  • Page 3 EXPRESS SERVICE … Get your vehicle serviced in 1 hour at no additional cost. Contact your nearest Dealership for details. … Facility available at selected Dealerships only. Terms and conditions apply...

  • Page 4: Expert On Wheels

    EXPERT ON WHEELS Busy Life? Easy Servicing! Now, service your bike anywhere, anytime. Service the vehicle at your door step. Available for regular maintenance or breakdown service only. Offered at nominal convenience charges. … Contact your nearest Dealership for details. …...

  • Page 5: Pickup And Drop

    PICKUP AND DROP Busy Life? Easy Servicing! Now, service your bike anywhere, anytime. Service the vehicle at your door step. Available for regular maintenance or breakdown service only. Offered at nominal convenience charges … Contact your nearest Dealership for details. …...

  • Page 6: Table Of Contents

    CONTENTS EXPRESS SERVICE EXPERT ON WHEELS PICKUP AND DROP CONTENTS CONTACT(S) FOR SUPPORT UNIQUE FEATURES OF TVS JUPITER ACCESSORIES FOREWORD NOTICE SAFETY INFORMATION RUNNING-IN INFORMATION SAFE RIDING TIPS KNOW YOUR TVS JUPITER RIDING YOUR TVS JUPITER MAINTENANCE WARRANTY AND SERVICES...

  • Page 7: Contact(S) For Support

    Email : customercare@tvsmotor.com Disclaimer : TVS Motor Company or any of its officials / Authorized Main dealer / Authorized Dealer do not ask customers for bank / card / wallet details / authentication. In case you face any such claim, please report to the relevant local authorities immediately.
  • Page 8 CONTACT AT OUR AREA OFFICES TAMILNADU-1, 3 & 4 KARNATAKA-1, 2 & GOA MAHARASHTRA-3 & CHATTISGARH 1. TVS Motor Company Limited 4. TVS Motor Company Limited 7. TVS Motor Company Limited V Floor, Gee Gee Universal, No. 600, Anand Surya, 2nd Floor, No.
  • Page 9 MADHYA PRADESH-1 & 2 PUNJAB & CHANDIGARH WEST BENGAL 9. TVS Motor Company Limited 12. TVS Motor Company Limited 15. TVS Motor Company Limited No. 211-212, 2nd Floor, 4th Floor, Royal Business Park, Ground Floor & First Floor, Chinar Incube Business Centre, Chandigarh Ambala Highway, 133 A.
  • Page 10 ORISSA & JHARKHAND 17. TVS Motor Company Limited No. 303, 3rd Floor, Creative Plaza, Rasulgarh, Bhubaneshwar - 751 010. Phone : 0674-2580019 Email : AO.Bhubaneshwar@tvsmotor.com NORTH EAST STATES 18. TVS Motor Company Limited 147 , Udayan, Ganesh Guri, Near Hotel D Courtyard, R G B.

  • Page 11: Unique Features Of Tvs Jupiter

    UNIQUE FEATURES OF TVS JUPITER ECONOMETER® RETRACTABLE BAG HOOKS Your scooter’s speedometer has Your scooter has two retractable ECONOMETER® which indicates Bag Hooks to carry light luggage like whether you are riding in Economy carry bags weighing upto 3 kg.
  • Page 12 TELESCOPIC FRONT FORK PATENTED E-Z CENTRE STAND Your Scooter has Motorcycle-like E-Z Centre Stand of your scooter ‘Telescopic Front Suspension’ for reduces the effort required to place extreme comfort for excellent riding the scooter on stand. Refer page comfort even on bad roads. No.
  • Page 13 SYNCHRONISED BRAKE SEAT-CUM-FUEL TANK CAP TECHNOLOGY (SBT) LOCK Synchronised Brake Technology Your scooter has a ‘Dual lock’ for reduces the stopping distance, opening the seat assembly and fuel while keeping the stability intact. tank cap. You can open the fuel tank cap without even getting down from the scooter, refer page No.

