- Page 1 For USA-CANADA (110v - 60 hZ - °F) INSTALLER’S MANUAL FOR “FLOW LINE, DESIGN LINE & BOX LINE” models (for models with FLASH motherboard)- 01/NOV. 6th- 2008 Rev.1...
- Page 2 Introduction 1. How a stove is made 1 - pellet feeding auger 2 - pellet ignitor 3 - fi re pot 4 - smoke duct 5 - air inlet pipe 6 - stainless steel exchanger 7 - pellet hopper 8 - fl ame trap 9 - exhaust vent pipe 10 - smoke temperature probe...
- Page 3 Black Condensatore Blue Brown Brown EXHAUST FAN Blue ROOM FAN Brown Green Introduction Blue Green Blue Black Black Condensatore Green Blue Blue CAPACITOR Blue Brown Brown Black Black Brown 2. Components of a pellet stove Blue ROOM FAN Brown Blue Blue White Black...
- Page 4 Introduction Revs encoder connector Capacitator EXHAUST BLOWER Rotor ( bell ) Blade in self-cleaning steel Blower body ROOM AIR BLOWER Blower Capacitator Faston Laminar pack ROOM AIR BLOWER Blower Silicon dust shield...
- Page 5 Introduction Faston electric connection Shaft Rotor GEAR-MOTOR Motor pack Aluminium body 10-pole connector 7-pole connector 2-pole connector 6-pole connector 4-pole connector Fuse Flash memory 2-pole connector Chronothermostat Flat cable connector ELECTRONIC MOTHERBOARD FLAT CABLE DISPLAY ( Connects from display to motherboard )
- Page 6 Introduction The vACUUM SWITCH is an electro-mechanical safety device that guarantees that the smoke duct is always free. It works by depression. The HOPPER THERMOSTAT WITH MANUAL RESET checks that the hopper POWER SWITCH temperature never exceeds 90°C (194°F). Blue Brown The SMOKE PROBE constantly measures the temperature of the stove’s EXHAUST FAN...
-
Page 7: Table Of Contents
Brochure for models with FLASH motherboard PAGE ( firmware version ECT2008air - & ECT2008box - ) Table of contents Page Operating conditions of a stove with ECT2008 AIR/BOX firmware ..........Page 1.1 Initial message ......................... Page 1.2 Initial conditions of a stove ....................... Page 1.2.1 “Cold”... - Page 8 Brochure for models with FLASH motherboard PAGE ( firmware version ECT2008air - & ECT2008box - ) Pellet stove operating statuses ....................... Page Operations linked to the “Final Clean” phase ................... Page 6.1 “Final clean” without Re-ignition attempt ..................Page 6.2 “Final clean” with Re-ignition attempt ..................Page Temperature settings ........................
-
Page 9: Initial Message
Brochure for models with FLASH motherboard PAGE ( fi rmware version ECT2008air - & ECT2008box - ) 1. 1. OPERATING CONDITIONS OF A STOvE WITH FIRMWARE ECT2008AIR/BOX 1.1. Initial message A few seconds after stove is switched ON, the message shown in the following fi gure appears: -vER. -
Page 10: Cold" Ignition Phase
Brochure for models with FLASH motherboard PAGE ( firmware version ECT2008air - & ECT2008box - ) 1.2.1 “COLD” ignitiOn phase - stOVe statUs “COLD“ this phase refers to every ignition phase with a temperature below the minimum threshold (pR 13) a pellet stove in these conditions functions in 5 phases: a - ignitiOn phase B - FLaMe staBiLiZatiOn phase... -
Page 11: 1-E Comfort Climate
Brochure for models with FLASH motherboard PAGE ( fi rmware version ECT2008air - & ECT2008box - ) C - Work phase DispLaY shOWing “WORK”: the stove carries out all the powers from pR 01 until it reaches the set one, while the heat exchanger, if the pR 15 “eXChangeR thReshOLD”... - Page 12 Brochure for models with FLASH motherboard PAGE ( firmware version ECT2008air - & ECT2008box - ) eXaMpLe: See user and maintance manual for air stoves /9.3 CONFORT CLIMATE n.B.: the functioning of the stove in COMFORt CLiMate mode can start up the phase of ignition and switching off several times through the day;...
- Page 13 Brochure for models with FLASH motherboard PAGE ( firmware version ECT2008air - & ECT2008box - )
-
Page 14: Hot Re-Ignition Phase
Brochure for models with FLASH motherboard PAGE ( firmware version ECT2008air - & ECT2008box - ) 1.2.2 “hOt” Re-ignitiOn phase - stOVe statUs “hOt“ this phase refers to every ignition cycle with temperature below the re-start threshold (pR 11), in any case over the minimum threshold (pR 13,say when the stoves is already hot). - Page 15 Brochure for models with FLASH motherboard PAGE ( firmware version ECT2008air - & ECT2008box - )
-
Page 16: Pellet-Air Blend Setting
Brochure for models with FLASH motherboard PAGE ( fi rmware version ECT2008air - & ECT2008box - ) 2.0 sUppLeMentaRY FUnCtiOns 7-KeY DispLaY (aiR models) in addition to the phases described in section 1, functions exist that can be activated on the display: •... - Page 17 Brochure for models with FLASH motherboard PAGE ( fi rmware version ECT2008air - & ECT2008box - ) DRaUght peLLet Values pellet From 0 to 5 to decrease the pellet load. Default value that considers the set combustion as excellent to increase the pellet load From 0 to 5 Values Draught...
