(c) Event icon
The icon display differs depending on the setting.
NOTE
Depending on the indoor unit settings, [Custom auto] may
be displayed instead of [Auto].
■ Event icon example
Event
icon
Icon color
Blue
Green
Red
Purple
Blue and red Custom
White
Black
(d) Active marker
Appears on the icon that is selected or being set.
(e) Event selector
The same number of points as the icons are displayed at
regular intervals. If the icons are overlapping and difficult
to select, tap here.
(f) Setting menu
Set event details. Tap to move to each setting screen.
Set the following items.
• Operation mode (refer to 3-1-4.)
• Set Temp. (refer to 3-1-5.)
• Time (refer to 3-1-6.)
• Operation Setting (refer to 3-1-7.)
(g) Add Event button
Tap here to create a new event or add one.
(h) Delete button
Tap here to delete the event with the active marker dis-
played.
En-9
Detail
Mode Set temperature
Cool 28.0°C
Dry 28.0°C
Heat or 24.0°C
10°C (50°F)
heat
Auto 26.0°C
Cool: 28.0°C
auto Heat: 23.0°C
Fan —
Operation stop
3-1-4

Operation mode screen

(a)
(b)
(a) Operation mode menu
Select and tap a operation mode. Swipe up or down on
any hidden items.
NOTE
If set "3-1-7 Operation Setting screen" to "Off", do not
need to set this item.
(b) Cancel button
Tap to display a confirmation screen. Tap [OK] on the
confirmation screen to return to the previous screen.
(c) OK button
Tap to confirm the setting and return to the previous
screen.
3-1-5

Set Temp. screen

(b)
(a) Temperature setting button
Tap the button to set the temperature.
NOTES
• This item cannot be set when "10°C (50°F) heat" or "Fan"
mode is selected in "3-1-4 Operation mode screen".
• If set "3-1-7 Operation Setting screen" to "Off", do not
need to set this item.
(b) Cancel button
Tap to display a confirmation screen. Tap [OK] on the
confirmation screen to return to the previous screen.
(c)
(a)
(c)