  • Page 14: Accessories

    ACCESSORIES ACCESSORIES YOUR UTILITY BOX LIGHT* SCOOTER TVS Jupiter ZX has a ‘Utility Box Light‘ which lights up the utility box automatically whenever the seat is SMART PHONE CHARGER* open. Smart phone charger is supplied as an optional accessory for your INDICATOR BEEPER* scooter.

  • Page 15: Foreword

    This manual explains the features and operations of your TVS Jupiter. Kindly read it carefully and follow the instructions to enjoy years of safe riding. To ensure reliable performance, we urge you to get your TVS Jupiter serviced only at TVS Motor Company Authorised Main Dealer / Authorised Dealer at specified regular periodic intervals.

  • Page 16: Notice

    This Owner‘s Manual contains a host of useful information. Please take the time to read this manual before you ride your new TVS Jupiter. Get familiarised with the operation of your scooter for maximum safety and pleasure. The better you know your vehicle, the more pleasure you will experience riding your new vehicle. Ensure that anyone else riding your TVS Jupiter does the same.

  • Page 17: Safety Information

    SAFETY INFORMATION Operating this vehicle safely is an important responsibility of the rider. To help you make decisions on safety, we have provided necessary operating procedure and other information in this manual. This information alerts you on potential hazards that could hurt you or others. Since it is not possible to warn you about all the hazards associated with operating or maintaining the vehicle, you must use your own judgment.

  • Page 18: Running-In Information

    Timely performance of the first free service will ensure optimum service life and performance from the engine. Replacing the engine cum transmission oil during first service is most important for better life of engine. Always use TVS TRU4 SKUUTA (SAE 10W30 API-SL, JASO MB) oil for better performance and life.

  • Page 19: Safe Riding Tips

    Riding skill and your mechanical knowledge form the foundation of safe riding practices. We suggest you to practice riding TVS Jupiter in a low-traffic condition until you are thoroughly familiar with your vehicle and its controls. Remember practice makes you perfect.
  • Page 20 Posture Cornering Proper vehicle riding starts with proper posture. When cornering, centrifugal force works in a direction perpendicular to the direction in which the vehicle 1. Keep your elbows relaxed and flexible. is moving. Centrifugal force increases in proportion 2. Sit and adjust yourself on seat so that arms and with speed and the radius of the corner.
  • Page 21 Causes for poor braking ACCESSORY INSTALLATION AND SAFETY TIPS Use extreme caution while selecting and installing 1. If the brake shoes / drum are worn out or if there the accessories for your scooter. is water or oil on them, sufficient friction does not develop and brakes do not work well.
  • Page 22 EMISSION CONTROL All the TVS vehicles are tested in the factory for If there is any abnormal jerk, startability issue are felt in optimum fuel efficiency and CO levels. If the vehicle the vehicle or noise due to sudden escape of gas during...

