy Research and Development Centre Viale del commercio 12/a - 37135 Verona (VR) - Italy T. + 39 030 7402939 info@ravelligroup.it FB Ravellifuocointelligente IG ravellistufe www.ravelligroup.it Aico S.p.A. does not assume any responsibility for any errors in this booklet and considers itself free to make any variations to the features of its products without notice.
