2
ESD Protective Cover
3
Diffuser Cover
4
YAG Protective Cover
5
Power and I/O Cable
6
M12 Network Cable
5.2 Install Device
Before You Start
● Make sure the device in the package is in good condition and all the assembly parts are
included.
● Make sure that all the related devices are powered off during the installation.
Steps
1. Select a suitable installation location according to the device's field of view.
Note
Refer to the device's datasheet for its FoV and installation range.
2. Adjust the device's right angle rotation structure according to the installation location.
SC3000X Series Vision Sensor Quick Start Guide
Straight Angle Installation
Figure 5-1 Adjust Right Angle Rotation Structure
Quantity
1
It is used to achieve ESD protection.
It
is
1
interference.
1
It is used to avoid YAG laser.
You can purchase flexible or different-length
12-pin M12 to open cable according to actual
1
demands.
You can purchase flexible or different-length
1
M12 to RJ45 network cable according to
actual demands.
Right Angle Installation
11
Description
used
to
suppress
background