  • Page 23: Know Your Tvs Jupiter

    KNOW YOUR TVS JUPITER VEHICLE IDENTIFICATION NUMBER The frame and engine serial numbers are the only means of identifying your vehicle from others of the same model and type. They are also required to assist your Dealer for ordering parts or referring to special information.
  • Page 24 LOCATION OF PARTS - HANDLE BAR Speedometer assembly 2. Rear view mirror L 3. Right hand brake lever 4. Throttle grip 5. Electric starter switch 6. Ignition cum steering lock Bag hook (front) 8. Horn switch 9. Turn signal lamp switch 10.
  • Page 25 LOCATION OF PARTS - VEHICLE LEFT SIDE Rear brake adjusting nut 2. Kickstarter lever 3. Effortless easy center stand 4. Side stand & side stand sensor 5. Pillion foot rest L 6. Speedometer cable Front brake adjusting nuts 8. Seat cum fuel tank cap lock 9.
  • Page 26 LOCATION OF PARTS - VEHICLE RIGHT SIDE Front wheel axle nut 2. Bag hook (rear) 3. Cover front 4. Pillion foot rest R 5. Gauge oil level 6. Muffler assembly Rear fender 8. Seat assembly...
  • Page 27 LOCATION OF PARTS - VEHICLE FRONT & REAR FRONT Head lamp 2. Head lamp focus adjuster 3. Turn signal lamp front LH 4. Turn signal lamp front RH 5. Throttle cable adjuster REAR Fuel tank cap 2. Turn signal lamp rear RH 3.
  • Page 28 3. ‘LOCK’ position IGNITION CUM STEERING LOCK TVS Jupiter steering can be locked in both ‘left’ and The ignition switch enables and disables the electrical ‘right’ directions. circuit and steering lock. The three positions of the Turn the handlebar to the ‘left’...
  • Page 29 If the battery voltage is very low, power mode lamp will glow once you switch ‘ON’ the ignition key till you start the vehicle. Electric starter will not work in this condition. Use kick starter only. Contact TVS Motor Company Authorised Main Dealer or Authorised Dealer.
  • Page 30 As a safety Registers and displays the total distance covered by measure it is recommended to visit the nearest TVS the vehicle in kilometers. The last digit denotes one Motor Company Authorised Main Dealer / Authorised Dealer.
  • Page 31 HANDLE BAR LEFT SIDE 3. Left hand brake lever (SBT brake lever) Synchronised Braking Technology (SBT) can be 1. Horn switch operated by pressing the left hand brake lever gently Press the switch ‘ ’ to operate the horn. towards the handle grip. 2.
  • Page 32 ‘ ’ to operate head lamp low beam. TVS Jupiter has a combined switch for head lamp ‘high / low beam’ and ’pass-by’. To operate the pass-by, keep the switch in ‘low beam’ position, press gently and release.
  • Page 33 HANDLE BAR RIGHT SIDE 3. Electric starter switch press the starter switch Retract the side stand ‘ ’ to start the engine electrically along with the application of either front or rear brake. It is not recommended to add any additional throttle grip (cover).
  • Page 34 FUEL TANK* CAP Fuel tank is located at the rear end of the vehicle Ensure that the fuel gun is inserted fully into the tank below the pillion holder. neck while refueling. To open the fuel tank cap, insert the control key into the ‘seat cum fuel tank cap lock’...
  • Page 35 EFFORTLESS E-Z CENTRE STAND The kickstarter lever is located on the left side of TVS Jupiter is equipped with a effortless centre the vehicle. To start the vehicle, keep the ignition in stand. The centre stand (1) has a pivoted flexible ‘ON’...
  • Page 36 Side stand can be operated by sitting on vehicle with your left foot by pushing it away from the vehicle till it stops. Always retract the side stand to its full up position before starting the vehicle. Else, the vehicle will not get start. Never sit on vehicle when it is supported by stands.
  • Page 37 4. Tool bag direction. Lift and open the seat. It is recommended to use the tool kit in case of any emergency only. It is always advisable to take your vehicle to TVS Motor Company Authorised Main Dealer / Authorised Dealer.
  • Page 38 Do not keep valuable items inside the utility box when leaving the vehicle unattended. Operating the TVS Jupiter overloaded will hamper the riding stability and may lead to loss of control. Hence, it is advisable to carry the recommended amount of load...
  • Page 39 Ensure that your mobile or any material stored is safely held with in the glove box front while riding your TVS Jupiter. * Mandatory and optional accessory will be charged extra...
  • Page 40 BAG HOOKS There are two bag hooks provided with your scooter Care should be taken not to attach the luggage which to carry light luggage like carry bags weighing upto hangs out of your scooter. Please note that the luggage 3 kg.
  • Page 41 SMART PHONE CHARGER* This smart phone charging socket enables you to charge your smart phone when you are traveling. This socket is located below left side of handle bar. Please go through the operating manual of the mobile phone and use a suitable adaptor for the battery operation recommended by the mobile phone manufacturer for that particular model.

