SERVICE AND TECHNICAL
SUPPORT MANUAL
Single Stage, PSC Blower Motor
F9MES (A Series) 220−V 50Hz
Save this manual for future reference.
Safety Labeling and Signal Words
DANGER,
WARNING,
. . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . .
. . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . .
. . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . .
. . . . . . .
. . . . . . . . . .
. . . . . . . . . . . . . . . . .
. . . . . . . . .
. . . . . . . . . . . . . . . . . . . . .
Signal Words in Manuals
The signal word WARNING is used throughout
this manual in the following manner:
WARNING
!
The signal word CAUTION is used throughout
this manual in the following manner:
CAUTION
!
Signal Words on Product Labeling
Signal words are used in combination with
colors and/or pictures or product labels.
Safety−alert symbol
When you see this symbol on the unit and in
instructions or manuals, be alert to the
potential for personal injury.
3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4
4
10
11
11
11
11
12
13
14
14
15
15
15
17
18
F9MES1002120A
18
F9MES1202420A
19
F9MES1402420A
19
. . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . .
MODELS
440 04 4900 02
12/5/2013
20
21
23
25
27
28
28

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the F9MES Series and is the answer not in the manual?

Questions and answers

Summary of Contents for ICP F9MES Series

  • Page 1: Table Of Contents

    SERVICE AND TECHNICAL SUPPORT MANUAL Single Stage, PSC Blower Motor 35” Tall, High Efficiency Condensing Gas Furnace F9MES (A Series) 220−V 50Hz Save this manual for future reference. Safety Labeling and Signal Words DANGER, WARNING, CAUTION, and NOTE Signal Words in Manuals signal words DANGER,...
