ASSEMBLY INSTRUCTIONS

ASSEMBLY STEP (1)

Step 1: Remove the main frame group (1) from the package, open the main frame group in
the direction indicated by the arrow, and place the main frame group on the ground side in
the direction of the above figure and align the corresponding pin holes. Then insert the
three pins d10*60(4) into the pin holes respectively(as shown inthe figure above).
ASSEMBLY STEP (2)
Step 2: Assemble the front and rear stabilizer tubes, they are the same size and with same
step.
Set (2) on the main frame (1), use 2 hexagonal cap nuts M8(3.1), 2 curved washers
d8(3.2), and 2 semicircular head square necks to bolt 3.3, use an open wrench (6) to lock
the nut clockwise.