  • Page 42: Riding Your Tvs Jupiter

    RIDING YOUR TVS JUPITER PRE RIDE INSPECTION Check the following items before riding ITEM WHAT TO CHECK FOR Engine oil Availability of oil upto the level (page No. 52) Transmission oil Availability of oil upto the level (page No. 53)
  • Page 43 STARTING THE ENGINE Ensure availability of fuel in the fuel tank. Insert the Do not raise the throttle rapidly so the vehicle will move control key into the ignition cum steering lock and forward suddenly and lead to loss of control. turn it to the ‘ON’...
  • Page 44 FUEL RECOMMENDATION Use only BS VI petrol with minimum RON 91. Never mix oil in petrol in the fuel tank. Always fill fuel BS VI petrol containing upto 20% of ethanol by volume from the reputed and reliable fuel stations. can be used.
  • Page 45 Engine oil and Transmission oil Tyres Dirty or less engine oil increases friction between Low tyre pressure has adverse effect on the vehicle. various parts of the engine and reduces the engine The drag on the vehicle increases resulting life, thereby increases the fuel consumption. decreased fuel economy.
  • Page 46 The on-road mileage of TVS Jupiter is dependent on several factors like Road condition, Quality of fuel, Riding speed, operation of Clutch and Brake, Tyre inflation, Maintenance / timely servicing of vehicle, load etc. and hence will differ from the mileage given under standard...