-
Page 18: Chronothermostat Setting" Menu
Brochure for models with FLASH motherboard PAGE ( firmware version ECT2008air - & ECT2008box - ) 2.7 “CLOCK setting“ menu to set the clock, proceed as follows: 1. Keep button p4 pressed for 2 seconds, MenU 01 set CLOCK will appear and confirm with p6. 2. -
Page 19: Select Language" Menu
Brochure for models with FLASH motherboard PAGE ( firmware version ECT2008air - & ECT2008box - ) 2.9 SETTING THE LANGUAGE (LANGUAGE MENU, STATUS STOVE ON) To set the language, proceed as follows: 1. Keep button P4 pressed for 2 seconds, CLOCK SETTING MENU will appear. 2. -
Page 20: Supplementary Functions - Inserts
Brochure for models with FLASH motherboard PAGE ( firmware version ECT2008air - & ECT2008box - ) 3.0 sUppLeMentaRY FUnCtiOns FOR inseRts For the inserts , all the operations described in paragraph 2.0. are repeated. the difference between the two versions is found in the combinations of keys used to access motherboard programming. the display allows activation of the following functions: - seLeCtiOn OF ReCeipt aCCORDing tO tYpe OF instaLLatiOn (protected by B9) - RapiD aCCess MenU... - Page 21 Brochure for models with FLASH motherboard PAGE ( firmware version ECT2008air - & ECT2008box - ) 3.4 Rapid access menu DesCRiptiOn KeY COMBinatiOns aCCess tO stove, auger, exhaust blower and smoke temperature p5 for 4 sec statUs MenU status p4 for 4 sec COMFORt CLiMate see point e par.
- Page 22 Brochure for models with FLASH motherboard PAGE ( firmware version ECT2008air - & ECT2008box - ) 3.10 “ChOOse LangUage“ Menu to set the language, proceed as follows: 1. press button p7, CLOCK setting MenU will appear. 2. press button p1 2 times: the display will show LangUage seLeCtiOn MenU. 3.
- Page 23 Brochure for models with FLASH motherboard PAGE ( firmware version ECT2008air - & ECT2008box - ) 4.1 smoke temperature probe alarm this occurs if the smoke detection probe is faulty or disconnected. 4.2 hot smoke and smoke over-temperature alarm hot smoke: this is triggered not as a real alarm but as a warning that the maximum threshold pR14 has been reached. When it is in this condition, although leaving the heat exchanger at p5, the motherboard reduces the pellet load and draught to p1 in order to cool the body and the sMOKe teMp.
- Page 24 Brochure for models with FLASH motherboard PAGE ( firmware version ECT2008air - & ECT2008box - ) 4.9 smoke fan fault alarm if the exhaust blower is faulty or the encoder does not read the number of revs, even just because the reading cable is discon- nect or broken.
- Page 25 Brochure for models with FLASH motherboard PAGE ( firmware version ECT2008air - & ECT2008box - ) 5.0 OpeRating COnDitiOns OF a peLLet stOVe...
-
Page 26: Operations Linked To The "Final Clean" Phase
Brochure for models with FLASH motherboard PAGE ( firmware version ECT2008air - & ECT2008box - ) 6.0 OpeRatiOns LinKeD tO “FinaL CLean” phase the purpose of the “FinaL CLean” phase is to burn all pellets in the fire pot during the extinction phase. in fact the smoke extractor is activated at maximum revs per minute. -
Page 27: Temperature Settings
Brochure for models with FLASH motherboard PAGE ( firmware version ECT2008air - & ECT2008box - ) 7.0 teMpeRatURe settings 7.1 settings via DispLaY Room temperature can be changed using keys p4 and p5 (p4 to display the temperature setting and p1 and p2 to change the values in the BOX version). -
Page 28: Operating Procedures With External Thermostat
Brochure for models with FLASH motherboard PAGE ( firmware version ECT2008air - & ECT2008box - ) 7.2.2 OpeRating pROCeDURes With eXteRnaL theRMOstat Keeping the ambient probe connected (aiR version) to pin 7-8, connect the external thermostat. Bringing the temperature setting to the value “-est” you totally exclude the internal probe (or probe located on the remote control for the BOX version) reading and in this way the temperature setting only depends on the external thermostat. -
Page 29: Safety Device For Auger When Opening Hopper Door
Brochure for models with FLASH motherboard PAGE ( fi rmware version ECT2008air - & ECT2008box - ) 8.1 SAFETY DEVICE FOR AUGER WHEN OPENING HOPPER DOOR When you are feeding wood pellet into the hopper, we advice to stop the stove before operation; if you just need to check into hopper the level of wood pellets, for your safety as soon as you will open pellet door, the auger will stop automatically the feeding of the pellet;... - Page 30 Brochure for models with FLASH motherboard PAGE ( firmware version ECT2008air - & ECT2008box - ) Schema elettrico stufe “AIR” versione America aiR models (Usa-CanaDa)
- Page 31 Brochure for models with FLASH motherboard PAGE Schema elettrico stufe “AIR” versione America ( firmware version ECT2008air - & ECT2008box - ) aiR plus models (Usa-CanaDa)
-
Page 32: Firmware
Brochure for models with FLASH motherboard PAGE ( firmware version ECT2008air - & ECT2008box - ) 9.0 FIRMWARE The firmware is the software part of the electronic motherboard. It is composed of a series of instructions that allow the stove to be managed. IMPORTANT!!! The firmware must not be confused with the parameters. - Page 33 Brochure for models with FLASH motherboard PAGE ( firmware version ECT2008air - & ECT2008box - )
