ICP F9MXE0801716A1 Installation Instructions Manual

HJJ(J|)i(i)))_J))1))
These instructions must be read and understood completely before attempting installation.
Safety Labeling and Signal Words
DANGER, WARNING, CAUTION, and NOTE
The signal words DANGER, WARNING,
CAUTION, and NOTE are used to identify levels of
hazard seriousness. The signal word DANGER is
only used on product labels to signify an immediate
hazard. The signal words WARNING, CAUTION,
and NOTE will be used on product labels and
throughout this manual and other manual that may
apply to the product.
DANGER - Immediate hazards which will result in
severe personal injury or death.
Signal Words in Manuals
The signal word WARNING is used throughout
this manual in the following manner:
The signal word CAUTION is used throughout
this manual in the following manner:
WARNING - Hazards or unsafe practices which
could result in severe personal injury or death.
CAUTION - Hazards or unsafe practices which
may result in minor personal injury or product or
property damage.
NOTE - Used to highlight suggestions which will
result in enhanced installation, reliability, or
operation.
TABLE OF CONTENTS
Signal Words on Product Labeling
Signal words are used in combination with
colors and/or pictures or product labels.
Z_ Safety-alert symbol
When you see this symbol on the unit and in
instructions or manuals, be alert to the
potential for personal injury.
SAFETY CONSiDERATiONS ....................................... 3
iNTRODUCTiON ............................................... 4
CODES AND STANDARDS ........................................ 4
ELECTROSTATIC DISCHARGE (ESD) PRECAUTIONS PROCEDURE ........... 5
DIMENSIONS ................................................. 6
LOCATION ................................................... 7
LOCATION RELATIVE TO COOLING EQUIPMENT ........................ 9
AiR FOR COMBUSTION AND VENTiLATiON ............................ 9
CONDENSATE TRAP ............................................ 12
iNSTALLATION ................................................ 18
UPFLOW INSTALLATION ......................................... 18
DOWNFLOW INSTALLATION ....................................... 19
HORIZONTAL INSTALLATION ...................................... 22
FILTER ARRANGEMENT ......................................... 24
AiR DUCTS ................................................... 26
GAS PiPiNG .................................................. 26
ELECTRICAL CONNECTIONS ...................................... 28
J-BOX iNSTALLATION ........................................... 29
VENTING .................................................... 35
SPECIAL VENTING REQUIREMENTS FOR INSTALLATIONS iN CANADA ........ 35
DIRECT VENT / 2-PIPE SYSTEM ................................... 41
VENTILATED COMBUSTION AiR .................................... 41
TERMINATION REQUIREMENTS FOR THE
PROVINCES OF ALBERTA AND SASKATCHEWAN ....................... 41
iNSTALLING THE VENT TERMINATION ............................... 46
MAXIMUM EQUIVALENT VENT LENTH ............................... 50
MAXIMUM ALLOWABLE EXPOSED VENT LENGTHS iN
UNCONDITIONED SPACE - SINGLE STAGE .......................... 51
MAXIMUM ALLOWABLE EXPOSED VENT LENGTHS iN
UNCONDITIONED SPACE - TWO-STAGE ............................ 52
IS0 9001)
Use of the AHRI Certified TM Mark indicates a
manufacturer's participation in the program,
For verification of certification for individual
products, go to www,ahridirectory.org .
INSTALLER: Affix these instructions on or adjacent to the
furnace,
CONSUMER: Retain these instructions for future
reference.