  • Page 47: Maintenance

    Cylinder head, steering components, suspension and wheel components etc., are key items and require very special and careful servicing. TVS Motor Company Limited strongly recommends that the jobs as per the maintenance schedule be performed by your TVS Motor Company Authorised Main Dealer / Authorised Dealer.
  • Page 48 PERIODIC MAINTENANCE SCHEDULE (months or km whichever occurs earlier) In free service After free service Item Service Every Every Remarks 500 - 750 2500 - 3000 5000 - 6000 8500 - 9000 3000 km 6000 km Period from the date of sale 2 months 4 months 8 months...
  • Page 49 In free service After free service Item Service Every Every Remarks 500 - 750 2500 - 3000 5000 - 6000 8500 - 9000 3000 km 6000 km Period from the date of sale 2 months 4 months 8 months 12 months 4 months 8 months All control cables...
  • Page 50 R - Replace; I - Inspect; T - Top up; C - Clean; A - Adjust; DR - Drain; L - Lubricate; TI - Tighten; S - Set ** Check for abnormal vehicle jerk / noise while opening the cap / leak. If found any, contact TVS Motor Company Authorised Main Dealer or...
  • Page 51 RECOMMENDED LUBRICANTS APPLICATION MANUFACTURER BRAND Engine oil 750 ~ 800 ml (during regular service) TVS Motor Company TVS TRU4 SKUUTA oil 800 ml (incase of disassembly) (SAE 10W30 API-SL, JASO MB) Transmission oil 100 ml (during regular service) -do- -do-...
  • Page 52 Check the battery voltage as per the schedule. If the voltage is less than 12.4 volts, charge the battery using recommended MF battery charger at TVS Motor Company Authorised Main Dealer / Authorised Dealer.
  • Page 53 ‘-’ terminal of the battery. Petroleum jelly must be applied at terminals to prevent it from corrosion. lncase of any abnormality or for removal of battery from the vehicle, contact TVS Motor Company Authorised Main Dealer / Authorised Dealer.
  • Page 54 Recommendations to maintain battery health c. Alternatively, battery connecting wires (positive negative wires) during prolonged parking conditions disconnected and fasteners can be secured While your vehicle is parked for prolonged duration, with battery terminals.* battery continues to discharge and if left unattended can 2.
  • Page 55 Periodic Maintenance of Batteries: • Keep top of battery clean Never operate the vehicle with discharged battery as • Check cables, clamps, and case for obvious damage it may damage electrical components. or loose connections Do not push start the vehicle, use a good battery to •...
  • Page 56 7 . Turn ‘ON’ the ignition switch and check for proper replacing the fuse. functioning of electrical systems. Incase the 1. Turn ‘OFF’ the ignition. fuse fails again, consult the nearest TVS Motor Company Authorised Main Dealer / Authorised 2. Remove the front panel as explained earlier. Dealer.
  • Page 57 SPARK PLUG 5. Pull out the suppressor cap from spark plug. Using the spark plug spanner, remove the spark To access the spark plug, the cover front has to be plug. removed. Follow the procedure to remove the cover front. A spark plug with heavy carbon deposits will not produce strong sparks.
  • Page 58 (shown in the figure). removed, to prevent dust / water entry. 5. If the oil is less than the minimum level, add ‘TVS TRU4 SKUUTA (SAE 10W30 API-SL, JASO MB)’ It is advisable to tighten the new spark plug by hand till the end, using plug spanner tighten by 1/4 turn.
  • Page 59 Check the oil level as per the schedule to avoid costly damage. Do not fill excess oil may cause oil leak. Always use ‘TVS TRU4 SKUUTA (SAE 10W30 API-SL, JASO MB)’ oil only.
  • Page 60 BRAKES Front brake - SBT type 1. Measure the free play of the front brake lever at lever end as shown in the figure. 2. The free play of the brake lever before the engagement of brake should be between 15 ~ 20 mm.
  • Page 61 Braking Technology (SBT) adjust the brakes with between the bullet top (3) and the slot top (4). additional care. If not it may result in brakes not working properly. Please contact TVS Motor Company Authorised Main Dealer or Authorised Dealer for any further assistance.
  • Page 62 Brake shoe wear indicator - Front Rear brake When the brake is applied, wear limit index mark (1) 1. Measure the free play of the rear brake lever at on the front brake cam should be within the wear the lever end as shown in the figure. limit indicator (2) on the front brake panel.
  • Page 63 3. If the measured distance is more than the limit, Brake shoe wear indicator - Rear adjust the nut provided at the rear wheel end to When brake is applied, the wear limit indication obtain the correct play. pointer (1) on the rear brake cam lever should be 4.
  • Page 64 Adjust the spring pre-load by shifting the adjuster to the required notch according to the different load TVS Jupiter is provided with 3 step adjustable rear conditions. The more you compress the spring, the shock absorbers to meet different road and load.
  • Page 65 TYRES Tyre pressure The tyre inflation pressure in cold condition and the Check the tyre pressure atleast once in a week if not tyre tread condition are extremely important for the more frequently. Insufficient air pressure in the tyres performance and safety of the rider. Check the tyres not only hasten the tyre wear, but also seriously frequently for inflation pressure as well as the wear affects the stability of the vehicle.
  • Page 66 Tyre puncture Your scooter is fitted with a tubeless tyre on both front and rear wheel. Incase of any puncture / tyre damage, it is advised to visit the nearest tyre manufacturer Dealer or the tyre repair shops who knows the repairing method of tubeless tyre. It is not necessary to remove the tyre from wheel rim always to attend a puncture.
  • Page 67 Tyre Maintenance Tips Inflation Pressure Check - Condition Within Within 1 km 5 km If vehicle is in hold condition for long time • Need movement of vehicle to avoid particular spot of tyre not to touch the ground for more than week time. •...
  • Page 68 FRONT WHEEL REMOVAL AND REASSEMBLY REAR WHEEL REMOVAL AND REASSEMBLY 1. Remove the axle nut (1) along with a washer. 1. Place the vehicle on the centre stand. 2. Pull out the axle (2) along with a washer and take 2.
  • Page 69 STORAGE PROCEDURES For storage of your scooter for longer period of over Do not park the vehicle on a slope or soft ground or else a month and above, we recommend to carry out the it may fall down. The exhaust system becomes hot after following steps: a run.
  • Page 70 2. Remount the battery after bench charging if required. 3. Fill the engine oil (TVS TRU4 SKUUTA - SAE 10W30 API-SL, JASO MB oil) and check the oil level using gauge oil level. 4. Fill the transmission oil (TVS TRU4 SKUUTA - SAE 10W30 API-SL, JASO MB oil) and check the oil level at the oil level screw.
  • Page 71 3. Turn signal lamp bulb one number. 12. Any other job as necessary. 4. Throttle, front and rear brake cable each one. 13. Have your vehicle checked at any TVS 5. First aid kit. Motor Company Authorised Main Dealer or Authorised Dealer.

