SC3000X Series Vision Sensor Quick Start Guide
No.
Name
2
Image Sensor
3
Light Source
4
Aiming System
5
Trigger Button
6
Device Indicator
7
Rear Screw Hole
Right Angle Rotation
8
Structure
9
12-Pin Connector
10
Network Interface
11
Bottom Screw Hole
It is used to acquire images.
It is the white point light source × 4 and white diffused light
source × 18 by default, which is used to provide light when the
device acquires images.
Note
The red/blue/IR light source is optional.
It is orange LED light used to show the field of view and aim
targets.
It is used to trigger the device via pressing the button. If the
device is in trigger mode, press the button and the device
triggers once.
It is a 360 ° visible indicator for observing the device's status.
It is used to fix the device, and you should use M3 screws.
It is used to rotate the device's cables.
It provides power supply, I/O, and RS-232 signals.
It is fast Ethernet for transmitting data.
It is used to connect protective cover, and you should use M3
screws.
7
Description
