SC3000X Series Vision Sensor Quick Start Guide

Chapter 4 12-Pin Connector and Indicator

4.1 12-Pin Connector

Read the following section to get pin definitions of 12-pin connector.
No.
Signal
1
DC-PWR
2
GND
3
LINE 3
4
LINE 4
5
LINE 5
6
OUT_COM
7
LINE 0
8
LINE 1
9
LINE 2
10
IN_COM
11
RS-232_R
12
RS-232_T
Figure 4-1 12-Pin Connector
Table 4-1 Pin Definitions
I/O Signal Source
--
--
LINE 3 output signal line
LINE 4 output signal line
LINE 5 output signal line
LINE 3/4/5 output signal
ground
LINE 0 input signal line
LINE 1 input signal line
LINE 2 input signal line
LINE 0/1/2 input signal
ground
--
--
Description
Direct current power
supply positive
Power supply ground
I/O isolated output 3
I/O isolated output 4
I/O isolated output 5
Output common port
I/O isolated input 0
I/O isolated input 1
I/O isolated input 2
Input common port
RS232 input
RS232 output
8
Cable Color
White
Brown
Green
Yellow
Gray
Pink
Blue
Red
Black
Purple
Gray/Pink
Red/Blue