  • Page 72: Warranty And Services

    TVS Motor Company Limited (‘the Company’) give this warranty with respect to the TVS Jupiter manufactured by the Company. While the Company has taken every care to maintain quality in the manufacture of the TVS Jupiter, the above said warranty is subject to other terms of warranty: ...
  • Page 73 Authorised Main Dealer / Authorised Dealer the owner’s manual for the concerned vehicle for verification of relevant details. 8. This is the only warranty given by the Company for the TVS Jupiter. No employee, Dealer or other person is authorised to extend or enlarge this warranty.
  • Page 74 List of parts not covered under warranty ITEM WHAT TO CHECK FOR Normal Maintenance Operations Engine tune-up, decarbonizing, fuel system cleaning, oil changes, head light focusing, fastener retightening, ignition timing, clutch and brakes as well as other normal adjustments. Wear and Tear Items Chain, sprockets, clutch and brake linings, fasteners, shims, washers, oil seals, gaskets, O’...
  • Page 75 Others Factors Vehicles on which any warranty service including scheduled paid service is not availed when it falls due (at TVS Motor Company Authorised Main Dealer / Authorised Dealer). Vehicles sold or transferred by original retail purchaser. Vehicles used for racing or any competition or used otherwise than for ordinary personal transportation.
  • Page 76 SERVICE INFORMATION There are seventeen services for TVS Jupiter during warranty period. Of these, first four services are free services for which labour charges are free. In addition to these four free services, we have a scheme of thirteen pay services.
  • Page 77 Planned Service Schedule (kms or month whichever of the two occurs early)* Sl.No. Service Type Months 1st Service 500 ~ 750 2nd Service 2500 ~ 3000 Free 3rd Service 5000 ~ 6000 4th Service 8500 ~ 9000 5th Service 11500 ~ 12000 6th Service 14500 ~ 15000 7th Service...
  • Page 78 Sl.No. Service Type Months 12th Service 32500 ~ 33000 13th Service 35500 ~ 36000 14th Service 38500 ~ 39000 15th Service 41500 ~ 42000 16th Service 44500 ~ 45000 17th Service 47500 ~ 48000 Free service enables the customer to avail the service at free of labour charges. Charges for the pay service should be borne by the customer.

  • Page 79: Technical Specifications

    TECHNICAL SPECIFICATIONS DESCRIPTION TVS Jupiter TVS Motor Company Limited P . B. No. 4, Harita,Hosur - 635 109, India TVS Motor Company Limited MANUFACTURER Village Bhatian, Bharatgarh Road, Teh Nalagarh, Dist. Solan. Himachal pradesh - 174 101, India ENGINE Type...
  • Page 80 DESCRIPTION TVS Jupiter TRANSMISSION Clutch Dry - Centrifugal clutch Primary transmission CVT (Continuously Variable Transmission) Primary reduction 2.58 to 0.8 Secondary reduction 10.47 CHASSIS Overall length 1834 mm Overall width 650 mm Overall height 1115 mm Seat length 782 mm...
  • Page 81 DESCRIPTION TVS Jupiter BRAKES Front (Drum) 130 mm dia (hand operated) Rear (Drum) 130 mm dia (hand operated) TYRE Front tyre 90/90 - 12 54J (tubeless) Rear tyre 90/90 - 12 54J (tubeless) Front tyre pressure** 1.70 kg/cm² (24 PSI) Rear tyre pressure - Solo** 2.25 kg/cm²...
  • Page 82 DESCRIPTION TVS Jupiter ELECTRICAL Speedometer lamp bulb 12V, 1.7W x 2 Turn signal indicator lamp bulb 12V, 1.7W x 2 High beam indicator lamp 12V, LED Low fuel warning lamp 12V, LED Economy and power mode indicator lamp 12V, LED...
  • Page 83 BS VI petrol with minimum RON 91 Fuel (containing upto 20% of ethanol by volume) Engine/transmission oil grade TVS TRU4 SKUUTA oil (SAE 10W30 API-SL, JASO MB) 750 ~ 800 ml (during regular service) Engine oil capacity 800 ml (incase of disassembly)

  • Page 84: General Information

    GENERAL INFORMATION Dear Customer, It is mandatory under the Motor Vehicles Act to insure all motor vehicles. No motor vehicle can be used in a public place without a valid policy of insurance issued by an authorised insurer. Driving a motor vehicle without any such insurance is an offense under Motor Vehicles Act.
