(3 WIRES 120/240 – 60 – 1)
MULTI POSITION
INSTALLER / SERVICE TECHNICIAN:
USE THE INFORMATION IN THIS MANUAL FOR THE INSTALLATION AND
SERVICING OF THE FURNACE AND KEEP THE DOCUMENT NEAR THE
UNIT FOR FUTURE REFERENCE.
HOMEOWNER:
PLEASE KEEP THIS MANUAL NEAR THE FURNACE FOR FUTURE
REFERENCE.
Printed in Canada
Printed on 100% recycled paper
Models:
FEM10-M2401AM-A
FEM15-M2401AM-A
FEM18-M2401AM-A
FEM20-M2401AM-A
FEM23-M2401AM-A
FEM20-M2401BM-A
FEM23-M2401BM-A
FEM27-M2401BM-A
Caution: Do not tamper with
the unit or its controls. Call a
qualified service technician.
Manufactured by:
UTC Canada Corporation
ICP Division
3400 Industrial Boulevard
Sherbrooke, Quebec - Canada
J1L 1V8
2008-05-27
X40131 Rev. M
